Double Shafts Plastic Bottles/Bags/Woven Bags/Waste Cloth Cutter

US$8,000.00-25,000.00 1 Piece (MOQ)

Basic Info.

Model NO.
FM-30-1000
Drive
Electric
Object
Wood, Plastic
Type
Roller Crusher
Principle
Roller Culling
Finished Surface
Hole Process
Compressive Strength (For Crushing)
>300MPA
Tongs′ Features
Dedicated Tongs
Transport Package
Plastic Film
Specification
4100*1200*2300mm
Trademark
FOTMA
Origin
China
HS Code
8477800000
Production Capacity
China

Packaging & Delivery

Package Size
5000.00cm * 230.00cm * 230.00cm
Package Gross Weight
5000.000kg

Product Description

Double Shafts Plastic Bottles/Bags/Woven Bags/Waste Cloth Cutter
The cutter is applicable for shredding the waste plastic bags, bottles, woven Bags, waste
Cloth. These machines ensure safe and healthy environment. The recycling machine is specially designed for waste management. There are different specifications and capacities in which those materials are various sizes.
Double shafts cutter is through the cut, tear and squeezing, reaching to decrease the size of raw material.
The structure features:
Machine body, motor, reduction gears, six arris spindle, Moving Blade and bottom fix blade, frame, bearing housing and other major structures.

The working principle:
Spindle bearings on both sides of main shaft, through motor and reduction gear, rotary main shaft drives the spiral arrangement blades, make the blades on two shafts are meshing together, to tear, raw materials, and repeating this move to finished shredding. electronic control parts has a Reverse automatic control devices, when overfeeding or raw material is too big, Machine will inverted running and stop, avoid damage of blades or motor. To improve the service life and cutting ability, the main shaft through conditioning processing, and use high quality imported blades.

Technical parameters:
Model unit FM-30-1000
Power kw 55+55
Pieces of blade pcs 30
Material / 6Crw2si
Thickness mm 30
Main shaft speed r/min 15
Capacity t/h 12
Weight kgs 3000

Photo:
