660 Channels Smart Hi-Target GPS Surveying Instrument V200 V300 Gnss Rtk with Ihand55 Controller

Product Description

Product DescriptionKey Features :
1. The new IMU can be measured by shaking it
2. Built-in integrated battery
3. Fast charging, can be fully charged in 1 hour
4.Small size, easy to carry
5,Higher Accuracy and Precision
6,Equipped with the High-Performance Patch Antenna,
7,enhances the low elevation angle tracking capabilities
Detailed Photos
Product Parameters
SPECIFICATIONS

V200 specification
Channels	800+
Satelite Tracked	GPS:L1/ L2/ L5/L2C
	BeiDou:B1/ B2/ B3/B1C/B2a
	GLONASS: L1/L2/L3
	Galileo:E1/ E5 AltBOC/E5a/E5b/E6
	QZSS:L1/L2/L5/L6
	SBAS: L1/ L5
	IRNSS:L5
Static and Fast static Gnss Surveying
Horizontal	± (2.5+0.5× 10-6d) mm (D is the distance between measured points)
Vertical	± (5+0.5× 10-6d) mm (D is the distance between measured points)
Post Processing Kinematic (PPK / Stop & Go ) GNSS Surveying
Horizontal	8mm+1ppm RMS
Vertical	15mm+1ppm RMS
Initialization time	Typically 10 min for base while 5 min for rover
Initialization reliability	typically > 99.9%
High-precision static GNSS Surveying
Horizontal	±(8+1×10¯6D)mm (D is the distance between measured points)
Vertical	:±(15+1×10¯6D)mm D is the distance between the measured points
Code Differential GNSS Positionnig
Horizontal	±0.25m + 1 ppm RMS
Vertical	±0.25m + 1 ppm RMS
SBAS
Positioning accuracy	0.50m Horizontal, 0.85m Vertical
Real Time Kinematic (RTK)
Single Base	Horizonta:8mm+1ppm RMS
	Vertica:15mm+1ppm RMS
Network RTK	Horizonta:8mm+0.5ppm RMS
	Vertical:15mm+0.5ppm RMS
	Initialization time:Typically <10s
	Initialization reliability:Typically > 99.9%
Communication
Internal UHF Radio	Frequency: 410-470MHz
	Channels:116 (16 adjustable)
	Transmitting power:0.5W,1W,2W
	agreement:Hi-Target, Trimtalk450S, trimmarkIII, Transeot, SATEL-3AS,South,CHC,ect
	Working Range:3-5km typical, 8-10km optimal
HI-TARGET External UHF Radio(Standard)	Frequency: 403-473MHz
	Transmitting speed:Up to 19.2Kbps
	Channels:116 (16 adjustable)
	5W,10W,20W,30W adjustable
	Working Range:8~10km typical,15~20km optimal
IMU(Tilt Survey)	Built-in high-precision inertial navigation, automatic attitude compensation, no correction, anti-magnetic interference, instant measurement at the point of arrival;
Network Communication
Full band support for cellular mobile network(LTE, WCDMA, EDGE, GPRS, GSM) 2.4GHz WIFI, supports 802.11b/g/n. Network RTK (in CORS) range is 20-50km
Physical
Dimensions(W×H)	132mm*67mm
Weight	≤0.83kg (includes battery)
Shock and vibration	Designed to survive a 2m(9.84ft) natural fall onto concrete
Water/Dustproof	IP67
Humidity	100% condensing
Operation temperature	-30ºC~+70ºC
Storage temperature	-40ºC~+80ºC
Bluetooth	2.1+4.0
NFC	NFC flash even
A serial port	RS232 serial port
Control Panel	Physical button
Energy consumption and working hours
Electrical	Power 6V to 28V DC external power input
	Power consumption≤4.2W
	Built-in high-capacity lithium battery 6800mAh/7.4V, support USB PD3.0 super fast charging, charging time <3.5h
Internal Battery Life	Static more than 10 hours
	RTK rover (UHF/GPRS/3G)6-10 hours
	RTK base more than 10 hours

Company Profile Our company is to provide professional surveying instruments and surveying service, and with rich experience in export trade, We have many customers abroad.Because of its high cost performance, it is deeply loved by customers all over the world, especially in African countries, Southeast Asian countries, South American countries and Oceanian countries. We have many customers in Tanzania, Uganda, Zambia, Cote d'Ivoire, Cameroon, Zimbabwe, Congo, India, Singapore, Pakistan, Mongolia Brazil, etc.Our company mainly sales of Total station, Auto/digital level, Optical /electronic theodolite, GNSS RTK, Laser distance meter, Handheld GPS, Drone, Surveying accessories, Surveying software, etc. We have good price with Trimble, Hi-target, South, Kolida, Sanding, Ruide, Chc, Stonex, Foif, Tersus, sokkia, spectra, nikon, Topcon, etc. And we keep good cooperation with surveying accessory manufacturer.The Company's employees graduated from engineering, surveying professional institutions of higher learning, with professional knowledge, is a high-quality sales and service team to provide you with excellent quality instrument service and efficient surveying solutions.Our goal: Be a best and professional export supplier of surveying instruments.Packing details
Payment support :
Delivery&transport
Contact us https://njjmch.en.made-in-china.com/contact-info.html
Customer feedback
FAQ1. how long we guarantee quality?
Our main products like Auto level, Theodolite, Total Station,Gnss rtk have one year warranty, And we sure the products will be free from maintenance within warranty period If it is not man-made damage,and accessories with 6 month warranty
2.what can you buy from us?
Auto/digital level, Theodolite, Total Station,Gnss rtk,Laser level,Laser distance meter, drone ,3D scanner, Echo sounder and surveying accessories like tripods,ranging pole,prism,bipod .etc
3.what repair service can we provide if products got problem?
For small issues like missing or damaged part, key board, please send us the photos, we will send the required part and related instructions to you for free;
For big issues in one year warranty like EDX board, main board issue. We could only ask you to send the instrument back to us. Normally we will have it fixed in 10 working days and send back to you. You and we shall take care of the corresponding shipping cost on each side. For big issues out of one year warranty, the customer should be responsible for all the cost.
4,what payment term we support?
TT, Paypal, Western union,L/C,Pay in cash
5, How will we prepare before shipment?
All products will have been strictly quality checked in factory before sending out.Usually, we will send out the products within 3-5 working days after the payment confirmed and the buyer are responsible for the tax and/or duty charged by their country.

---
