7cx-7.0 Series Tractor Trailer for Sale

Product Description

7C(7CB) series trailer is suitable to be used for plain area, mountain area, swamp and hills, farmland and highway transportation etc, different area environment, trailers of different forms match the tractors of different types.
On basis of fundamental type, we have developed the hydraulic pressure self-discharging trailer, improved efficiency.The trailer that our company produced are composed of steel entirely, the appearance is exquisitely, artistic and unaffected, the structure is rational and compacted, sturdy and durable, be able to adjust the height, the machines are advantageous and reliable, they are good assistant of mountain area friends.
Technical parameters:

Agricultural trailer
Number	Product Name	Model	Overall dimensions (mm)	Matched power (kw)	Weight (kg)	Rated load (kg)	Carriage size (mm)	Way of braking	Number of wheels	Specification of tire
1	Dump Trailer	7CBX-1.5	2900×1680×1580	12-30	420	1500	2000×1000×450	Mechanical brake	2	6.50-16
2	Dump Trailer	7CBX-2.0	3100×1680×1580	12-30	430	2000	2000×1000×500	Mechanical brake	2	7.50-16
3	Dump Trailer	7CBX-2.0A	3300×1680×1580	12-30	480	2000	2200×1200×500	Mechanical brake	2	7.50-16
4	Dump Trailer	7CBX-2.5	3600×1580×1680	12-40	580	2500	2500×1500×450	Mechanical brake	2	8.25-16
5	Dump Trailer	7CBX-3.0	4180×1680×2080	18-30	680	3000	3000×1600×450	Mechanical brake	2	8.25-16
	Dump Trailer	7CBX-5.0		30-60	1150	5000	3000×1600×450	Air braking	2	8.25-16
6	Dump Trailer	7CX-3.0	4680×1800×2080	25-50	1100	3000	3400×1700×450	Air braking	4	6.50-16
7	Dump Trailer	7CX-4.0	5300×1800×2100	30-70	1300	4000	3800×1700×450	Air braking	4	7.50-16
8	Dump Trailer	7CX-5.0	5500×2180×2280	50-80	1650	5000	3900×2100×500	Air braking	4	8.25-16
9	Dump Trailer	7CX-6.0	6000×2250×2280	50-80	1850	6000	4500×2150×500	Air braking	4	9.00-16
10	Dump Trailer	7CX-7.0	6500×2250×2280	50-90	2100	7000	4900×2150×550	Air braking	4	9.00-20
11	Dump Trailer	7CX-9.0	7200×2250×2380	50-100	2300	9000	5600×2150×550	Air braking	4	9.00-20
12	Dump Trailer	7CX-10	7600×2250×2400	50-100	3000	10000	6000×2150×600	Air braking	8	8.25-16
13	Dump Trailer	7CX-12	8000×2250×2520	65-120	3220	12000	6500×2150×650	Air braking	8	8.25-16
14	Dump Trailer	7CX-15		65-120	3400	15000	6500×2150×650	Air braking	8	8.25-16
15	Dump Trailer	7CX-20		65-120	3800	20000	6500×2150×650	Air braking	8	8.25-16
Number	Product Name	Model	Overall dimensions (mm)	Matched power (kw)	Weight (kg)	Rated load (kg)	Carriage size (mm)	Way of braking	Number of wheels	Specification of tire
14	Trailer	7CB-0.5	3160×1200×1250	Hand 12-15	166	500	1600×900×320	Mechanical brake	2	5.50-16
15	Trailer	7CB-0.8	3380×1250×1300	Hand 12-15	180	800	1800×900×320	Mechanical brake	2	6.00-16
15	Trailer	7CB-1.0-1.5	3600*1250*1300	Hand 12-15	190-200	1000-1500	2100×900×330	Mechanical brake	2	6.00-16
16	Trailer	7CB-1.5	3580×1680×1580	12-30	320	1500	2000×1000×450	Mechanical brake	2	6.50-16
17	Trailer	7CB-2.0	3100×1680×1580	12-30	380	2000	2000×1000×500	Mechanical brake	2	7.50-16
18	Trailer	7CB-2.0A	3300×1780×1580	12-30	420	2000	2200×1200×500	Mechanical brake	2	7.50-16
19	Trailer	7CB-2.5	3880×1580×1680	12-40	520	2500	2500×1500×450	Mechanical brake	2	8.25-16
20	Trailer	7CB-3.0	4180×1680×2080	18-30	620	3000	3000×1600×450	Mechanical brake	2	8.25-16
21	Trailer	7C-3.0	4680×1780×2080	25-50	850	3000	3400×1700×450	Air braking	4	6.50-16
22	Trailer	7C-4.0	5300×2000×2100	30-70	1100	4000	3800×1700×450	Air braking	4	7.50-16
23	Trailer	7C-5.0	5500×2100×2280	50-80	1400	5000	3900×2100×500	Air braking	4	8.25-16
24	Trailer	7C-6.0	6000×2100×2280	50-80	1650	6000	4500×2150×500	Air braking	4	9.00-16
25	Trailer	7C-7.0	6500×2100×2280	50-90	1850	7000	4900×2150×550	Air braking	4	9.00-20
26	Trailer	7C-7W		50-90	2150	7000	4900×2150×550	Air braking	4	9.00-20
27	Trailer	7C-9.0	7200×2200×2380	50-100	2100	9000	5600×2150×550	Air braking	4	9.00-20
28	Trailer	7C-10	7600×2250×2400	50-100	2500	10000	6000×2150×600	Air braking	8	8.25-16
29	Trailer	7C-12	8000×2300×2520	65-120	2800	12000	6500×2150×650	Air braking	8	8.25-16
30	Trailer	7C-15		65-120	3000	15000	6500×2150×650	Air braking	8	8.25-16

---
