US$3,000.00-18,000.00
|
1 Piece
(MOQ)
|
Basic Info.
Model NO.
TU1803 Vario/TU2104
Guide Rail
Horizontal Guide Rail
Controlling Mode
Artificial
Certification
CE, ISO 9001
Transport Package
Standard Export Packing
Specification
740x390x310mm/840x390x370mm/1030x450x430mm
Trademark
Alpha industries
Production Capacity
100 Sets/Year
Product Description
Product Parameters
Basic Info. |
Model NO | TU1803 VARIO TU2104VARIO TU2105VARIO | | Power Source | Electric |
Controlling Mode | Artificial | Automatic Grade | Manual |
Setting Mode | Foor-type | Precision | High Precision |
Certification | CE,ISO 9001 | Condition | New |
Specificaton | 740x390x310mm 840x390x370mm 1030x450x430mm | Trademark | Alpha industries |
Origin | China | Production Capacity | 100 Sets/Year |
Model No. | Unit | TU1803 Vario | TU2104 Vario |
swing over bed | mm | Ø180(7.09") | Ø210(8.27") |
swing over cross slide | mm | Ø120(4.72") | Ø210(8.27") |
admits betwee | mm | 300(11.81") | 400(15.75") |
center height | mm | 90(3.54") | 105(4.13") |
width of bed | mm | 100(3.94") | 100(3.94") |
spindle bore | mm | Ø21(0.83") | Ø21(0.83") |
spindle taper | | MT3 | MT3 |
3-jaw chuck | mm | Ø100(3.94") | Ø100(3.94") |
range of spindle speed | rpm | 150-2500 | 150-2500 |
compound rest travel | mm | 75(2.95") | 75(2.95") |
cross slide travel | mm | 85(3.35") | 85(3.35") |
max. section of tool | mm | 12×12(0.47"×0.47") | 12×12(0.47"×0.47") |
threads metric pitches | mm | 0.5-3(0.02"×0.12") | 0.5-3(0.02"×0.12") |
threads imperial pitches | | 10-44TPI | 10-44TPI |
quill diameter | mm | Ø25(0.98") | Ø25(0.98") |
quill travel | mm | 60(2.36") | 60(2.36") |
quill taper | | MT2 | MT2 |
main motor power | W | 600 | 600 |
overall dimension(L×W×H) | mm | 740×390×310 | 840×390×370 |
packing size(L×W×H) | mm | 760×500×480 | 900×480×450 |
N.W./G.W. | kg | 44/66 | 48/70 |
Standard Accessories | | | |
3-jaw chuck | Dead center MT1 | Change gears kit | Wrench |
Spanner | Splash guard | Oil gun | |
Optional Accessories | | | |
Steady rest | Follow rest | Turning tools 8×8mm | Live center MT1 |
Back plate | Stand+Chip tray | Face plate 100mm | 4-jaw chuck |
Company Profile
Certifications
Exhibition
Packaging & Shipping
FAQ
FAQs
Q1: How is the warranty?
A1: Warranty time is 15 months after BL date.
Q2: Can we visit your factory before order?
A2: Sure. All new and old friends are welcomed to visit us at our factory. Besides, we can pick up you at the station or airport if needed. We will be very honored to help with tickets and accommodation booking.
Q3: Do you have a stock?
A3: We have stock for popular models, we produce according to order.
Q4: What's the MOQ?
A4: One set only.
Q5: How about your quality?
A5: We have approved the ISO9001:2008 Quality management system.ISO14001 Environmental management system, OHSAS18001 International occupational health and safety management system, and Social Accountability 8000(SA8000). Most products have been approved by the European and American safety standards, including CE, GS, EMS&UL,90% of our products are exported to more than 40 countries and regions around the world, especially to Europe and America market and always win high reputation. So you can rest assured of our quality products and our best services.
Q6: Do you have professional engineers?
A6: Yes, we have professional engineers and designers. We can provide OEM services under Alpha brand.
Q7: Can you provide customized machines?
A7: Yes, we can design and manufacture according to your specific requirements.
>>
