Transmitter | Receiver | ||
Output power | H:7W L:1W | Sensitivity | Better than 0.2µV(width) Better than 0.25µV(narrow) |
Modulation | 16K¢F3E(width) 8K¢F3E(narrow) | Adjacent selectivity | ≥60dB(width)/50dB(narrow) |
Noise and harmonic | ≤-36dB | Intermodulation rejection ratio | ≥60dB(width)/50dB(narrow) |
FM noise | ≤-40dB | Spurious suppression | ≥60dB(width)/50dB(narrow) |
Rated audio distortion | ≤5% | SNR | ≥45dB(width)/ 40dB (narrow) |
Adjacent power | ≥55dB(width)/55dB(narrow) | Rated audio output power | 500mW |
Modulation limitation | ≤5KHz(width)/2.5KHz(narrow) | Rated audio distortion | ≤5% |
