| US$48,500.00 | 1 sets (MOQ) |
| SPECIFICATION ITEM | KBD3980 | |||
| Injection unit | Unit | A | B | C |
| SCREW DIA | mm | 65 | 70 | 75 |
| SHOT VOLUME (THEORETICAL) | cm3 | 1193 | 1393 | 1599 |
| INJECTION WEIGHT(PS) | g | 1098 | 1250 | 1455 |
| INJECTION PRESSURE | Mpa | 210 | 170 | 130 |
| SCREW SPEED | rpm | 0-150 | ||
| CLAMPING UNIT | ||||
| CLAMPING FORCE | KN | 3980 | ||
| TOGGLE STROKE | mm | 740 | ||
| SPACE BETWEEN TIE BARS | mm | 730*730 | ||
| MAX.MOLD HEIGHT | mm | 780 | ||
| Min.MOLD HEIGHT | mm | 250 | ||
| EJECTOR STROKE | mm | 150 | ||
| EJECTOR TONNAGE | KN | 79 | ||
| OTHERS | | |||
| PUMP MOTER POWER | Kw | 40 | ||
| HEATING POWER | Kw | 25.2 | ||
| MACHINE DIMENSION(L*W*H) | m | 7.5*1.95*2.4 | ||
| MACHINE WEIGHT | T | 19 | ||
