Specification
| Model
|
XYL-146YA
| XYL-146YAT
|
Viewing head
| Compensation Free Binocular
Head .Inclined at 30 °
| standard outfit
| |
Compensation Free Trinocular
Head .Inclined at 30 °
| | standard outfit
|
Eyepiece
| | | |
WF10X/ 22mm
| standard outfit
| standard outfit
|
Objective
| | | |
Infinity Plan Objective: 4X,10X,40X(S),100X
(S) 0il
| standard outfit
| standard outfit
|
20X,60X(S) objective
| optional parts
| optional parts
|
Stage
| Double layers mechanical stage
| standard outfit
| standard outfit
|
Stage size: 180mmX 150mm
|
Moving range : 75mmX 50mm
|
Fluoroscope box
| B ,G Wave band
| standard outfit
| standard outfit
|
U,V Wave band
| optional parts
| optional parts
|
Focusing
| Coaxial coarse & fine focusing adjustment with
rack and pinion mechanism Fine focusing scale
Value 0.002mm
| standard outfit
| standard outfit
|
Condenser
| N. A.1.25 Abbe condenser with iris
diaphragm&filter
| standard outfit
| standard outfit
|
Optional Accessory
| 1.3 or 3.0 Mega pixels CMOS electronic eyepiece
|
Photography attachment
|
PInfinite Apochromatic Fluorescent Objectives: 4X,10X,20X,40X,100X
|
|
