| US$11,000.00-12,000.00 | 1 Piece (MOQ) |
| Model | ACME220 -3020 | ACME220 -3030 | ACME220 -3050 | ACME220 -3100 | |
| DC input | input rating voltage (VDC) | 220 | |||
| Input rating current (A) | 10.1 | 15.2 | 25.3 | 49.4 | |
| Input DC voltage allowing range (VDC) | 180~300 | ||||
| AC bypass input | Allowing input voltage range(VAC) | 380±15% | |||
| Input rating current (A) | 3.0 | 4.5 | 7.6 | 15 | |
| Bypass switch time (ms) | ≤4 | ||||
| AC output | Rating capacity (KVA) | 2 | 3 | 5 | 10 |
| Output rating power (KW) | 1.6 | 2.4 | 4.0 | 8.0 | |
| Output rating voltage and frequency | 380VAC (Three phase four wire)50HZ | ||||
| Output rating current (A) | 3.0 | 4.5 | 7.6 | 15 | |
| Output voltage precision(V) | 380±2% | ||||
| Three-phase unbalanced load capacity | ≤100% | ||||
| THD | ≤3% | ||||
| Dynamic response (load 0←→100%) | 5% | ||||
| Power factor(PF) | 0.8 | ||||
| Load ability | 150%, 10scends | ||||
| Crest factor (CF) | 3:1 | ||||
| Inverted efficiency | 92% | ||||
| Working environment | Insulation strength(input and output) | 1500VAC,1minute | |||
| Noise(1meter) | ≤50dB | ||||
| using condition temperature | -10ºC~+50ºC | ||||
| temperature | 0~90%,no condensing | ||||
| Using altitude(m) | ≤2000 | ||||
| Protection function | Input reversing protection, input low-voltage protection, output over-load protection, output short-circuit protection, over-heat protection | ||||
| Model | ACME220 -3200 | ACME220 -3450 | ACME220 -3600 | ACME220 -31000 | |
| DC input | input rating voltage (VDC) | 220 | |||
| Input rating current (A) | 99 | 222 | 296 | 496 | |
| Input DC voltage allowing range (VDC) | 180~300 | ||||
| AC bypass input | Allowing input voltage range(VAC) | 380±15% | |||
| Input rating current (A) | 30.1 | 68.4 | 91.2 | 152 | |
| Bypass switch time (ms) | ≤4 | ||||
| AC output | Rating capacity (KVA) | 20 | 45 | 60 | 100 |
| Output rating power (KW) | 16 | 36 | 48 | 80 | |
| Output rating voltage and frequency | 380VAC (Three phase four wire),50HZ | ||||
| Output rating current (A) | 30.1 | 68.4 | 91.2 | 152 | |
| Output voltage precision(V) | 380±2% | ||||
| Three-phase unbalanced load capacity | ≤100% | ||||
| THD | ≤3% | ||||
| Dynamic response (load 0←→100%) | 5% | ||||
| Power factor(PF) | 0.8 | ||||
| Load ability | 150%,10s | ||||
| Crest factor (CF) | 3:1 | ||||
| Inverted efficiency | 92% | ||||
| Working environment | Insulation strength(input and output) | 1500VAC,1minute | |||
| Noise(1meter) | ≤50dB | ||||
| using condition temperature | -10ºC~+50ºC | ||||
| temperature | 0~90%,no condensing | ||||
| Using altitude(m) | ≤2000 | ||||
| Protection function | Input reversing protection, input low-voltage protection, output over-load protection, output short-circuit protection, over-heat protection | ||||
