Steel Wire Braided 5000 Psi High Pressure Washer Hose

Product Description

Steel wire braided 5000 psi high pressure washer hose
Specification

Washing hose I
MAIN APPLICATION:		For medium pressure cleaning applications with hot water
TEMPERATURE RANGE:		-40°F / +248°F, -40°C / +120°C Intermittent 150°C for pressure washer only
INNER TUBE:		Synthetic rubber
REINFORCEMENT:		One high tensile steel braid
COVER:		Synthetic rubber with high abrasion, ozone and weather resistance (rubber color and surface finish can be customized as per customer's request, pls refer to page 10)
Optional Features:		1. Extreme Abrasion resistant
		2. High tempreture( up to 200°C)
		3. Low tempreture( down to -50°C)
		4. Anti-static(FRAS)
		5. Color customized
		6. Surface customized(clothed or smooth)
I.D			R.O.D.		O.D		MAX W.P.		MIN B.P.		MIN B.R.	WEIGHT
dash	DN	inch	mm	inch	mm	inch	bar	psi	bar	psi	mm	kg/m
-4	6	1/4"	11.2	0.44	13.2	0.52	250	3625	1000	14500	100	0.23
-5	8	5/16"	12.8	0.50	14.8	0.58	250	3625	1000	14500	115	0.27
-6	10	3/8"	15.1	0.59	17.1	0.67	250	3625	1000	14500	130	0.34
-8	12	1/2"	18.1	0.71	20.1	0.79	250	3625	1000	14500	180	0.42
MORE FLEXIBLE APPLICATION
-4	6	1/4"	10.2	0.40	12.0	0.47	250	3625	1000	14500	75	0.18
-5	8	5/16"	11.5	0.45	13.6	0.54	250	3625	1000	14500	85	0.21
-6	10	3/8"	13.6	0.54	15.5	0.61	250	3625	1000	14500	90	0.26
-8	12	1/2"	17.3	0.68	19.1	0.75	250	3625	1000	14500	130	0.34
Washing hose II
MAIN APPLICATION:		For high pressure cleaning applications with hot water
TEMPERATURE RANGE:		-40°F / +248°F -40°C / +120°C Intermittent 150°C for pressure washer only
INNER TUBE:		Synthetic rubber
REINFORCEMENT:		Two high tensile steel braid
COVER:		Synthetic rubber with high abrasion, ozone and weather resistance
Optional Features:		1. Extreme Abrasion resistant
		2. High tempreture( up to 200°C)
		3. Low tempreture( down to -50°C)
		4. Anti-static(FRAS)
		5. Color customized
		6. Surface customized(clothed or smooth)
dash	DN	inch	mm	inch	mm	inch	bar	psi	bar	psi	mm	kg/m
-4	6	1/4"	12.7	0.50	14.7	0.58	400	5800	1600	23200	100	0.34
-5	8	5/16"	14.3	0.56	16.3	0.64	400	5800	1600	23200	115	0.39
-6	10	3/8"	16.7	0.66	18.7	0.74	400	5800	1600	23200	127	0.49
-8	12	1/2"	19.8	0.78	21.8	0.86	400	5800	1600	23200	180	0.59
MORE FLEXIBLE APPLICATION
-4	6	1/4"	11.3	0.44	13.1	0.52	400	5800	1600	23200	75	0.28
-5	8	5/16"	12.9	0.51	14.7	0.58	400	5800	1600	23200	85	0.33
-6	10	3/8"	15.0	0.59	16.8	0.66	400	5800	1600	23200	90	0.39
-8	12	1/2"	18.5	0.73	20.3	0.80	400	5800	1600	23200	130	0.5
Washing hose IV
MAIN APPLICATION:		Very high pressure hose for water scaling and jetting system
TEMPERATURE RANGE:		-40°F / +212°F -40°C / +100°C
INNER TUBE:		Synthetic rubber
REINFORCEMENT:		Four high tensile steel spiral
COVER:		Synthetic rubber with high abrasion, ozone and weather resistance
Optional Features:		1. Extreme Abrasion resistant
		2. High tempreture( up to 200°C)
		3. Low tempreture( down to -50°C)
		4. Anti-static(FRAS)
		5. Color customized
		6. Surface customized(clothed or smooth)
I.D			R.O.D.		O.D		MAX W.P.		MIN B.P.		MIN B.R.	WEIGHT
dash	DN	inch	mm	inch	mm	inch	bar	psi	bar	psi	mm	kg/m
-4	6	1/4"	14.7	0.58	17.6	0.69	1000	14500	2500	36250	125	0.60
-6	10	3/8"	17.6	0.69	21.1	0.83	850	12325	2125	30813	180	0.78
-8	12	1/2"	20.3	0.80	24.3	0.96	800	11600	2000	29000	230	0.89
-12	19	3/4"	28.2	1.11	31.9	1.26	720	10440	1800	26100	300	1.59
-16	25	1"	35.0	1.38	39.0	1.54	700	10150	1700	24650	340	2.02

Product Show
Our company Hebei Hengyu Rubber Product Group Co., Ltd, founded in 1999, is a manufacturer dedicated to the design, production, and distribution of all types of flexible hoses, fittings, adapters, quick couplings and assembly machines with excellent quality standard.
After 20 years of development, today the plants of Hengyu Group has expended to occupy an area of 260,000 square meters, owns over 300 well-trained staffs and over 10 million meters production capacity per year, in order to meet high demand of both local and oversea market. Until now, Hengyu Group has been awarded as 'The well-known trademark enterprises" and "The best top 10 enterprises" in China.
Our product range 1. HOSE SAE 100 R1AT, R2AT, R4, R5, R6, R7, R8, R12, R13, R14,R15, R16,R17, R19
2. HOSE DIN EN 853 1SN, 2SN,2ST; EN 856 4SP, 4SH; EN 857 1SC, 2SC
3. PTFE hose
4. Thermoplastic hose
5. Jack hose
7. Pilot line hose
8. Washer pressure hose, sewer hose, water blast hose
9. Rotary Drilling and Vibrator Hoses, Cement Hoses, and Mud Delivery Hoses
10. Air/Water/Oil Suction & Discharge Rubber Hose
11 . Air conditioning hose
12. Steam hose
13. Chemical hose, Food hose
14. Welding hose, LPG hose
15. Tank Truck hose
16. Sandblast Hose, Concrete pump hose
17. Fiber glass fire sleeve (Pyrojacket), Plastic Spiral Guard for Hose
18. Ferrules, fittings and adapters, with materials of carbon steel and stainless steel
19. Quick couplings with materials of carbon steel, stainless steel and copper
20. Crimping machine,Skiving machine, Cutting machine

FAQ Q1. Are your company a manufacturer or trading company?
A: Our company is a manufacturing company.
Q2. Can your products be customized?
A: Sure, we can provide the customized design and customized production for metal connectors, hose assembly and steel pipe assembly as your requirements.
Q3. Do you produce smooth or cloth wrapped cover?
A: Yes,we can produce both cover.
Q4. Can you produce products with my own brand?
A: Yes,we can offer OEM services.
Q5. Can I get free samples?
A: yes, send your address,your telephone number,post code,and express account number to us,and told us which samples you need and samples specification.
Q6. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.
Q7.What is your port of loading?
A: Xingang port or Qingdao port
Q8. What is your terms of packing?
A: Generally, we pack our goods in fiber cloth or woven bag. If you have legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters.
Q9. How about your delivery time?
A: It usually takes 15 to 30 days,which generally depends on the quantity of your order and our storage.

---
