Large Capacity Hydraulic Car Elevator Platform with CE Approved

Product Description

Large Capacity Hydraulic Car Elevator Platform with CE Approved
As a premier manufacturer of 4 post car lifts, XYZLift is your dependable partner for efficient and reliable vertical vehicle transportation. Our superior lifts are designed to meet the diverse needs of your business, ensuring smooth movement of cars across floors. With XYZLift, you can customize your 4 post car lift to your exact specifications. Our offerings include lifts with rolling doors for garages and platforms with rotating capabilities. Whether you need a specific table size, height adjustment, or load capacity, we can tailor the lift to your precise requirements. Our lifts can be installed in a pit or be free-standing without a pit.
In addition to our top-tier products, XYZLift is committed to exceptional customer service. Our experienced team is on standby to provide detailed product information, assist with installation, and offer ongoing maintenance support. We strive to ensure your complete satisfaction and optimize the performance of your 4 post car lift. Choose XYZLift as your preferred 4 post car lift manufacturer and discover the unmatched quality and reliability.
Four post car lift model

Model	Load capacity	Platform size	Lift height
XYZGL-3	3000KG	3000mm*6000mm	3000mm
XYZGL-4	5000KG	2800mm*5800mm	4000mm
XYZGL-6	4000KG	3000mm*6500mm	6000mm
XYZGL-9	7000KG	2900mm*5900mm	9000mm

Major ComponentsFour Post
Our 4 post car lift boasts a 6mm steel plate guide rail, providing remarkable strength and resilience. It operates smoothly and securely under heavy loads, thanks to its robust construction. The precisely bent steel plate ensures structural integrity and reliability.Platform
The platform base our 4 post car lift is designed according to the load capacity, featuring a non-slip surface on the platform and equipped with safety guardrails.
Hydraulic Cylinder
The hydraulic cylinders of our 4 post car lift are specifically engineered for automotive lifting. The sealing rings of the hydraulic cylinders are sourced from NSK, a renowned Japanese manufacturer known for their high-quality products.
Power Pack
The motor of our 4 post car lift is supplied by Siemens, a trusted brand in the industry. We use Siemens motors for their reliability and performance. The voltage of the motor can be customized according to the specific requirements of our customers.
Control Panel
Each floor has a control panel with an emergency stop button, ensuring immediate halting in emergencies, enhancing safety and reliability.
Safety Lock
To ensure a secure and stable operation, our 4 post car lift is equipped with a pneumatic safety device. This innovative feature allows for safe locking at any leveling position, preventing any undesired downward movement.
Four post car lift safety
1.Cylinder will anti-explosion valve: If the cylinder damaged, lift will not down. Anti-explosion valve will lock oil and platform will not down.
2.Lift with anti-drop: When lift at top level, platform will anti-drop system will stop at four post.
3.Four post chain: 2 pcs main chain, one chain could bear load 50t.
4.Lift with safety steel rope: If chain cut down, safety steel rope will be still wok, platform will not down. 5.Spillover valve: It can prevent high pressure when the machine moves up. Adjust the pressure.
6.Emergency decline valve: It can go down when you meet an emergency or the power off.
7.Emergency unlock the safety lock at second floor: Lift with manual pump. Up platform by manual pump. And open the lock by manual, and emergency down platform but emergency button.
8.Platform with lilt sensor: It platform incline 1.5 degree, lift will be stop work.
9.Overload warning device: Prevent the machine work under overload.
When lift overload, lift stop work and warning.
10.Emergency button: Each control panel with Emergency button.Project Show
Surface Show
Packaing
FAQQ1.What is the delivery time for the four post car lift?
A1.The delivery time for our four post car lift is 3-5 weeks from the order deposit.
Q2.What details are required for specifying a four post car lift?
A2.To accurately specify a four post car lift, we require the following information:Load capacity: Weight and type of materials to be lifted. Platform size: Size slightly larger than the materials being lifted or shaft size Travel height: Distance between floors Loading and unloading directions: Access from one side, opposite sides, or three sides Special functions or requests: Higher speed, explosion-proof standards, weighing capabilities, specific surface treatments Additional equipment: Optional items required, such as full mesh cover, electromagnetic fall protection, landing safety fence, roller door, etc.
Q3.How many floors can a four post car lift go?
A3.Our four post car lift can travel up to 22m, covering 7 floors.
Q4.What is the maximum weight a four post car lift can lift?
A4.Our heavy-duty four post car lift can lift items weighing up to 100 tons, ensuring stability with thick steel and balance ropes.
Q5.What color options are available for the four post car lift?
A5.Please provide the interested RAL color number, and we will produce the four post car lift accordingly.

---
