| Part Number | 2882111 |
| Previous Version | 2882004NX, 288211100, 2882111NX, 2882111RX, 2841220, 2841221, 2841222, 3768194, 3773569, 3792586, 2882111, 2881807, 2882004, 2840007, 3773562, 3773561, 2882110, 3792586H, 2882110NX, 3792586HX, 288211100HX |
| Year | 2005-10 |
| OE Number | 8773568, 3783568, 2843893, 3792584, 3773566, 3768191, 2882110NX |
| Description | Various Trucks |
| Manufacturer Part Number | 2843481 |
| Turbo Model | HE451VE, HE400VG |
| Engine | ISX CM570, ISX CM870, ISX CM871, ISX CM871 E, ISX15 CM2250, ISX15 CM2250 SN, ISX15 CM2350 X101, ISX15 CM2350 X114, ISZ13 CM2150 SN, QSX11.9 CM2250 ECF, QSX15 CM2250, QSX15 CM2250 ECF, QSX15 CM2350 X105, QSX15 CM2350 X106, QSX15 CM570, QSZ13 CM2150 Z101, QSZ13 CM2150 Z102 |
| Displacement | 15.0L, 1500 ccm |
| Fuel | Diesel |
| Engine Manufacturer | |
| Angle α (compressor housing) | 275° |
| Angle β (turbine housing) | 155° |
| Turbine Wheel | 2840238RX (Ind. 66.35 mm, Exd. 71.28 mm, 11 Blades) NEW IN STOCK |
| Comp. Wheel | (Ind. 61.95 mm, Exd. 92.96 mm, 7+7 Blades, Superback) NEW IN STOCK |
| Turbine Housing AR | VGT |
| Speed Sensor Kit | 4034201H |
