| US$1.00-2.00 | 1 Piece (MOQ) |
| PET STYLE SPECIFICATION | UE/560 | ||||
| SCREW TYPE | A | B | C | D | |
| Injection Unit | |||||
| Screw diameter | mm | 80 | 85 | 90 | 100 |
| Screw L/D ratio | L/D | 25 | 25 | 25 | 25 |
| Shot volume(theoretical) | CM3 | 2212 | 2497 | 2799 | 3456 |
| Injection weight(PET) | g | 2758 | 3113 | 3490 | 4309 |
| Injection rate | g/s | 607 | 685 | 769 | 949 |
| Injection pressure | MPA | 179 | 159 | 142 | 115 |
| Screw speed | rpm | 100 | |||
| Clamping Unit | |||||
| Clamping force | KN | 5600 | |||
| Open stroke | mm | 850(860) | |||
| Space between tie-bars(W*H) | mm | 830*830 | |||
| Max mould height | mm | 850 | |||
| Min mould height | mm | 330 | |||
| Ejector stroke | mm | 240 | |||
| Ejector force | KN | 150 | |||
| Others | |||||
| Max pump pressure | MPA | 16 | |||
| Pump Motor power | KW | 58 | |||
| Heating power | KW | 31.4 | |||
| Numbers of heating area | Segment | 5+1 | |||
| Machine dimension(L*W*H) | M | 8.45*2.15*2.84 | |||
| Oil tank cubage | L | 795 | |||
| Machine weight | TON | 21 | |||
| Name | Brand |
| Computer | KEBA(AUSTRIA) or EST |
| Servo Drive | INOVANCE(CHINA) |
| Servo Pump | SUNNY(USA) / SUMITOMO(JAPAN) |
| Servo Motor | PHASE(ITALY) |
| Electro-hydraulic Proportion valve | HNC (Taiwan) |
| Stroke transducer | NOVO or Miran(GERMANY)/GERFRAN(ITALY) |
| Breaker | Schneider (FRANCEN)/Siemens(GERMANY) |
| Contacts | Schneider (FRANCEN)/Siemens(GERMANY) |
| Switch | Schneider (FRANCEN)/Siemens(GERMANY) |
| Hydraulic Direction Valve | Vickers (USA) or Rexroth (GERMANY) |
| Plasticing Motor | DINAMIC(ITALY) or STF(ENGLAND) |
| Hydraulic Hose | MANULI(ITALY)/CONTINENTAI(GERMANY) |
| Plasticing speed sensor | OMRON |
| Sealing ring | HALITE or TREIIEBORG(UK or GERMANY) |
