Tow Behind ATV Log Splitter

Product Description

WS-30T Log splitter adopts the hydraulic working principle to split tree stumps, large branches,logs and harder wood material to achieve the effect of raw materials into materials for other uses.
The cutting blades have telescopic linear motion, with a maximum cutting length of 650mm and a maximum push force 30T and the splitter's reciprocating time is 10-12S. The front of the log splitter is equipped with a traction moving mechanism to meet a variety of working scenarios. And it combines ergonomic design to fulfill product functionality and provides a perfect operating experience. The machine equipped with an operating lever, which can achieve loading and log splitting operations continuously .

Oil Tank Capacity:	120L
Max Flow of Pump:	80L/min
Max Working Pressure:	21MPa
Max Splitting Force:	4-17T
Cycle Time:	6~12S
Engine Power:	14HP
Max Towing Speed:	30KM/H
Dimension:	4048.8*1454*1621.5MM
Recommended Hydraulic Oil:	HM32or HM46
Start-up Voltage:	12VDC
Max Splitting Height:	650mm
Max Splitting Diameter:	320mm

AWON GROUP founded in 2006 which headquarter in the Netherlands is an integrated solution provider for modern Agricultural, Orchard and Gardening applications. With much effort of these years, AWON machinery gradually grows up to a pioneer in modern agriculture from designing to manufacturing a wide range of agricultural implements which used in commercial crops and field crops, including: Mower, mulcher, wood shredder, cotton baler, straw baler etc. With AWON GROUP's excellent design concepts and reliable product performance to help users improve operating efficiency, reduce usage costs, and increase profits, thereby protecting the ecological environment and achieving sustainable development of agriculture and nature.
The following are our patent certificates: Design Patent (mulcher), Utility Patent (branch mulcher, mulcher blades, pick-up branch mulcher and telescopic mower)
The following are our original hand-painted drawings, originality has always been our pursuit!

---
