CNC Slitting /Folding Machine (4 METERS)

Product Description

CNC SLITTING /FOLDING MACHINE (4 METERS)
If customization:No
Series:Hydraulic Folding/Bending Machine
Type:4 meter
Overall Dimensions: 5800mm×1700mm×1500 mm (estimated only)
Total G.W.: 3000KG (estimated only)
Brand:Erudite roll forming
Technical Parameters
The main technical parameters are for your inference only

(1)General Parameter
Raw material	Steel sheet; Aluminum; Stainless steel
Thickness	Max.1.0mm
Feeding width	Max. 1000mm
Driven by Servo motor	pump motor: 0.82KW
Working length	4000mm
Press clamp	5 units
Weight	Approx. 3000 Kg
Pressing power	pump motor for hydraulic station7.5KW(Located inside)
Bending range	0-125 degree
Depth of throat	1000 mm(Max. working width of material in clamp)
Hinge	5 groups
Total power	9.42KW (7.5KW+1.1KW+0.82KW)
Outline dimension	(Length×Width×Height):5800×1700×1500 mm
(2) Slitting Device
Type Of Blade : Slitting wheel Diameter:∮80 (Enough) Material:Cr12MoV
Drive system:Motor driving, 1.1KW Guiding device:Steel rope circling
Slitting speed:Approx.0.8m/s Slitting distance: Through steel rope circulation
(3) Bending & Slitting Device
Max. Bending thickness	1.0mm
Max. Bending length	4000mm
Max. Slit thickness	1.0mm
(4) Hydraulic power pack
Capability	Max.16MPA
Power source	Hydraulic
(5)PLC Control System
System	Siemens PLC Control
Numerical control locating system	Siemens PLC Control
Operating table	Touch Screen
Angle programmer	Encoder test
Slitting control	Manual
Emergency stop	e-stop button+ e-limit+ foot switch (right heavily)
(6)About us
Please visit the web site: eruditerfm.en.made-in-china.com for detailed information

Packing Method:
Main body of machine is naked and covered by plastic film(to protect of dust and corrosion),
loaded into container and steadily fixed in container suitable by steel rope and lock, suitable for long-distance transportation.
Xiamen Erudite Machinery Co., Ltd is a professional manufacturer specializing in the design and production of roll forming machines and bending/curving machines to serve the metal building industry.
Before the inception of its establishment, Erudite invested and set up its own R & D team to enhance the technologies in design, production and quality control. Erudite has experienced engineers and technicians who have worked in this field of business for over 10 years individually. Erudite can provide customized, accurate and comprehensive design for machinery according to the clients' profile drawings and technical requirements. Erudite has actively invested in research and development, obtained a number of patents, and has been selected as a National High-tech Enterprise in 2021.Erudite equipped with professional production technical management personnel, supporting series supply chain services from design, production, and technical support to after-service. The professional sales team in Erudite is responsible for providing professional recommendation and solutions to clients before sales and after sales to ensure our customers can maximize their investment and meet their production requirements/demands with a fruitful return on investment.
Erudite is willing to be your sincere and trustworthy partner!

---
