Diy Ozone Generator Damp Proof Ozone Ceramic PlatesProduct Description
Brief introduction:
Aquapure ozone module was developed from German office which use the latest corona discharge technology. With a high performance, we use accurate quartz tube and 304 Stainless steel electrode for the generator part, we sure a stable unit will help you win more business.
Functions and Features:
1. High performance and compact size
2. Very stable performance
3. Very easy installation with very reasonable design
4. Fan cooling mode & with a big cooling fins area
7. Quartz tube can be easily cleaned, should it become contaminated.
8. High ozone concentration with dry air source
100% check ozone concentration100% burn-in test100% 304 stainless steel and ozone compatible materialSuitable for water treatment/air treatment/medical treatment300mg/h-500mg/h ozone output available
1. Ozone output: 500mg/h with dry air, 300mg/h with normal air
2. Ozone generator: Quartz Tube and 304 Stainless Steel Electrode
3. High ozone concentration: > 5.0 mg/L at 1.0 L/min gas flow
4. Light weight: only 0.3 Kgs
5. Technology: German corona discharge
6. Low power consumption: 10W
7. Able to be used as (a)Water application; (b)Air application ; (c) Medical application
AOT-D-500 Specification
|
Ozone Output
| 500mg/h at 2.5 L/min dry air;
300mg/h at 2.5L/min normal air
|
Ozone Concentration
| > 5.0 mg/L at 0.5-1.0 L/min gas flow
|
Gas Flow
| 2.5 L/min recommended
|
Generating method
| German corona discharge
|
Continuous operation
| 24 h/day with cooling system
|
Cooling system
| Air cooling and with big cooling fins areas
|
Gas source
| Ambient air, dry air and oxygen
|
Input voltage
| 12 VDC
|
Power input
| < 10 W
|
Operating temperature
| -10 °C~ +60 °C
|
Storage temperature
| -20 °C~ +70 °C
|
Size Generator L x W x H (mm)
| 100.6 x 40 x 30
|
Size Electronic L x W x H (mm)
| 100 x 41 x 33
|
Weight
| 0.30 kgs
|
Able to be used
| water /air treatment/medical
|
Packing detail:
l Foam and bubble bag for each unit, 60 pcs/carton
l Weight: 0.3kg/pcs, 19kg/carton
l Carton size: 68x47x36cm
About Us
Certifications
Why choose AQUAPURE:
Select material:
In order to produce high performance Ozone product with competitive price, We select material supplier in person.
Attention to detail:
To ensure the constant quality of products, AQUAPURE is strict in testing system to make sure ozone products are in good system.
Quality guarantee:
Committed to the standradization of the ozone market , AQUAPURE make strict control of every step from assembling to packing.
Company information:
AQUAPURE’s core technology is from Germany and was invested by German since 2002. We are mainly manufacture ozone generators, plasma generators and anion generators in China. We Committed to the standardization of the ozone market, Our group is making great effort in the high quality and stable performance.
Product Catalogue
Product scope:
Ozone ModulePlasma GeneratorPortable Ozone GeneratorIndustrial Ozone GeneratorAir Dryer for Ozone GeneratorHousehold Air PurifierAir PumpDiffuser StoneNon-return ValveVenturi: 1/4'', 1/2'', 3/4'',1''Silicone TubeFAQ
1.What’s your after sales service?
We offer one year warranty and also provide technical support even exceed the warranty period.
2. When will you ship after I pay?
Normally we can ship within 5 days for sample order, 5-10 days for small order, please confirm the actual delivery time with our sales according to your quantity .
3. How can I pay?
We accept T/T, Paypal ,credit card and western Union, please let us know your payment method and we will send you the account information accordingly.
4. What shipping method I can choose?
A:We can ship by Sea and air for bulk order ;
B: DHL, FEDEX, UPS, TNT, ARAMEX,EMS and some other special line express with competitive price are optional, it takes 5-10 days to get the parcel based on your area.
Contact Information
Contact person: Queenie Wei
Tel.: 0086-755-26605963
Cell: 0086-15820425983
Skype: queenie.wee2
We chat:queenie.wee
What’s app:0086-15820425983
>>
