| US$7.00 | 10 Pieces (MOQ) |
| Metric | Inch | |||||||
| Painted | Chromed | Painted Frame | Chromed Frame Plated | |||||
| Frame | Frame | 0.0001" | 0.00005" | 0.0001" | 0.00005" | |||
| Range | Grad. | Model No. | Model No. | Range | Model No. | Model No. | Model No. | Model No. |
| 0-25mm | 0.001mm | 600-5025 | 601-5025 | 0-1/2" | ||||
| 25-50mm | 0.001mm | 600-5050 | 601-5050 | 0-1" | 600-0111 | 600-0051 | 601-0111 | 601-0051 |
| 50-75mm | 0.001mm | 600-5075 | 601-5075 | 1-2" | 600-0112 | 600-0052 | 601-0112 | 601-0052 |
| 75-100mm | 0.001mm | 600-5100 | 601-5100 | 2-3" | 600-0113 | 600-0053 | 601-0113 | 601-0053 |
| 0-13mm | 0.01mm | 601-A013 | 3-4" | 600-0114 | 600-0054 | 601-0114 | 601-0054 | |
| 0-25mm | 0.01mm | 600-4025 | 601-4025 | 4-5" | 600-0125 | 601-0115 | ||
| 25-50mm | 0.01mm | 600-4050 | 601-4050 | 5-6" | 600-0126 | 601-0116 | ||
| 50-75mm | 0.01mm | 600-4075 | 601-4075 | 6-7" | 600-0127 | 601-0117 | ||
| 75-100mm | 0.01mm | 600-4100 | 601-4100 | 7-8" | 600-0128 | 601-0118 | ||
| 100-125mm | 0.01mm | 600-4125 | 601-4125 | 8-9" | 600-0119 | |||
| 125-150mm | 0.01mm | 600-4150 | 601-4150 | 9-10" | 600-0210 | |||
| 150-175mm | 0.01mm | 600-4175 | 601-4175 | 10-11" | 600-0211 | |||
| 175-200mm | 0.01mm | 600-4200 | 601-4200 | 11-12" | 600-0212 | |||
