US$266.72-7,722.31
|
1 Piece
(MOQ)
|
Basic Info.
Output Power
Base on Model
Connection Mode
Parallel Switching Power Supply
Starting Mode
Base on Model
Voltage Regulating Mode
Base on Model
Power Supplying System
Base on Model
Energy Transmission
Base on Model
Modulation System
Base on Model
Certification
CE, RoHS, ISO, CCC
Transport Package
Package or Wooden Carton
Product Description
Product Description
We specialize in customizing DC power supply to meet your specific requirements.
With customized input and output voltage and current, our offerings range from 0V to 2000KV DC and 0A to 2000A.
We provide AC-DC solutions for the motor category or electrical appliances testing or Lab testing, electrochemistry, electrolysis, electroplating, and anodizing.
Please visit our website and submit any inquiries to explore our capabilities further. Our dedicated team endeavors to respond within one hour.
Thank you for considering our services.
I. APPLICATION SCOPE
| 1 | Motor: electric car motor, controller, DC motor testing and aging debugging, etc. |
| 2 | Electric appliances: LED/LCD testing and aging, energy-saving bulb testing and aging, lamp testing, tungsten gasification, etc. |
| 3 | Automotive: starter motor, auto air conditioner, auto motor controller, auto light, cigarette lighter, auto AV testing and aging, etc. |
| 4 | Electronic devices: capacitors, resistors, relays, transistors, sensors, etc. |
| 5 | Display: display screen, liquid screen, touch screen, car DVD, cell phone display, etc. |
| 6 | Electrochemistry: electrolysis, electroplating, anodic oxidation, non-ferrous metals, sewage treatment, etc. |
| 7 | Aircraft start-up maintenance, power supply for many equipment, etc. |
| 8 | Physical exploration: power supply of mineral and petroleum equipment, etc. |
| 9 | Power supply: inverter products aging, inverter maintenance testing, etc. |
| 10 | Power tools: contact aging, wire pack testing, circuit breaker release test, etc. |
| 11 | Others |
II. PRODUCT FEATURES
| 1 | Small size and light weight suitable for workbench use and rack mounting. |
| 2 | Adopting PWM modulation, low power consumption of crystal module, high efficiency, more power saving. |
| 3 | Well-designed electronic technology circuit, forced air-cooled heat dissipation treatment, with a very low-temperature coefficient. |
| 4 | Low noise, low ripple. |
| 5 | Adopt high gain amplifier circuit design, with good fast response characteristics. |
| 6 | Adopt a 4-digit high sampling rate, high-resolution voltage, and current digital display meter. |
| 7 | Built-in O.V.P. over-voltage protection circuit and O.T.P. over-temperature protection circuit, the protection function is perfect and reliable. |
| 8 | The product is designed with a load terminal voltage detection terminal, with the ability to accurately read the load terminal voltage and accurate control function. |
III. PERFORMANCE FEATURES
| 1 | Display: Output Voltage And Current Led Display. |
| 2 | Appearance: Using a Desktop, Cabinet, Or 19-Inch Standardized Size, Can Be Combined And Placed In a Variety Of Workbenches And Racks. |
| 3 | Advantages: High-Frequency Pwm Hardware-Adjusted Soft-Switching Control Technology Makes The Power Supply High Efficiency, Low Ripple, Low Noise, And High Reliability, Small Size, And Light Weight. |
| 4 | Constant Voltage And Constant Current: Output Cc, Cv Constant Voltage And Constant Current Automatic Switching, Voltage, And Power Flow Value From Zero To The Rated Value Of Continuous Adjustment |
| 4 | Protection Functions: Over-Voltage Protection (Ovp, Over-Current Protection (Ocp, Over-Temperature Protection (Otp.)) |
| | External Compensation: Optional External Compensation (Remote Sensing, Reducing The Circuit Cable Voltage Drop. |
| 5 | Current Presetting Function: The User Can Preset Any Voltage Actually Needed By The Load Without Connecting The Load, And When The Product Actually Has Current Output, The Actual Maximum Output Current Can Reach The Pre-Set Value (Optional). |
| 6 | Voltage Presetting Function: The User Can Preset Any Voltage Actually Needed By The Load Without Connecting The Load, And When The Product Actually Has a Voltage Output, The Actual Maximum Output Current Can Reach The Pre-Set Value (Optional). |
| 7 | Computer Program Control Function: Optional Rs485/Rs232 And Other Data Interfaces, Standard Modbus Communication Protocol, Can Be Configured With Computer/Upper Computer Software Control Monitoring. Can Be Multiple Network Control, Or Master-Slave Parallel Control. (Optional) |
| 8 | Positive And Negative Commutation Function: Can Provide Output Positive And Negative Commutation Function (Bipolar), Commutation Mode: Manual, Timing, Calculator Program Control, Etc. (Optional) |
IV. ABOUT THE PACKAGING.
The use of professional instrument wooden box packaging can reliably protect the power supply. Tight packaging, reduces the logistics process of cargo damage, and cargo difference, to ensure the safety of the goods.
V. TECHNICAL PARAMETRIC
| Brand | IDEALPLUSING |
| Model | YBY-ATDH122000 |
| AC Input | Single phase 110VAC±15% 50/60hz (Customized-Contact sales for quote) |
| Single phase 220VAC±15% 50/60hz (Less than 7000W) |
| Three phase 380VAC±15% 50/60hz (More than 7000W) |
| Input frequency | 50Hz/60Hz |
| Output voltage | 0~12VDC |
| Output current | 0-2000A |
| Output Power | 24000W |
| Voltage Stabilization | ≤0.3%+10mV |
| Load Stabilization | ≤0.5%+30mV |
| Ripples and Noises | ≤0.5%+10mVrms |
| Voltage Display Accuracy | 4-digit Accuracy: ±1%+1 word (10%-100% rating) |
| Display Format | 0.000V-9.999V; 0.00V-99.99V; 0.0V-999.9V |
| Current Display Accuracy | 4-digit Accuracy: ±1%+1 word (10%-100% rating) |
| Remote Adjustment | (Analog control: Voltage adjustable ):0-5VDC;(Current adjustable):0-5VDC |
| Remote Display | (Analog control: Voltage adjustable ): 0-5VDC;(Current adjustable):0-5VDC |
| Output Over Voltage Protection | Built-in O.V.P. protection, protection limited value is rated +5% |
| Output Over Load Protection | Overload, current limit, constant current output |
| Over Temperature Protection | Built-in O.T.P. protection, Protection value 85ºC±5% heat sink temperature |
| Voltage Setting | 10-turn precision potentiometer |
| Current Setting | 10-turn precision potentiometer |
| Output Polarity | Output Positive(+) negative(- ) Can be grounded at will |
| Heat Dissipation Way | Forced fan cooling |
| Work Conditions | Indoor use design,Temperature:0ºC~40ºC;Humidity:10%~85%RH |
| Storage Conditions | Temperature:-20ºC~70ºC;Humidity:10%~90%RH |
| Machine Dimension | Base on models |
| Package Dimension | Base on models |
| Net/Gross Weight | Base on models |
Detailed Photos Model List for aging test
| Model | Input voltage | Output voltage(VDC) | Output Current(AMPS) | Output Power
(W) |
| IPS-ATDH5010 | 220VAC | 50V | 10A | 500W |
| IPS-ATDH10010 | 220VAC | 100V | 10A | 1000W |
| IPS-ATDH5200 | 220VAC | 5V | 200A | 1000W |
| IPS-ATDH2050 | 220VAC | 20V | 50A | 1000W |
| IPS-ATDH2450 | 380VAC | 24V | 50A | 1200W |
| IPS-ATDH12100 | 380VAC | 12V | 100A | 1200W |
| IPS-ATDH2550 | 380VAC | 25V | 50A | 1250W |
| IPS-ATDH3050 | 380VAC | 30V | 50A | 1500W |
| IPS-ATDH15010 | 380VAC | 150V | 10A | 1500W |
| IPS-ATDH15100 | 380VAC | 15V | 100A | 1500W |
| IPS-ATDH3650 | 380VAC | 36V | 50A | 1800W |
| IPS-ATDH3006.6 | 380VAC | 300V | 6.6A | 2000W |
| IPS-ATDH20010 | 380VAC | 200V | 10A | 2000W |
| IPS-ATDH10020 | 380VAC | 100V | 20A | 2000W |
| IPS-ATDH20100 | 380VAC | 20V | 100A | 2000W |
| IPS-ATDH22010 | 380VAC | 220V | 10A | 2200W |
| IPS-ATDH24100 | 380VAC | 24V | 100A | 2400W |
| IPS-ATDH25010 | 380VAC | 250V | 10A | 2500W |
| IPS-ATDH25100 | 380VAC | 25V | 100A | 2500W |
| IPS-ATDH5005 | 380VAC | 500V | 5A | 2500W |
| IPS-ATDH10030 | 380VAC | 100V | 30A | 3000W |
| IPS-ATDH15200 | 380VAC | 15V | 200A | 3000W |
| IPS-ATDH30100 | 380VAC | 30V | 100A | 3000W |
| IPS-ATDH30010 | 380VAC | 300V | 10A | 3000W |
| IPS-ATDH6500 | 380VAC | 6V | 500A | 3000W |
| IPS-ATDH6050 | 380VAC | 60V | 50A | 3000W |
| IPS-ATDH36100 | 380VAC | 36V | 100A | 3600W |
| IPS-ATDH24150 | 380VAC | 24V | 150A | 3600W |
| IPS-ATDH20200 | 380VAC | 20V | 200A | 4000W |
| IPS-ATDH8500 | 380VAC | 8V | 500A | 4000W |
| IPS-ATDH8050 | 380VAC | 80V | 50A | 4000W |
| IPS-ATDH40010 | 380VAC | 400V | 10A | 4000W |
| IPS-ATDH24200 | 380VAC | 24V | 200A | 4800W |
| IPS-ATDH48100 | 380VAC | 48V | 100A | 4800W |
| IPS-ATDH51000 | 380VAC | 5V | 1000A | 5000W |
| IPS-ATDH50010 | 380VAC | 500V | 10A | 5000W |
| IPS-ATDH25020 | 380VAC | 250V | 20A | 5000W |
| IPS-ATDH10050 | 380VAC | 100V | 50A | 5000W |
| IPS-ATDH10005 | 380VAC | 1000V | 5A | 5000W |
| IPS-ATDH10500 | 380VAC | 10V | 500A | 5000W |
| IPS-ATDH50100 | 380VAC | 50V | 100A | 5000W |
| IPS-ATDH30200 | 380VAC | 30V | 200A | 6000W |
| IPS-ATDH20300 | 380VAC | 20V | 300A | 6000W |
| IPS-ATDH30020 | 380VAC | 300V | 20A | 6000W |
| IPS-ATDH60100 | 380VAC | 60V | 100A | 6000W |
| IPS-ATDH40015 | 380VAC | 400V | 15A | 6000W |
| IPS-ATDH15400 | 380VAC | 15V | 400A | 6000W |
| IPS-ATDH32000 | 380VAC | 32V | 2000A | 6000W |
| IPS-ATDH61000 | 380VAC | 61V | 1000A | 6000W |
| IPS-ATDH32200 | 380VAC | 32V | 200A | 6400W |
| IPS-ATDH13050 | 380VAC | 130V | 50A | 6500W |
| IPS-ATDH45015 | 380VAC | 450V | 15A | 6750W |
| IPS-ATDH35020 | 380VAC | 350V | 20A | 7000W |
| IPS-ATDH36200 | 380VAC | 36V | 200A | 7200W |
| IPS-ATDH24300 | 380VAC | 24V | 300A | 7200W |
| IPS-ATDH15500 | 380VAC | 15V | 500A | 7500W |
| IPS-ATDH10008 | 380VAC | 1000V | 8A | 8000W |
| IPS-ATDH16500 | 380VAC | 16V | 500A | 8000W |
| IPS-ATDH20400 | 380VAC | 20V | 400A | 8000W |
| IPS-ATDH40020 | 380VAC | 400V | 20A | 8000W |
| IPS-ATDH81000 | 380VAC | 8V | 1000A | 8000W |
| IPS-ATDH32250 | 380VAC | 32V | 250A | 8000W |
| IPS-ATDH40200 | 380VAC | 40V | 200A | 8000W |
| IPS-ATDH15006 | 380VAC | 1500V | 6A | 9000W |
| IPS-ATDH18005 | 380VAC | 1800V | 5A | 9000W |
| IPS-ATDH18500 | 380VAC | 18V | 500A | 9000W |
| IPS-ATDH30300 | 380VAC | 30V | 300A | 9000W |
| IPS-ATDH48200 | 380VAC | 48V | 200A | 9600W |
| IPS-ATDH32300 | 380VAC | 32V | 300A | 9600W |
| IPS-ATDH100100 | 380VAC | 100V | 100A | 10000W |
| IPS-ATDH100010 | 380VAC | 1000V | 10A | 10000W |
| IPS-ATDH101000 | 380VAC | 10V | 1000A | 10000W |
| IPS-ATDH20500 | 380VAC | 20V | 500A | 10000W |
| IPS-ATDH50200 | 380VAC | 50V | 200A | 10000W |
| IPS-ATDH20005 | 380VAC | 2000V | 5A | 10000W |
| IPS-ATDH36300 | 380VAC | 36V | 300A | 10800W |
| IPS-ATDH60200 | 380VAC | 60V | 200A | 12000W |
| IPS-ATDH120010 | 380VAC | 1200V | 10A | 12000W |
| IPS-ATDH30400 | 380VAC | 30V | 400A | 12000W |
| IPS-ATDH24500 | 380VAC | 24V | 500A | 12000W |
| IPS-ATDH121000 | 380VAC | 12V | 1000A | 12000W |
| IPS-ATDH120100 | 380VAC | 120V | 100A | 12000W |
| IPS-ATDH25050 | 380VAC | 250V | 50A | 12500W |
| IPS-ATDH22060 | 380VAC | 220V | 60A | 13200W |
| IPS-ATDH36400 | 380VAC | 36V | 400A | 14400W |
| IPS-ATDH48300 | 380VAC | 48V | 300A | 14400W |
| IPS-ATDH151000 | 380VAC | 15V | 1000A | 15000W |
| IPS-ATDH25600 | 380VAC | 25V | 600A | 15000W |
| IPS-ATDH30500 | 380VAC | 30V | 500A | 15000W |
| IPS-ATDH100150 | 380VAC | 100V | 150A | 15000W |
| IPS-ATDH150100 | 380VAC | 150V | 100A | 15000W |
| IPS-ATDH25060 | 380VAC | 250V | 60A | 15000W |
| IPS-ATDH30050 | 380VAC | 300V | 50A | 15000W |
| IPS-ATDH50030 | 380VAC | 500V | 30A | 15000W |
| IPS-ATDH150010 | 380VAC | 1500V | 10A | 15000W |
| IPS-ATDH30005 | 380VAC | 3000V | 5A | 15000W |
| IPS-ATDH82000 | 380VAC | 8V | 2000A | 16000W |
| IPS-ATDH32500 | 380VAC | 32V | 500A | 16000W |
| IPS-ATDH80200 | 380VAC | 80V | 200A | 16000W |
| IPS-ATDH48350 | 380VAC | 48V | 350A | 16800W |
| IPS-ATDH35500 | 380VAC | 35V | 500A | 17500W |
| IPS-ATDH35050A | 380VAC | 350V | 50A | 17500W |
| IPS-ATDH63000 | 380VAC | 6V | 3000A | 18000W |
| IPS-ATDH30600 | 380VAC | 30V | 600A | 18000W |
| IPS-ATDH36500 | 380VAC | 36V | 500A | 18000W |
| IPS-ATDH60300 | 380VAC | 60V | 300A | 18000W |
| IPS-ATDH100180 | 380VAC | 100V | 180A | 18000W |
| IPS-ATDH120150 | 380VAC | 120V | 150A | 18000W |
| IPS-ATDH180100 | 380VAC | 180V | 100A | 18000W |
| IPS-ATDH30060 | 380VAC | 300V | 60A | 18000W |
| IPS-ATDH38500 | 380VAC | 38V | 500A | 19000W |
| IPS-ATDH24800 | 380VAC | 24V | 800A | 19200W |
| IPS-ATDH32600 | 380VAC | 32V | 600A | 19200W |
| IPS-ATDH48400 | 380VAC | 48V | 400A | 19200W |
| IPS-ATDH82500 | 380VAC | 8V | 2500A | 20000W |
| IPS-ATDH102000 | 380VAC | 10V | 2000A | 20000W |
| IPS-ATDH80250 | 380VAC | 80V | 250A | 20000W |
| IPS-ATDH100200 | 380VAC | 100V | 200A | 20000W |
| IPS-ATDH200100 | 380VAC | 200V | 100A | 20000W |
| IPS-ATDH40050 | 380VAC | 400V | 50A | 20000W |
| IPS-ATDH200010 | 380VAC | 2000V | 10A | 20000W |
| IPS-ATDH35600 | 380VAC | 35V | 600A | 21000W |
| IPS-ATDH36600 | 380VAC | 36V | 600A | 21600W |
| IPS-ATDH151500 | 380VAC | 15V | 1500A | 22500W |
| IPS-ATDH83000 | 380VAC | 8V | 3000A | 24000W |
| IPS-ATDH122000 | 380VAC | 12V | 2000A | 24000W |
| IPS-ATDH241000 | 380VAC | 24V | 1000A | 24000W |
| IPS-ATDH48500 | 380VAC | 48V | 500A | 24000W |
| IPS-ATDH60400 | 380VAC | 60V | 400A | 24000W |
| IPS-ATDH120200 | 380VAC | 120V | 200A | 24000W |
| IPS-ATDH120020 | 380VAC | 1200V | 20A | 24000W |
| IPS-ATDH251000 | 380VAC | 25V | 1000A | 25000W |
| IPS-ATDH50500 | 380VAC | 50V | 500A | 25000W |
| IPS-ATDH50050 | 380VAC | 500V | 50A | 25000W |
| IPS-ATDH250110 | 380VAC | 250V | 110A | 27500W |
| IPS-ATDH35800 | 380VAC | 35V | 800A | 28000W |
| IPS-ATDH35080 | 380VAC | 350V | 80A | 28000W |
| IPS-ATDH58050 | 380VAC | 580V | 50A | 29000W |
| IPS-ATDH103000 | 380VAC | 10V | 3000A | 30000W |
| IPS-ATDH152000 | 380VAC | 15V | 2000A | 30000W |
| IPS-ATDH251200 | 380VAC | 25V | 1200A | 30000W |
| IPS-ATDH301000 | 380VAC | 30V | 1000A | 30000W |
| IPS-ATDH50600 | 380VAC | 50V | 600A | 30000W |
| IPS-ATDH60500 | 380VAC | 60V | 500A | 30000W |
| IPS-ATDH100300 | 380VAC | 100V | 300A | 30000W |
| IPS-ATDH150200 | 380VAC | 150V | 200A | 30000W |
| IPS-ATDH200150 | 380VAC | 200V | 150A | 30000W |
| IPS-ATDH300100 | 380VAC | 300V | 100A | 30000W |
| IPS-ATDH50060 | 380VAC | 500V | 60A | 30000W |
| IPS-ATDH60050 | 380VAC | 600V | 50A | 30000W |
| IPS-ATDH100030 | 380VAC | 1000V | 30A | 30000W |
| IPS-ATDH300010 | 380VAC | 3000V | 10A | 30000W |
| IPS-ATDH321000 | 380VAC | 32V | 1000A | 32000W |
| IPS-ATDH400080 | 380VAC | 400V | 80A | 32000W |
| IPS-ATDH351000 | 380VAC | 35V | 1000A | 35000W |
| IPS-ATDH350100 | 380VAC | 350V | 100A | 35000W |
| IPS-ATDH241500 | 380VAC | 24V | 1500A | 36000W |
| IPS-ATDH361000 | 380VAC | 36V | 1000A | 36000W |
| IPS-ATDH60600 | 380VAC | 60V | 600A | 36000W |
| IPS-ATDH60060 | 380VAC | 600V | 60A | 36000W |
| IPS-ATDH152500 | 380VAC | 15V | 2500A | 37500W |
| IPS-ATDH251500 | 380VAC | 25V | 1500A | 37500W |
| IPS-ATDH150250 | 380VAC | 150V | 250A | 37500W |
| IPS-ATDH250150 | 380VAC | 250V | 150A | 37500W |
| IPS-ATDH381000 | 380VAC | 38V | 1000A | 38000W |
| IPS-ATDH180220 | 380VAC | 180V | 220A | 39600W |
| IPS-ATDH202000 | 380VAC | 20V | 2000A | 40000W |
| IPS-ATDH251600 | 380VAC | 25V | 1600A | 40000W |
| IPS-ATDH401000 | 380VAC | 40V | 1000A | 40000W |
| IPS-ATDH100400 | 380VAC | 100V | 400A | 40000W |
| IPS-ATDH200220 | 380VAC | 200V | 200A | 40000W |
| IPS-ATDH400100 | 380VAC | 400V | 100A | 40000W |
| IPS-ATDH80040 | 380VAC | 800V | 50A | 40000W |
| IPS-ATDH100040 | 380VAC | 1000V | 40A | 40000W |
| IPS-ATDH400010 | 380VAC | 4000V | 10A | 40000W |
| IPS-ATDH300150 | 380VAC | 300V | 150A | 45000W |
| IPS-ATDH301500 | 380VAC | 30V | 1500A | 45000W |
| IPS-ATDH242000 | 380VAC | 24V | 2000A | 48000W |
| IPS-ATDH60080 | 380VAC | 600V | 80A | 48000W |
| IPS-ATDH105000 | 380VAC | 10V | 5000A | 50000W |
| IPS-ATDH252000 | 380VAC | 25V | 2000A | 50000W |
| IPS-ATDH501000 | 380VAC | 50V | 1000A | 50000W |
| IPS-ATDH100500 | 380VAC | 100V | 500A | 50000W |
| IPS-ATDH500100 | 380VAC | 500V | 100A | 50000W |
| IPS-ATDH100050 | 380VAC | 1000V | 50A | 50000W |
| IPS-ATDH500010 | 380VAC | 5000V | 10A | 50000W |
| IPS-ATDH361500 | 380VAC | 36V | 1500A | 54000W |
| IPS-ATDH551000 | 380VAC | 55V | 1000A | 55000W |
| IPS-ATDH282000 | 380VAC | 28V | 2000A | 56000W |
| IPS-ATDH351600 | 380VAC | 35V | 1600A | 56000W |
| IPS-ATDH350160 | 380VAC | 350V | 160A | 56000W |
| IPS-ATDH381500 | 380VAC | 38V | 1500A | 57000W |
| IPS-ATDH203000 | 380VAC | 20V | 3000A | 60000W |
| IPS-ATDH100600 | 380VAC | 100V | 600A | 60000W |
| IPS-ATDH120500 | 380VAC | 120V | 500A | 60000W |
| IPS-ATDH200300 | 380VAC | 200V | 300A | 60000W |
| IPS-ATDH300200 | 380VAC | 300V | 200A | 60000W |
| IPS-ATDH500120 | 380VAC | 500V | 120A | 60000W |
| IPS-ATDH100060 | 380VAC | 1000V | 60A | 60000W |
| IPS-ATDH125500 | 380VAC | 125V | 500A | 62500W |
| IPS-ATDH85080 | 380VAC | 850V | 80A | 68000W |
| IPS-ATDH362000 | 380VAC | 36V | 2000A | 72000W |
| IPS-ATDH600120 | 380VAC | 600V | 120A | 72000W |
| IPS-ATDH501500 | 380VAC | 50V | 1500A | 75000W |
| IPS-ATDH150500 | 380VAC | 150V | 500A | 75000W |
| IPS-ATDH250300 | 380VAC | 250V | 300A | 75000W |
| IPS-ATDH500150 | 380VAC | 500V | 150A | 75000W |
| IPS-ATDH150050 | 380VAC | 1500V | 50A | 75000W |
| IPS-ATDH600133 | 380VAC | 600V | 133A | 79200W |
| IPS-ATDH360220 | 380VAC | 360V | 220A | 79800W |
| IPS-ATDH801000 | 380VAC | 80V | 1000A | 80000W |
| IPS-ATDH200400 | 380VAC | 200V | 400A | 80000W |
| IPS-ATDH800100 | 380VAC | 800V | 100A | 80000W |
| IPS-ATDH300300 | 380VAC | 300V | 300A | 90000W |
| IPS-ATDH1010000 | 380VAC | 10V | 10000A | 100000W |
| IPS-ATDH205000 | 380VAC | 20V | 5000A | 100000W |
| IPS-ATDH50200 | 380VAC | 50V | 200A | 100000W |
| IPS-ATDH1001000 | 380VAC | 100V | 1000A | 100000W |
| IPS-ATDH200500 | 380VAC | 200V | 500A | 100000W |
| IPS-ATDH250400 | 380VAC | 250V | 400A | 100000W |
| IPS-ATDH500200 | 380VAC | 500V | 200A | 100000W |
| IPS-ATDH1000100 | 380VAC | 1000V | 100A | 100000W |
| IPS-ATDH330400 | 380VAC | 330V | 400A | 120000W |
| IPS-ATDH150080 | 380VAC | 1500V | 80A | 120000W |
| IPS-ATDH502500 | 380VAC | 50V | 2500A | 125000W |
| IPS-ATDH650230 | 380VAC | 650V | 230A | 149500W |
| IPS-ATDH300500 | 380VAC | 300V | 500A | 150000W |
| IPS-ATDH1000150 | 380VAC | 1000V | 150A | 150000W |
| IPS-ATDH1500100 | 380VAC | 1500V | 100A | 150000W |
| IPS-ATDH800200 | 380VAC | 800V | 200A | 160000W |
| IPS-ATDH300600 | 380VAC | 300V | 600A | 180000W |
| IPS-ATDH2010000 | 380VAC | 20V | 10000A | 200000W |
| IPS-ATDH800250 | 380VAC | 800V | 250A | 200000W |
| IPS-ATDH1000200 | 380VAC | 1000V | 200A | 200000W |
| IPS-ATDH1102000 | 380VAC | 110V | 2000A | 220000W |
| IPS-ATDH660500 | 380VAC | 660V | 500A | 330000W |
| IPS-ATDH2025000 | 380VAC | 20V | 25000A | 500000W |
| IPS-ATDH1000500 | 380VAC | 1000V | 500A | 500000W |
Model list for water treatment
| Model | Input voltage | Output voltage(VDC) | Output Current(AMPS) | Output Power
(W) |
| IPS-ATDH1250 | 380VAC | 12V | 50A | 600W |
| IPS-ATDH12100 | 380VAC | 12V | 100A | 1200W |
| IPS-ATDH2450 | 380VAC | 24V | 50A | 1200W |
| IPS-ATDH15100 | 380VAC | 15V | 100A | 1500w |
| IPS-ATDH12200 | 380VAC | 12V | 200A | 2400W |
| IPS-ATDH24100 | 380VAC | 24V | 100A | 2400W |
| IPS-ATDH25100 | 380VAC | 25V | 100A | 2500W |
| IPS-ATDH1530 | 380VAC | 15V | 30A | 3000W |
| IPS-ATDH30100 | 380VAC | 30V | 100A | 3000W |
| IPS-ATDH6050 | 380VAC | 60V | 50A | 3000W |
| IPS-ATDH12300 | 380VAC | 12V | 300A | 3600W |
| IPS-ATDH36100 | 380VAC | 36V | 100A | 3600W |
| IPS-ATDH20200 | 380VAC | 20V | 200A | 4000W |
| IPS-ATDH15300 | 380VAC | 15V | 300A | 4500W |
| IPS-ATDH12400 | 380VAC | 12V | 400A | 4800W |
| IPS-ATDH24200 | 380VAC | 24V | 200A | 4800W |
| IPS-ATDH48100 | 380VAC | 48V | 100A | 4800W |
| IPS-ATDH10500 | 380VAC | 10V | 500A | 5000W |
| IPS-ATDH25200 | 380VAC | 25V | 200A | 5000W |
| IPS-ATDH32170 | 380VAC | 32V | 170A | 5440W |
| IPS-ATDH12500 | 380VAC | 12V | 500A | 6000W |
| IPS-ATDH15400 | 380VAC | 15V | 400A | 6000W |
| IPS-ATDH20300 | 380VAC | 20V | 300A | 6000W |
| IPS-ATDH30200 | 380VAC | 30V | 200A | 6000W |
| IPS-ATDH60100 | 380VAC | 60V | 100A | 6000W |
| IPS-ATDH35200 | 380VAC | 35V | 200A | 7000W |
| IPS-ATDH24300 | 380VAC | 24V | 300A | 7200W |
| IPS-ATDH48150 | 380VAC | 48V | 150A | 7200W |
| IPS-ATDH15500 | 380VAC | 15V | 500A | 7500W |
| IPS-ATDH25300 | 380VAC | 25V | 300A | 7500W |
| IPS-ATDH20400 | 380VAC | 20V | 400A | 8000W |
| IPS-ATDH15600 | 380VAC | 15V | 600A | 9000W |
| IPS-ATDH30300 | 380VAC | 30V | 300A | 9000W |
| IPS-ATDH24400 | 380VAC | 24V | 400A | 9600w |
| IPS-ATDH32300 | 380VAC | 32V | 300A | 9600w |
| IPS-ATDH48200 | 380VAC | 48V | 200A | 9600w |
| IPS-ATDH101000 | 380VAC | 10V | 1000A | 10000W |
| IPS-ATDH20500 | 380VAC | 20V | 500A | 10000W |
| IPS-ATDH50200 | 380VAC | 50V | 200A | 10000W |
| IPS-ATDH100100 | 380VAC | 100V | 100A | 10000W |
| IPS-ATDH35300 | 380VAC | 35V | 300A | 10500W |
| IPS-ATDH15800 | 380VAC | 15V | 800A | 12000W |
| IPS-ATDH24500 | 380VAC | 24V | 500A | 12000W |
| IPS-ATDH60020 | 380VAC | 600V | 20A | 12000W |
| IPS-ATDH25500 | 380VAC | 25V | 500A | 12500W |
| IPS-ATDH121200 | 380VAC | 12V | 1200A | 14400W |
| IPS-ATDH151000 | 380VAC | 15V | 1000A | 15000W |
| IPS-ATDH30500 | 380VAC | 30V | 500A | 15000W |
| IPS-ATDH82000 | 380VAC | 8V | 2000A | 16000W |
| IPS-ATDH20800 | 380VAC | 20V | 800A | 16000W |
| IPS-ATDH36500 | 380VAC | 36V | 500A | 1800W |
| IPS-ATDH201000 | 380VAC | 20V | 1000A | 2000W |
| IPS-ATDH200100 | 380VAC | 200V | 100A | 2000W |
| IPS-ATDH70030 | 380VAC | 700V | 30A | 21000W |
| IPS-ATDH36600 | 380VAC | 36V | 600A | 21600W |
| IPS-ATDH241000 | 380VAC | 24V | 1000A | 24000W |
| IPS-ATDH251000 | 380VAC | 25V | 1000A | 25000W |
| IPS-ATDH50500 | 380VAC | 50V | 500A | 25000W |
| IPS-ATDH36800 | 380VAC | 36V | 800A | 28800W |
| IPS-ATDH152000 | 380VAC | 15V | 2000A | 30000W |
| IPS-ATDH301000 | 380VAC | 30V | 1000A | 30000W |
| IPS-ATDH8500 | 380VAC | 8V | 500A | 32000W |
| IPS-ATDH704000 | 380VAC | 70V | 4000A | 35000W |
| IPS-ATDH241500 | 380VAC | 24V | 1500A | 36000W |
| IPS-ATDH361000 | 380VAC | 36V | 1000A | 36000W |
| IPS-ATDH301200 | 380VAC | 30V | 1200A | 36000W |
| IPS-ATDH251500 | 380VAC | 25V | 1500A | 37500W |
| IPS-ATDH85000 | 380VAC | 8V | 5000A | 40000W |
| IPS-ATDH153000 | 380VAC | 15V | 3000A | 45000W |
| IPS-ATDH301500 | 380VAC | 30V | 1500A | 45000W |
| IPS-ATDH124000 | 380VAC | 12V | 4000A | 48000W |
| IPS-ATDH242000 | 380VAC | 24V | 2000A | 48000W |
| IPS-ATDH105000 | 380VAC | 10V | 5000A | 50000W |
| IPS-ATDH252000 | 380VAC | 25V | 2000A | 50000W |
| IPS-ATDH100500 | 380VAC | 100V | 500A | 50000W |
| IPS-ATDH100050 | 380VAC | 1000V | 50A | 50000W |
| IPS-ATDH125000 | 380VAC | 12V | 5000A | 60000W |
| IPS-ATDH302000 | 380VAC | 15V | 4000A | 60000W |
| IPS-ATDH302000 | 380VAC | 30V | 2000A | 60000W |
| IPS-ATDH401500 | 380VAC | 40V | 1500A | 60000W |
| IPS-ATDH601000 | 380VAC | 60V | 1000A | 60000W |
| IPS-ATDH252500 | 380VAC | 25V | 2500A | 62500W |
| IPS-ATDH25260 | 380VAC | 25V | 2600A | 65000W |
| IPS-ATDH701000 | 380VAC | 70V | 1000A | 70000W |
| IPS-ATDH126000 | 380VAC | 12V | 6000A | 72000W |
| IPS-ATDH155000 | 380VAC | 15V | 5000A | 75000W |
| IPS-ATDH253000 | 380VAC | 25V | 3000A | 75000W |
| IPS-ATDH302500 | 380VAC | 30V | 2500A | 75000W |
| IPS-ATDH156000 | 380VAC | 15V | 6000A | 90000W |
| IPS-ATDH303000 | 380VAC | 30V | 3000A | 90000W |
| IPS-ATDH128000 | 380VAC | 12V | 8000A | 96000W |
| IPS-ATDH254000 | 380VAC | 25V | 4000A | 100000W |
| IPS-ATDH502000 | 380VAC | 50V | 2000A | 100000W |
| IPS-ATDH323500 | 380VAC | 32V | 3500A | 112000W |
| IPS-ATDH1210000 | 380VAC | 12V | 10000A | 120000W |
| IPS-ATDH158000 | 380VAC | 15V | 8000A | 120000W |
| IPS-ATDH702000 | 380VAC | 70V | 2000A | 140000W |
| IPS-ATDH1510000 | 380VAC | 15V | 1000A | 150000W |
| IPS-ATDH305000 | 380VAC | 30V | 5000A | 150000W |
| IPS-ATDH15V15000 | 380VAC | 15V | 15000A | 225000W |
| IPS-ATDH308000 | 380VAC | 30V | 8000A | 24000W |
| IPS-ATDH2510000 | 380VAC | 25V | 10000A | 250000W |
| IPS-ATDH328000 | 380VAC | 32V | 8000A | 256000W |
| IPS-ATDH1520000 | 380VAC | 15V | 20000A | 300000W |
| IPS-ATDH1502000 | 380VAC | 150V | 2000A | 300000W |
| IPS-ATDH2001500 | 380VAC | 200V | 1500A | 300000W |
| IPS-ATDH1820000 | 380VAC | 18V | 20000A | 360000W |
| IPS-ATDH203000 | 380VAC | 20V | 30000A | 600000W |
| IPS-ATDH6010000 | 380VAC | 60V | 10000A | 600000W |
| IPS-ATDH1280000 | 380VAC | 12V | 80000A | 960000W |
Model List for electroplating
| Model | Input voltage | Output voltage(VDC) | Output Current(AMPS) | Output Power
(W) |
| IPS-ATDH1220 | 380VAC | 12V | 20A | 240W |
| IPS-ATDH1030 | 380VAC | 10V | 30A | 300W |
| IPS-ATDH1050 | 380VAC | 10V | 50A | 500W |
| IPS-ATDH1250 | 380VAC | 12V | 50A | 600W |
| IPS-ATDH10100 | 380VAC | 10V | 100A | 1000W |
| IPS-ATDH12100 | 380VAC | 12V | 100A | 1200W |
| IPS-ATDH2450 | 380VAC | 24V | 50A | 1200W |
| IPS-ATDH15100 | 380VAC | 15V | 100A | 1500W |
| IPS-ATDH12150 | 380VAC | 12V | 150A | 1800W |
| IPS-ATDH12200 | 380VAC | 12V | 200A | 2400W |
| IPS-ATDH25100 | 380VAC | 25V | 100A | 2500W |
| IPS-ATDH30100 | 380VAC | 30V | 100A | 3000W |
| IPS-ATDH12300 | 380VAC | 12V | 300A | 3600W |
| IPS-ATDH12400 | 380VAC | 12V | 400A | 4800W |
| IPS-ATDH24200 | 380VAC | 24V | 200A | 4800W |
| IPS-ATDH25200 | 380VAC | 25V | 200A | 5000W |
| IPS-ATDH12500 | 380VAC | 12V | 500A | 6000W |
| IPS-ATDH30200 | 380VAC | 30V | 200A | 6000W |
| IPS-ATDH24300 | 380VAC | 24V | 300A | 7200W |
| IPS-ATDH30300 | 380VAC | 30V | 300A | 9000W |
| IPS-ATDH24400 | 380VAC | 24V | 400A | 9600W |
| IPS-ATDH101000 | 380VAC | 10V | 1000A | 10000W |
| IPS-ATDH20500 | 380VAC | 20V | 500A | 10000W |
| IPS-ATDH121000 | 380VAC | 12V | 1000A | 12000W |
| IPS-ATDH24500 | 380VAC | 24V | 500A | 12000W |
| IPS-ATDH25500 | 380VAC | 25V | 500A | 12500W |
| IPS-ATDH151000 | 380VAC | 15V | 1000A | 15000W |
| IPS-ATDH20800 | 380VAC | 20V | 800A | 16000W |
| IPS-ATDH121500 | 380VAC | 12V | 1500A | 18000W |
| IPS-ATDH201000 | 380VAC | 20V | 1000A | 20000W |
| IPS-ATDH122000 | 380VAC | 12V | 2000A | 24000W |
| IPS-ATDH251000 | 380VAC | 25V | 1000A | 25000W |
| IPS-ATDH122500 | 380VAC | 12V | 2500A | 30000W |
| IPS-ATDH152000 | 380VAC | 15V | 2000A | 30000W |
| IPS-ATDH123000 | 380VAC | 12V | 3000A | 36000W |
| IPS-ATDH361000 | 380VAC | 36V | 1000A | 36000W |
| IPS-ATDH152500 | 380VAC | 15V | 2500A | 37500W |
| IPS-ATDH153000 | 380VAC | 15V | 3000A | 45000W |
| IPS-ATDH124000 | 380VAC | 12V | 4000A | 48000W |
| IPS-ATDH125000 | 380VAC | 12V | 5000A | 60000W |
| IPS-ATDH154000 | 380VAC | 15V | 4000A | 60000W |
| IPS-ATDH126000 | 380VAC | 12V | 6000A | 72000W |
| IPS-ATDH155000 | 380VAC | 15V | 5000A | 75000W |
| IPS-ATDH127000 | 380VAC | 12V | 7000A | 84000W |
| IPS-ATDH156000 | 380VAC | 15V | 6000A | 90000W |
| IPS-ATDH128000 | 380VAC | 12V | 8000A | 96000W |
| IPS-ATDH121000 | 380VAC | 12V | 1000A | 120000W |
| IPS-ATDH158000 | 380VAC | 15V | 8000A | 120000W |
| IPS-ATDH1510000 | 380VAC | 15V | 10000A | 150000W |
| IPS-ATDH1512000 | 380VAC | 15V | 12000A | 180000W |
| IPS-ATDH1515000 | 380VAC | 15V | 15000A | 225000W |
| IPS-ATDH1520000 | 380VAC | 15V | 20000A | 300000W |
| IPS-ATDH1820000 | 380VAC | 18V | 20000A | 360000W |
Model List-electric heating
| Model | Input voltage | Output voltage(VDC) | Output Current(AMPS) | Output Power
(W) |
| IPS-ATDH1220 | 380VAC | 12V | 20A | 240W |
| IPS-ATDH4300 | 380VAC | 4V | 300A | 1200W |
| IPS-ATDH12100 | 380VAC | 12V | 100A | 1200W |
| IPS-ATDH2450 | 380VAC | 24V | 50A | 1200W |
| IPS-ATDH15100 | 380VAC | 15V | 100A | 1500W |
| IPS-ATDH24100 | 380VAC | 24V | 100A | 2400W |
| IPS-ATDH25100 | 380VAC | 25V | 100A | 2500W |
| IPS-ATDH15200 | 380VAC | 15V | 200A | 3000W |
| IPS-ATDH30100 | 380VAC | 30V | 100A | 3000W |
| IPS-ATDH20200 | 380VAC | 20V | 200A | 4000W |
| IPS-ATDH15300 | 380VAC | 15V | 300A | 4500W |
| IPS-ATDH24200 | 380VAC | 24V | 200A | 4800W |
| IPS-ATDH48100 | 380VAC | 48V | 100A | 4800W |
| IPS-ATDH10500 | 380VAC | 10V | 500A | 5000W |
| IPS-ATDH32170 | 380VAC | 32V | 170A | 5440W |
| IPS-ATDH15400 | 380VAC | 15V | 400A | 6000W |
| IPS-ATDH20300 | 380VAC | 20V | 300A | 6000W |
| IPS-ATDH30200 | 380VAC | 30V | 200A | 6000W |
| IPS-ATDH24150 | 380VAC | 24V | 150A | 7200W |
| IPS-ATDH48300 | 380VAC | 48V | 300A | 7200W |
| IPS-ATDH15500 | 380VAC | 15V | 500A | 7500W |
| IPS-ATDH20400 | 380VAC | 20V | 400A | 8000W |
| IPS-ATDH15600 | 380VAC | 15V | 600A | 9000W |
| IPS-ATDH30300 | 380VAC | 30V | 300A | 9000W |
| IPS-ATDH24400 | 380VAC | 24V | 400A | 9600W |
| IPS-ATDH48200 | 380VAC | 48V | 200A | 9600W |
| IPS-ATDH101000 | 380VAC | 10V | 1000A | 10000W |
| IPS-ATDH20500 | 380VAC | 20V | 500A | 10000W |
| IPS-ATDH50200 | 380VAC | 50V | 200A | 10000W |
| IPS-ATDH62000 | 380VAC | 6V | 2000A | 12000W |
| IPS-ATDH24500 | 380VAC | 24V | 500A | 12000W |
| IPS-ATDH25500 | 380VAC | 25V | 500A | 12500W |
| IPS-ATDH121200 | 380VAC | 12V | 1200A | 14400W |
| IPS-ATDH151000 | 380VAC | 15V | 1000A | 15000W |
| IPS-ATDH30500 | 380VAC | 30V | 500A | 15000W |
| IPS-ATDH82000 | 380VAC | 8V | 2000A | 16000W |
| IPS-ATDH20800 | 380VAC | 20V | 800A | 16000W |
| IPS-ATDH30600 | 380VAC | 30V | 600A | 18000W |
| IPS-ATDH36500 | 380VAC | 36V | 500A | 18000W |
| IPS-ATDH201000 | 380VAC | 20V | 1000A | 20000W |
| IPS-ATDH40500 | 380VAC | 40V | 500A | 20000W |
| IPS-ATDH70030 | 380VAC | 700V | 30A | 21000W |
| IPS-ATDH36600 | 380VAC | 36V | 600A | 21600W |
| IPS-ATDH151500 | 380VAC | 15V | 1500A | 22500W |
| IPS-ATDH241000 | 380VAC | 24V | 1000A | 24000W |
| IPS-ATDH251000 | 380VAC | 25V | 1000A | 25000W |
| IPS-ATDH50500 | 380VAC | 50V | 500A | 25000W |
| IPS-ATDH36800 | 380VAC | 36V | 800A | 28800W |
| IPS-ATDH152000 | 380VAC | 15V | 2000A | 30000W |
| IPS-ATDH301000 | 380VAC | 30V | 1000A | 30000W |
| IPS-ATDH84000 | 380VAC | 8V | 4000A | 32000W |
| IPS-ATDH70500 | 380VAC | 70V | 500A | 35000W |
| IPS-ATDH241500 | 380VAC | 24V | 1500A | 36000W |
| IPS-ATDH361000 | 380VAC | 36V | 1000A | 36000W |
| IPS-ATDH152500 | 380VAC | 15V | 2500A | 37500W |
| IPS-ATDH251500 | 380VAC | 25V | 1500A | 37500W |
| IPS-ATDH85000 | 380VAC | 8V | 5000A | 40000W |
| IPS-ATDH202000 | 380VAC | 20V | 2000A | 40000W |
| IPS-ATDH153000 | 380VAC | 15V | 3000A | 45000W |
| IPS-ATDH301500 | 380VAC | 30V | 1500A | 45000W |
| IPS-ATDH124000 | 380VAC | 12V | 4000A | 48000W |
| IPS-ATDH242000 | 380VAC | 24V | 2000A | 48000W |
| IPS-ATDH252000 | 380VAC | 25V | 2000A | 50000W |
| IPS-ATDH100500 | 380VAC | 100V | 500A | 50000W |
| IPS-ATDH361500 | 380VAC | 36V | 1500A | 54000W |
| IPS-ATDH125000 | 380VAC | 12V | 5000A | 60000W |
| IPS-ATDH154000 | 380VAC | 15V | 4000A | 60000W |
| IPS-ATDH203000 | 380VAC | 20V | 3000A | 60000W |
| IPS-ATDH242500 | 380VAC | 24V | 2500A | 60000W |
| IPS-ATDH302000 | 380VAC | 30V | 2000A | 60000W |
| IPS-ATDH401500 | 380VAC | 40V | 1500A | 60000W |
| IPS-ATDH300200 | 380VAC | 300V | 200A | 60000W |
| IPS-ATDH252500 | 380VAC | 25V | 2500A | 62500W |
| IPS-ATDH252600 | 380VAC | 25V | 2600A | 65000W |
| IPS-ATDH701000 | 380VAC | 70V | 1000A | 70000W |
| IPS-ATDH126000 | 380VAC | 12V | 6000A | 72000W |
| IPS-ATDH243000 | 380VAC | 24V | 3000A | 72000W |
| IPS-ATDH362000 | 380VAC | 36V | 2000A | 72000W |
| IPS-ATDH155000 | 380VAC | 15V | 5000A | 75000W |
| IPS-ATDH253000 | 380VAC | 25V | 3000A | 75000W |
| IPS-ATDH302500 | 380VAC | 30V | 2500A | 75000W |
| IPS-ATDH156000 | 380VAC | 15V | 6000A | 90000W |
| IPS-ATDH303000 | 380VAC | 30V | 3000A | 90000W |
| IPS-ATDH300300 | 380VAC | 300V | 300A | 90000W |
| IPS-ATDH128000 | 380VAC | 12V | 8000A | 96000W |
| IPS-ATDH205000 | 380VAC | 20V | 5000A | 100000W |
| IPS-ATDH254000 | 380VAC | 25V | 4000A | 100000W |
| IPS-ATDH502000 | 380VAC | 50V | 2000A | 100000W |
| IPS-ATDH6010000 | 380VAC | 60V | 10000A | 100000W |
| IPS-ATDH1001000 | 380VAC | 100V | 1000A | 100000W |
| IPS-ATDH200500 | 380VAC | 200V | 500A | 100000W |
| IPS-ATDH1210000 | 380VAC | 12V | 10000A | 120000W |
| IPS-ATDH158000 | 380VAC | 15V | 8000A | 120000W |
| IPS-ATDH602000 | 380VAC | 60V | 2000A | 120000W |
| IPS-ATDH702000 | 380VAC | 70V | 2000A | 140000W |
| IPS-ATDH1510000 | 380VAC | 15V | 10000A | 150000W |
| IPS-ATDH305000 | 380VAC | 30V | 5000A | 150000W |
| IPS-ATDH200750 | 380VAC | 200V | 750A | 150000W |
| IPS-ATDH300500 | 380VAC | 300V | 500A | 150000W |
| IPS-ATDH300600 | 380VAC | 300V | 600A | 180000W |
| IPS-ATDH405000 | 380VAC | 40V | 5000A | 200000W |
| IPS-ATDH1002000 | 380VAC | 100V | 2000A | 200000W |
| IPS-ATDH2001000 | 380VAC | 200V | 1000A | 200000W |
| IPS-ATDH250800 | 380VAC | 250V | 800A | 200000W |
| IPS-ATDH2410000 | 380VAC | 24V | 10000A | 240000W |
| IPS-ATDH308000 | 380VAC | 30V | 8000A | 240000W |
| IPS-ATDH2001250 | 380VAC | 200V | 1250A | 250000W |
| IPS-ATDH328000 | 380VAC | 32V | 8000A | 256000W |
| IPS-ATDH1003000 | 380VAC | 100V | 3000A | 300000W |
| IPS-ATDH1502000 | 380VAC | 150V | 2000A | 300000W |
| IPS-ATDH2001500 | 380VAC | 200V | 1500A | 300000W |
| IPS-ATDH1820000 | 380VAC | 18V | 20000A | 360000W |
| IPS-ATDH3610000 | 380VAC | 36V | 10000A | 360000W |
| IPS-ATDH3801000 | 380VAC | 380V | 1000A | 380000W |
| IPS-ATDH1004000 | 380VAC | 100V | 4000A | 400000W |
| IPS-ATDH2002000 | 380VAC | 200V | 2000A | 400000W |
| IPS-ATDH1005000 | 380VAC | 100V | 5000A | 500000W |
| IPS-ATDH2002500 | 380VAC | 200V | 2500A | 500000W |
| IPS-ATDH2030000 | 380VAC | 20V | 30000A | 600000W |
| IPS-ATDH6010000 | 380VAC | 60V | 10000A | 600000W |
| IPS-ATDH1280000 | 380VAC | 12V | 80000A | 960000W |
Model list-anodic oxidation
| Model | Input voltage | Output voltage(VDC) | Output Current(AMPS) | Output Power
(W) |
| IPS-ATDH12100 | 380VAC | 12V | 100A | 1200W |
| IPS-ATDH2450 | 380VAC | 24V | 50A | 1200W |
| IPS-ATDH24100 | 380VAC | 24V | 100A | 2400W |
| IPS-ATDH20150 | 380VAC | 20V | 150A | 3000W |
| IPS-ATDH12300 | 380VAC | 12V | 300A | 3600W |
| IPS-ATDH20200 | 380VAC | 20V | 200A | 4000W |
| IPS-ATDH12400 | 380VAC | 12V | 400A | 4800W |
| IPS-ATDH24200 | 380VAC | 24V | 200A | 4800W |
| IPS-ATDH12500 | 380VAC | 12V | 500A | 6000W |
| IPS-ATDH20300 | 380VAC | 20V | 300A | 6000W |
| IPS-ATDH30200 | 380VAC | 30V | 200A | 6000W |
| IPS-ATDH24300 | 380VAC | 24V | 300A | 7200W |
| IPS-ATDH50150 | 380VAC | 50V | 150A | 7500W |
| IPS-ATDH20400 | 380VAC | 20V | 400A | 8000W |
| IPS-ATDH24400 | 380VAC | 24V | 400A | 9600W |
| IPS-ATDH20500 | 380VAC | 20V | 500A | 10000W |
| IPS-ATDH50200 | 380VAC | 50V | 200A | 10000W |
| IPS-ATDH24500 | 380VAC | 24V | 500A | 12000W |
| IPS-ATDH25500 | 380VAC | 25V | 500A | 12500W |
| IPS-ATDH121200 | 380VAC | 12V | 1200A | 14400W |
| IPS-ATDH20800 | 380VAC | 20V | 800A | 16000W |
| IPS-ATDH36500 | 380VAC | 36V | 500A | 18000W |
| IPS-ATDH201000 | 380VAC | 20V | 1000A | 20000W |
| IPS-ATDH100200 | 380VAC | 100V | 200A | 20000W |
| IPS-ATDH40050 | 380VAC | 400V | 50A | 20000W |
| IPS-ATDH241000 | 380VAC | 24V | 1000A | 24000W |
| IPS-ATDH251000 | 380VAC | 25V | 1000A | 25000W |
| IPS-ATDH50500 | 380VAC | 50V | 500A | 25000W |
| IPS-ATDH301000 | 380VAC | 30V | 1000A | 30000W |
| IPS-ATDH150200 | 380VAC | 150V | 200A | 30000W |
| IPS-ATDH350100 | 380VAC | 350V | 100A | 35000W |
| IPS-ATDH241500 | 380VAC | 24V | 1500A | 36000W |
| IPS-ATDH361000 | 380VAC | 36V | 1000A | 36000W |
| IPS-ATDH202000 | 380VAC | 20V | 2000A | 40000W |
| IPS-ATDH400100 | 380VAC | 400V | 100A | 40000W |
| IPS-ATDH242000 | 380VAC | 24V | 2000A | 48000W |
| IPS-ATDH252000 | 380VAC | 25V | 2000A | 50000W |
| IPS-ATDH203000 | 380VAC | 20V | 3000A | 60000W |
| IPS-ATDH242500 | 380VAC | 24V | 2500A | 60000W |
| IPS-ATDH302000 | 380VAC | 30V | 2000A | 60000W |
| IPS-ATDH252600 | 380VAC | 25V | 2600A | 65000W |
| IPS-ATDH243000 | 380VAC | 24V | 3000A | 72000W |
| IPS-ATDH501500 | 380VAC | 50V | 1500A | 75000W |
| IPS-ATDH303000 | 380VAC | 30V | 3000A | 90000W |
| IPS-ATDH502000 | 380VAC | 50V | 2000A | 100000W |
| IPS-ATDH602000 | 380VAC | 60V | 2000A | 120000W |
| IPS-ATDH502500 | 380VAC | 50V | 2500A | 125000W |
| IPS-ATDH308000 | 380VAC | 30V | 8000A | 240000W |
| IPS-ATDH2510000 | 380VAC | 25V | 10000A | 250000W |
| IPS-ATDH328000 | 380VAC | 32V | 8000A | 256000W |
| IPS-ATDH1820000 | 380VAC | 18V | 20000A | 360000W |
| IPS-ATDH2415000 | 380VAC | 24V | 15000A | 360000W |
| IPS-ATDH2420000 | 380VAC | 24V | 20000A | 480000W |
>>
Chinese factory Cabin filter for AUDI and VW OEM 4H0 819 439
>>
Concrete Mixing Works Flake Ice Machine
>>
Cute High Quality 200ml Custom Spice Oil & Vinegar Glass Bottle
>>
Custom log big design wood furniture kitchen cabinets usa
>>
China Factory Cheap Price Exterior/Interior/French/Patio/Balcony/Security/Glass/Metal Wrought Iron Main Gate Single/Double New Steel Door
>>
Robust Tube Making Machine for 273.1mm to 406.4mm Diameter
>>
Z5025 Small Round Column Vertical Metal Hole Drilling Machine for sale
>>
Large Custom Design Mould Manufacturing Moulding Manufacturers ABS Part Molding Maker Plastic Injection Mold
>>
Hongxin stainless steel universal pulverizer/grain milling machine/pepper grinding machine
>>
3MP 12.5~780mm 62X F3.5 C Mount HD Motorized Zoom Lens
>>
Factory Made 500Ml Glass Hair Care Oil Dispenser Bottle Spray Bottle Continuous Mist With Spray Pump At Good Price
>>
Decorative curtain mesh woven mesh crimped wire metal mesh
>>
Popular Highlight Stripe Nylon with PVC Backing Commercial Carpet Tiles 50cm*50cm
>>
Automatic Aluminum Pet Can Beverage Liquid Carbonated Soft Energy Drink Beer Hot Juice Canning Filling Sealing Packaging Machine
>>
Maquinaria PARA Madera Woodworking Machine Edge Bander Machine
>>
High Quality 20W 30W 50W Fiber Laser Marking Machine for Jewellery Metal and Nonmetal
>>
China made Bladder NXQ A-40/31.5-L-EH for power plant
>>
Spot PVC Filling body bags Dead Body Bag Professional factory Cadaver Bag for dead body
>>
Eco-Friendly Rubber Granules Mixing Tires Filling Polyurethane Foam Machine
>>
Good Quality Automatic SMS 1600mm Nonwoven Machine
