BS-1 5 gallon barrel decaper bottle washing machine

Product Description

Product Description
BS-1 5 gallon barrel decaper bottle washing machine
Product Description
Functions and features:
Worker put used cover in right side of de-capper position, with the neck inserting into the hole, worker foot press pedal to release cap off neck; And then worker need to take the jar to insert into left side of the machine-washing position. After the jar putting in, the window need to be closed. Then the washer will be started by itself. During washing, the inner brush inside jar and Washing time is pre-settled, the machine will stop when time finish. Heating function could be switched on/ off as client's needing.
Semi automatic cap pulling out and inside brusher washing machine
Note: This machine operated by manual and is suitable for pulling out cap and cleaning inside and outside of 5 gallon bottle.
Details

	Semi automatic 5 gallon decapper and washing machine (associated equipment for this filling line) 1.The empty barrel inverted and insertion pulling out cap stations, foot air valve plate, pulling cap head will pull off the lid into the pipeline. 2.Open the brush barrel cover, insert empty barrel pulled out cap into washing barrel station, close machine cover and automatically open water pumps and hair brush.
Washing Process 1.In order to achieve the purpose of washing and sterilizing, bottle washer adopts multiple liquid injections washing and disinfectant spray, and washing solution can be used circularly. 2.There are five or seven flushing process: First, second steps are disinfectant, the third step: drip dry, four step: recycling water inside and outside rinsing, five step: pure water and drip dry.
	Filling and capping machine This filling machine working with automatic cap holding and cap hopper, use gravity filling type. full bottle filling process. One head capping machine
Automatic barrel loader: The empty barrel cleaned by inside and outside brushing machine sending through automatic loading system by transmission chain, loading barrel counter counting 1pcs barrel, blocking barrel cylinder action to stop feeding barrel, loading and pushing barrel action, and pushing barrel to barrel inverting frame reset.
	Light checker and steam heating shrink machine: Inspection light is used for lighting when inspect whether exist sundries in barrel. Heat shrinking machine is consist of water vessel and electric heat up, electric heat up to produce steam.
Bottle conveyor system Including: Automatic empty bottle feeding in system, plastic chain material with driven motor. Full barrel conveyor system with SUS34 material chain
	Roller conveyor system Material: SUS304 Length:1.5m

Company information
Workshop detail
Our team
Our exhibition
FAQ
Q1: How to find suitable machine or complete beverage production line?
A1: Looking for beverage filling machine in www.grandeemachine.en.china.cn
•Enquiry: Contact us by email, phone call, fax, Instant Messenger (Trade manager, Skype, WhatsApp, Wechat) and let us know your requirements
• Discussion: Specify the items and what are you exactly looking for.
Q2: Are you a trading company or a manufactory?
A2: We are the manufacture of water/beverage filling machine and water treatment system over 10 years.We just not only sell drinking water machines and other related equipment , Quality is our culture. We have rich experienced engineers with technicians working team , providing good and after-sales service term , professional salesman terms .
Q3: Do you have technical support after we purchased your machines?
A3: We will arrange our professional technical to go aboard to your factory, they will help you and teach you how to install and maintenance the machines which you purchased. Or help you to fix machine when it has problems.
Q4: If you buy our machines, can you offer us wear-out spare pats?
A4: We provide our high quality machine 2 years guarantee , and we will also offer you 2 years wear-out spare parts for free. Once your machines broken or doesn't work within 2 years and you can't solve it, firstly, we will try to help you to find problems from your words description by phone or other communication tolls. Secondly, if the phone solutions still not work, our engineers will go to your factory to solve it. Meanwhile, they will teach you the related experiences for fixing.
