Vertical Production Planetary Ball Mill for Grinding, Mixing, Alloying and Other Production

Product Description

Vertical production planetary ball mill for grinding, mixing, alloying and other production
Description of Vertical planetary ball mill:
Vertical production type planetary ball mill is a large-scale planetary ball mill that is enlarged and designed on the basis of the principle of small planetary ball mill. The production type planetary ball mill is mainly suitable for large-scale, Chinese batch grinding, mixing, alloying and other production. It is widely used in geology, Minerals, metallurgy, electronics, building materials, ceramics, chemical industry, light industry, medicine, beauty, environmental protection, etc.
Vertical production planetary ball mill features:
The equipment adopts professional appearance design, high-precision laser cutting, CNC bending, generous and delicate, high-end and stable,
The planetary disk is integrally formed, the structural components are processed by numerical control processing technology, and the metal heat treatment technology of nitriding ensures that the rotating shaft parts are wear-resistant and prevent the shaft from breaking,
The transmission gear adopts the combination of high temperature and wear-resistant non-metal and metal precision gear, adopts the self-lubricating gear box type of lubricating oil bubble, good heat dissipation, and is equipped with the liquid oil level gauge, which is convenient for replacement and ensures the stable and quiet operation of the equipment at high speed,
The grinding tank marking device can be used to mark the grinding tank at the same time to lock and prevent loosing synchronously, which is convenient, safe and reliable for operation,
The equipment is equipped with a temperature meter to monitor the temperature in the ball milling chamber, and a level meter to facilitate the installation of heavy equipment,
The integrated design is adopted for the supporting hoisting and dumping device. The dumping device is designed with a vibrating screening discharging mechanism, which is easy to operate and can be easily and quickly taken, unloaded and loaded, reducing labor intensity and improving production efficiency.
The product color matching of the shell gives the product new vitality, activates the new life of the product, conforms to the international and domestic aesthetic needs, and conforms to the ergonomics.
Technical specifications of Vertical planetary ball mill:

Transmission mode	gear drive
operation mode	Two or four ball mills working at the same time
Maximum sample loading	Two thirds of the volume of the ball mill
Volume	5l-25l per tank, total volume 20l-100l
Feeding size	Soil ≤ 10 mm, other ≤ 3 mm
Discharge particle size	Up to 0.1 μ m minimum
Speed ratio (Revolution: rotation)	See main parameters for details
Speed (rotation)	See main parameters for details
Speed regulation mode	Brand frequency converter, stepless speed regulation

Technical parameters(1)

Type	SPEC	Ball mill SPEC	Quantity	Matching vacuum ball mill tank	Standard ball milling tank locking device
PBM-20	20	2-5L	4	2-4L	self-locking
PBM-40	40	5-10L	4	5L	self-locking
PBM-60	60	10-15L	4	10L	self-locking
PBM-80	80	15-20L	4	15L	self-locking
PBM-100	100	20-25L	4	20L	self-locking

Technical parameters(2)

Type	Voltage (single phase)	motor power( (KW)	Run setting total time(min)	Alternate running time(min)	Adjustable speed Revolution (rpm) rotation(rpm)
PBM-20	three phase380V-50HZ	4	1-9999	1-9999	25-215 50-430
PBM-40	three phase380V-50HZ	5.5	1-9999	1-9999	20-195 40-390
PBM-60	three phase380V-50HZ	7.5	1-9999	1-9999	27-174 40-260
PBM-80	three phase380V-50HZ	11	1-9999	1-9999	27-160 40-240
PBM-100	three phase380V-50HZ	11	1-9999	1-9999	27-160 40-240

Technical parameter(3)

Type	Basic panel (intelligent, touch screen optional)	Lubrication method	Speed mode	Weight(kg)	Size Length X width X height	Noise≤db
PBM-20	intelligence	grease	frequency control	440	1300X810X950	68±5
PBM-40	intelligence	grease	frequency control	680	1500X850X1050	68±5
PBM-60	intelligence	grease	frequency control	880	1700X950X1150	68±5
PBM-80	intelligence	grease	frequency control	1100	1850X1100X1200	68±5
PBM-100	intelligence	grease	frequency control	1100	1850X1100X1200	68±5

Reference pictures of Vertical planetary ball mill:
Q. Are you a manufacturer or a trading company?
A. We are professional laboratory instrument manufacturers, have their own design team and factory, have mature technical experience, and can guarantee the quality of products and the optimal price.
Q. How is your company's product after-sales service system?
A. The product warranty period is 12 months, we can provide lifetime maintenance. We have professional pre-sales and after-sales departments that can respond to you within 24 hours to resolve any technical issues.
Q. How long is your delivery time? If I want to customize the instrument, how long does it take?
A.1. If the goods are in stock, it is 5-10 days. 2. We can provide customized services for our customers. It usually takes 30-60 days depending on the specifications of the custom instrument.
Q. Our country's power supply and plug are different. How do you solve it?
A. We can supply a transformer and plug according to your local requirements according to the power plug of different countries.
Q. How to pay?
A.T / T, L / C, D / P, etc., it is recommended to use ****** Trade Guarantee.
Q. How is the package of goods? Delivery methods?
A.1. Standard export fumigation sign wooden box packaging 2. Express, air, sea shipping according to customer requirements, find the most suitable way.
More questions, please contact customer service

---
