5mm Round, Green LED 5034G3c Water Clear LED Light

Product Description

5mm Round, Green LED Light
ELECSOUND
Elecsound is very strong in round LED. We can offer 3mm round LED, 5mm round LED, 8mm round LED and 10mm round. We can offer white round LED, blue round LED, yellow round LED, red round LED and so on. Welcome to check our website
Features
High efficiency
Low Power consumption
General purpose leads
Selected minimum intensities
Available on tape and reel
Pb free
Descriptions
The series is specially designed for applications
Requiring higher brightness
The LED lamps are available with different
Colors, intensities, epoxy colors, etc
Superior performance in outdoor environment
Usage Notes:
The ultra bright LED is an electrostatic insensitive device, so static electricity and surge will damage the LED. It is required to wear a wrist-band when handling the LED. All device, equipment, machinery, desk and ground must be properly grounded
When using LED, it must use a protective resistor in series with DC current about 20mA
Applications
Status indicators
Commercial use
Advertising Signs
Back lighting
Device Selection Guide
LED Part No. Chip Lens Color
Material Emitted Color
5034G3C-CSC-A InGaN Green Water clear
Absolute Maximum Rating (Ta=25c)
Parameter Symbol Absolute Maximum Rating Unit
Forward Pulse Current IFPM 70 mA
Forward Current IFM 30 mA
Reverse Voltage VR 5 V
Power Dissipation PD 140 mW
Operating Temperature Topr -40~+80c
Storage Temperature Tstg -40~+100c
Soldering Heat (5s) Tsol 260c
Note:
1. Luminous intensity is measured with a light sensor and filter combination that approximates the CIE eye-response curve.
2.1/2 is the off-axis angle at which the luminous intensity is half the axial luminous intensity.

Electro-Optical Characteristics (Ta=25c)
Parameter	Symbol	Min.	Typ.	Max.	Unit	Test Condition
Luminous Intensity	Iv	3000	5500	---	mcd	IF=20mA(Note1)
Viewing Angle	2λ 1/2	20	25	30	Deg	(Note 2)
Peak Emission Wavelength	λ P	520	525	530	nm	IF=20mA
Spectral Line Half-Width	Dλ	30	35	40	nm	IF=20mA
Forward Voltage	VF	2.9	---	3.5	V	IF=20mA
Reverse Current	IR	---	---	10	µ A	VR=5V

5003R4C-BPC-P	GaP	Red	640	Water Clear	1.8-2.4	50-100	15
5003R2C-BHC-S	GaAsP	Red	630-640	Water Clear	1.9-2.3	250-400	15
5003R1C-BSA-A	AlGaInP	Red	620-635	Water Clear	1.9-2.3	1000-2000	15
5003R1C-BSB-B	AlGaInP	Red	620-635	Water Clear	1.9-2.3	2000-3500	15
5034R1C-BSC-C	AlGaInP	Red	620-635	Water Clear	1.9-2.5	4000-6000	15
5034R1C-BUA-D	AlGaInP	Red	620-635	Water Clear	1.9-2.5	10000-15000	15
5003Y1C-BSA-A	AlGaInP	Yellow	580-595	Water Clear	1.9-2.3	1000-2000	15
5003Y1C-BSB-B	AlGaInP	Yellow	580-595	Water Clear	1.9-2.3	2000-3500	15
5034Y1C-BSC-C	AlGaInP	Yellow	580-595	Water Clear	1.9-2.5	4000-5500	15
5034Y1C-BUA-D	AlGaInP	Yellow	580-595	Water Clear	1.9-2.5	10000-15000	15
5003G6C-BHA-P	GaP	Green	565-575	Water Clear	1.8-2.4	50-100	15
5003G6C-BSA-S	AlGaInP	Green	565-575	Water Clear	1.9-2.3	1000-2000	15
5034G3C-BSC-A	InGaN	Green	520-530	Water Clear	2.9-3.5	4000-6000	15
5034G3C-BUA-B	InGaN	Green	520-530	Water Clear	2.9-3.5	10000-15000	15
5034B2C-BSB-A	InGaN	Blue	460-470	Water Clear	2.9-3.5	1500-2500	15
5034B2C-BSC-B	InGaN	Blue	460-470	Water Clear	2.9-3.5	2000-4000	15
5034B2C-BSD-C	InGaN	Blue	460-470	Water Clear	2.9-3.5	6000-9000	15
5034W2C-BSC-A	InGaN	White		Water Clear	2.9-3.5	2000-4000	15
5034W2C-BSD-B	InGaN	White		Water Clear	2.9-3.5	6000-9000	15
5034W2C-BUB-C	InGaN	White		Water Clear	2.9-3.5	12000-18000	15

Product Overviews
We currently offer a broad range of capacitors, LEDs, Cermet Trimming Potentiometers, PCBs, Semiconductors, Transistors, Zinc Oxide Varistors, Switches and Resistors.
Company Information
Elecsound is an ISO Certificated manufacturer of high quality, high reliability electronic components, formed in January of 1996. Our staff has over 10 years of experience with excellent English. All of our employees have a strong work ethic and a strong commitment to provide the high quality products that consistently meet or exceed our customer's requirements.
Certificates
Packaging & Shipping
FAQ
1: How long is your lead time?
It depends. Normally, it is 2-6 working days if the goods are in stock, or it is 7-40 days if the goods not in stock.

2: What is your terms of payment ?
For small amount orders, 100% better paid by PayPal or T/T in advance. For large amount orders like more than
10000USD, 30% T/T in advance , balance fully paid before shipment.

3. Do you have any MOQ limit for an order?
Yes, we have MOQ. different items have different MOQ. We will mark MOQ when we quote.

4: How to proceed an order?
Firstly, let us know your requirements or application. Secondly, we quote according to your requirements or our suggestions. Thirdly, customer confirms the samples and pay deposit for the official order. Finally, we arrange the production and ship once it's ready.

5: Do you accept online orders?
Sure!! We prefer to fulfil orders under Trade Assurance system, since both parties will be protected.

6: Do you provide samples? is it free or extra?
Yes, normally we could offer samples with free charge but do not pay the shipping freight.

7: How do you guarantee my goods right?
Order will be arranged exactly as requested, we will doubly check the packing and qty before delivering out also we will take you photos if required or necessary.

8: Is it OK to print my logo on the packing?
Of course, customized packing accepted!! But it may bring some cost, it depends on the qty, if small qty then we don't accept.
