| Item | Unit | XH2016 |
| X axis travel | mm | 2000 |
| Y axis travel | mm | 1650 |
| Z axis travel | mm | 800 |
| Spindle nose to worktable | mm | 250-1050 |
| Distance between two column | mm | 1660 |
| Leadscrew diameter | mm | 63/50/50 |
| Linear guideway width | mm | 55/55/Rectangle |
| Worktable Length | mm | 2000 |
| Worktable width | mm | 1300 |
| T slot qty-width*distance | mm | 7-22*170 |
| Max loading capacity | Ton | 4 |
| Spindle speed | rpm | 10000/belt |
| Spindle motor power | kw | 15 |
| Fast moving speed | m/min | 20/20/10 |
| Cutting speed | mm/min | 1-8000 |
| Spindle taper | BT50 | |
| Feed motor power | kw | 6/5/5 |
| X/Y/Z axsis motor torque | Nm | 38/30/30 |
| Tool Magazine Capacity | pcs | Disc/24 |
| Positioning accuracy | mm | 0.016/0.015/0.015 |
| Repeat accuracy | mm | 0.012/0.010/0.010 |
| Length | mm | 4000 |
| Width | mm | 2950 |
| Height | mm | 3200 |
| Weight | kg | 16800 |
