| US$1,500.00-2,000.00 | 1 Piece (MOQ) |
| Model | AU-F30C |
| Image mode | RB, B+B, 4B mode RB+M mode RCFM color blood flow pattern RB+CFM mode RPDI energy mode RPDI+B mode RPW mode R B-tilt mode (Note: B-tilt is only applicable to high frequency linear probes less than or equal to 40mm) R3D mode (Optional) |
| Application mode | abdomen, gynecology, obstetrics, superficial organs, pediatrics, urology, heart, blood vessels and other modes |
| Imaging mode | full digital multi-beam formation, speckle noise suppression, tissue harmonic imaging, etc. |
| Sound output | mechanical index, thermal index real-time display, sound power adjustable and real-time display |
| Pseudo-color processing | 16 pseudo-color coding options |
| Gain adjustment | 8 segments TGC, B/M/D/C gain can be adjusted respectively, TGC curve can be displayed and automatically hidden |
| Image processing | 5 levels of image optimization, edge enhancement, frame average, line average, focus optimization, noise suppression, gamma correction, squeeze curve, contrast, brightness adjustable, up and down, left and right flip |
| Automatic optimization function | built-in multiple check types, according to different check types, preset the best image check conditions, reduce the adjustment operation keys |
| Measurement and calculation | B mode conventional measurement, distance, circumference, area, volume, Angle, ratio, and shorthand rate, M mode conventional measurement, woman Department measurement, obstetrics measurement, cardiology measurement, urology measurement, PW measurement and other measurements |
| Image annotation | alphanumeric input, adjustable annotation arrows, labels and comments, body markers, patient and hospital ids, etc |
| Image storage | image storage, video storage, movie playback, solid state disk storage capacity ≥128G |
| Patient data | medical record management, report query and printing, image and video output (hard disk, USB, optional DVD-RW), built-in ultrasound workstation |
| Report page system | automatic report generation system, and full-screen characters in Chinese and English editing |
| Interface | HDMI, VGA, USB, DICOM interface |
| Support probe | electronic linear array CT7.5L40GN, electronic convex array CT3.5C60GN, electronic cavity CT6.5C10GN, electronic slightly convex CT3.5C20GN Electronic convex CT6.5C8015, electronic convex CT7.5C8020, electronic rectal CT6.0L8064 |
| Input voltage | 100-240V, 50/60Hz 19V,6A,DC adapter |
| Battery power supply | ≥1.5 hours (4.5 hours battery is optional) (Actual battery working time may vary according to the use environment) |
| Appearance size | 370mm*382mm*90mmm (length × width × height) Weight ≤ 6.5Kg |
| SL No | Probe Type | Picture | Radius/ Footprint | Frequency Range(MHz) | Human/ vet | Clinical application |
| CT3.5C60GN | Convex | R60 | 2.0 MHz /3.0 MHz /3.5 MHz /4.5 MHz /6.0MHz | Both | Abdomen, Obstetrics, Gynecology, Kidney, Urology | |
| CT7.5L40GN | Linear | L40 | 5.0 MHz /6.0 MHz /7.5 MHz /9.0 MHz /12.0MHz | Both | Vascular, Small parts, Muscleskeletal, Carotid, Nerve, Orthopedic | |
| CT6.5C10GN | TV | R10 | 4.5 MHz /5.0 MHz /6.5 MHz /7.5 MHz /10.0MHz | Both | Gynecology, Obstetrics, Urology | |
| CT6.5C8015 | Micro Convex | R15 | 4.5 MHz /5.0 MHz /6.5 MHz /7.5 MHz /10.0MHz | Both | General small abdomen and cardiac Equine musculoskeletal and abdomens | |
| CT3.5C20GN | Micro Convex | R20 | 5.0 MHz /6.0 MHz /7.5 MHz /9.0MHz /12.0MHz | Both | General small abdomen and cardiac Equine musculoskeletal and abdomens | |
| CT7.5C8020 | Micro Convex | R20 | 5.0 MHz /6.0 MHz /7.5 MHz /9.0MHz /12.0MHz | Both | General small abdomen and cardiac Equine musculoskeletal and abdomens | |
| CT6.0L8064 | Linear transrectal | L64 | 5.0 MHz /5.5 MHz /6.5 MHz /7.5MHz /10.0MHz | Veterinary only | Equine and bovine reproduction Equine musculoskeletal Fish-sexing, egg determination |
