Product Details
Product Description
Product Description
Basic Info.
Model NO.
HP-CSD250
Cyclone Type
Customized
Slot Type
CTS
Customized
Customized
Condition
New
Warranty
12 Months Free Warranty, Free Repair.
After-sales Service
Lifetime Technical Support
Solid Capacity
180m3/H
Water Flow
800-900m3/H
Dredging Depth
8-10m
Discharge Distance
1000m
Transport Package
Yes
Specification
8 inch
Trademark
HengPeng
Origin
China
HS Code
89051000
Production Capacity
120 Sets
Product Description
Product Description
Exquisite Cutter Head Suction Dredger Crafted by Heng Peng Shipyard: Your Ultimate Solution for Efficient and Effective Dredging
Product Description
1. Introduction:
Our state-of-the-art Cutter Suction Dredger, featuring robust steel construction and a modular, non self-propelled design, is versatile enough to operate in various water bodies, whether in coastal zones or inland rivers. It meets the stringent standards of navigation area 'A' or regions below the 'A'-line as per the P. R. China's inland river steel engineering ship manufacturing code.
This innovative dredger excels in excavating and transporting cohesive sediments, adhering to the Class III specifications set forth in the dredging engineering construction techniques issued by the Ministry of Water Resources (MWR) of P. R. China.
Built with precision, the hull consists of three meticulously designed pontoons: one main pontoon (housing the engine room) and two side pontoons. The YS-CSD450 dredger can be effortlessly transported by road, rail, or water. It features a rapid connection-disconnection system for the pontoons, with secure bolt attachments at the deck level, hull front and rear, and hooks at the bottom. Powered by a robust Marine engine, the main engine drives both the dredge pump and the hydraulic pump, which in turn, powers all other equipment such as cutter, swing and ladder winches, and the spud rams, ensuring seamless operations.
Constructed with all-welded, high-strength steel, the hull offers the durability needed for rigorous dredging operations. The side pontoons are securely bolted to the main pontoon, ensuring stability and strength.
Our hull steel plates utilize CCSB (shipbuilding steel plate) for unparalleled durability.
2. Key Features:
1. Effortless one-man operation with the latest PLC control system.
2. Cutting-edge, highly efficient cutter/wheel drive system.
3. Exceptionally reliable hydraulic system.
4. Advanced fresh water cooling system.
5.Comes fully assembled and rigorously tested before delivery for ultimate reliability.
6. Quick and easy assembly, whether afloat or onshore.
7. Standardized design for minimal delivery lead times.
8. Standard spare parts readily available from our inventory.
9. Engineered to meet Coastal Waters Certification standards.
10. A variety of optional equipment available to suit your needs.
3. Hull Decomposition:
Product Parameters
Main Parameter Information: Unveiling the future of slush removal, the New Generation Mini Dredger Machine is meticulously engineered to redefine efficiency and performance. Designed for unparalleled functionality, this innovative machine is poised to set new industry standards.
| Cutter Suction Dredger Specs HP-CSD200 |
| No. | Item | Parameter | Remark |
| 1 | Product Name | HP-CSD200 |
|
| 2 | Total Length | 16.0m |
|
| 3 | Hull Length | 11.05m |
|
| 4 | Hull Width | 4.4m |
|
| 5 | Hull Depth | 1.3m |
|
| 6 | Draft | 0.8m |
|
| 7 | Main Engine | 450KW ; 1 set
| WEICHAI MARINE ENGINE POWER |
| 8 | Auxiliary Engine | 24KW ; 1 set | WEICHAI MARINE POWER |
| 9 | Dredging Depth | 8-10m |
|
| 10 | Pump Water Flow Capacity
| WN200, 800-900m3/h
|
|
| 11 | Discharge Distance
| 1000m
|
|
| 12 | Waranty | 12 Months |
|
| 13 | Pump Discharge Dia | 200mm | SHIJIAZHUANG,Austrilia Technology |
| 14 | Pump Suction Dia | 250mm |
|
| 15 | Solid Capacity | 180m3/H |
|
| 16 | Total Working Weight of machine | 60Ton |
|
| 17 | Spud | two pieces |
|
| 18 | Hydraulic Winch | 3 pieces/sets |
|
| 19 | Navigation Ability | Yes |
|
| 20 | Operation System | PLC Control System and Hydraulic system
|
|
| 21 | Spare Part | Diesel engine tools,oliseal,eletric,welder and so on |
|
Certifications
Packaging & Shipping
*For our more compact dredger models, transportation is streamlined via container shipping. The dredger is dissassembled, ensuring each component fits securely into containers for efficient shipping. Upon arrival at the job site, our expert engineers will handle the complete assembly, conduct thorough testing, and provide comprehensive training.
* Larger dredger units are shipped via bulk cargo vessels across the sea,once all cargoes are delivered to the job site,our proficient engineers will then manage the assembly, conduct rigorous testing, and offer in-depth training.
After Sales Service
1. Lifetime Technical Support: Enjoy our unwavering technical assistance for a lifetime, ensuring your Mini Dredger Machine operates at peak performance.
2. 24-Hour Service Response: Experience our rapid response mechanism, designed to address any service needs within 24 hours, guaranteeing minimal downtime.
3. Detailed Customer Records: We meticulously maintain customer records for superior long-term follow-up services, ensuring your satisfaction and continued success.
4. Customizable Dredgers: Each of our dredgers can be tailored to meet your specific needs, delivering a perfect solution every time.
5. On-Site Support: Our engineers provide field installation, commissioning, and comprehensive training to ensure seamless integration and operation.
6. Timely Professional Service: Receive expert service and prompt solutions from our dedicated team, guaranteeing your operations run smoothly.
7. 12-Month Free Warranty: Benefit from a full year of free warranty service, including complimentary repairs, to keep your machine in top condition.
8. Expert Assembly and Testing: Our engineers will assemble and test your machine within the agreed contract period, ensuring it's ready for optimal performance.
9. Detailed Customer Records: We meticulously maintain customer records for superior long-term follow-up services, ensuring your satisfaction and continued success.
>>
