Wc67y Series Estun E21 Nc Metal Sheet Press Brake Machine for Bending Plate

Product Description

Product Description - The device adopts all steel-welded construction, and vibratory stress relief. Thus the device with good rigidity and high strength, to permit high accuracy.
- The whole frame with good rigidity, work is stable, safety and reliable, easy to operate.
- To adopt stress theory to control the deformation of structural parts effectively, so can to get satisfied work-piece.
- Controller: E21 from ESTUN is a NC controller specialized in torsion axis synchronous press brake

Product Parameters

Model	Pressure	Worktable length	Distance between uprights	Throat depth	Ram stroke	Motor
WC67Y-40/ 2000	400kN	2000mm	1700mm	245mm	100mm	4kw
WC67Y-40/ 2200	400kN	2200mm	1800mm	245mm	100mm	4kw
WC67Y-40/ 2500	400kN	2500mm	2005mm	245mm	100mm	4kw
WC67Y-63/ 2500	630kN	2500mm	2005mm	250mm	120mm	5.5kw
WC67Y-63/ 3200	630kN	3200mm	2520mm	250mm	120mm	5.5kw
WC67Y-80/ 3200	800kN	3200mm	2520mm	320mm	120mm	7.5kw
WC67Y-80/ 4000	800kN	4000mm	3005mm	320mm	120mm	7.5kw
WC67Y-100/ 2500	1000kN	2500mm	2005mm	400mm	120mm	7.5kw
WC67Y-100/ 3200	1000kN	3200mm	2520mm	400mm	120mm	7.5kw
WC67Y-100/ 4000	1000kN	4000mm	3005mm	400mm	120mm	7.5kw
WC67Y-100/ 5000	1000kN	5000mm	4010mm	400mm	120mm	7.5kw
WC67Y-125/ 2500	1250kN	2500mm	2005mm	400mm	120mm	7.5kw
WC67Y-125/ 3200	1250kN	3200mm	2520mm	400mm	120mm	7.5kw
WC67Y-125/ 4000	1250kN	4000mm	3005mm	400mm	120mm	7.5kw
WC67Y-125/ 5000	1250kN	5000mm	4010mm	400mm	120mm	7.5kw
WC67Y-160/ 3200	1600kN	3200mm	2520mm	400mm	200mm	11kw
WC67Y-160/ 4000	1600kN	4000mm	3005mm	400mm	200mm	11kw
WC67Y-160/ 5000	1600kN	5000mm	4010mm	400mm	200mm	15kw
WC67Y-160/ 6000	1600kN	6000mm	4800mm	400mm	200mm	15kw
WC67Y-200/ 3200	2000kN	3200mm	2520mm	400mm	200mm	15kw
WC67Y-200/ 4000	2000kN	4000mm	3005mm	400mm	200mm	15kw
WC67Y-200/ 5000	2000kN	5000mm	4010mm	400mm	200mm	15kw
WC67Y-200/ 6000	2000kN	6000mm	4800mm	400mm	200mm	18.5kw
WC67Y-250/ 3200	2500kN	3200mm	2520mm	400mm	250mm	18.5kw
WC67Y-250/ 4000	2500kN	4000mm	3005mm	400mm	250mm	18.5kw
WC67Y-250/ 5000	2500kN	5000mm	4010mm	400mm	250mm	18.5kw
WC67Y-300/ 4000	3000kN	4000mm	3005mm	400mm	250mm	22kw
WC67Y-300/ 5000	3000kN	5000mm	4010mm	400mm	250mm	22kw
WC67Y-300/ 6000	3000kN	6000mm	4800mm	400mm	250mm	22kw

Detailed Photos
FAQ 1. Where is your factory located ?
Friendship Machinery CO., LTD (FSM) is located in Wuxi, Jiangsu, and about 40mins from Shanghai if take railway.
2. How can you guarantee your product quality?
From raw material purchase to production, FSM has strict restriction. And we will provide 1 year warranty time for all the products. ISO 9001 and CE certification can be provided.
3. How long is one order production time?
After you place a order, the production handling time is about 25-30 days. It will subject to our factory production schedule.
4. Can you accept special order?
Yes, we have our own R&D center , and our engineer can provide machine drawing according to your requirement.
5. Are your engineers available for oversea project ?
Yes, our engineers can be delegated aboard for machine installation and debugging.
6. How can you make sure the deal safe?
You can pay by TT/ LC. Making the world a better place is our company's beautiful vision, we will be your trusted partner.

---
