Gains 600mm Fiberglass Pipes Manufacturers Large Diameter GRP/FRP Pipe China 3" GRP Mortar Tube

US$5.00-500.00 10 Meters (MOQ)

Basic Info.

Model NO.
FRP GRP Mortar Pipe
Thickness
8-30mm
Usage
Environmental Protection, Industral, Household
Product Categories
FRP Pipe
Molding Method
Hand Lay-up Method
Material
FRP
Fiber Type
CFRP
Type
Silicone FRP
Product Name
FRP Filament Winding Pipe
Keywords
Fiberglass-Reinforced Plastic Mortar Pipe
Name5
Grve Reinforced Pipe
Name6
Corrosion-Resist Pipe
Name7
Spigot & Socket Joint
Name8
Potable Water Pipe
Name9
Seawater Desalliation Pipe
Pressure
0.2-1.6MPa
Connection
Flanged Joint, Butt Joint
Materials
Fibreglass Reinforced Plastic
Work Temperature
-40c - 80c
Name1
Fiberglass Pipe
Name2
GRP Round Pipe
Name3
FRP Undergroud Pipe
Name4
GRP Water Pipe
Transport Package
Standard or Customized
Specification
DN150mm - DN5000mm Or Customized
Trademark
GJ
Origin
China
HS Code
8424899990
Production Capacity
10000set/Year

Packaging & Delivery

Package Size
120.00cm * 50.00cm * 50.00cm
Package Gross Weight
100.000kg

Product Description

Gains 600Mm Fiberglass Pipes Manufacturers Large Diameter Grp Pipe China 3" GRP Mortar Tube
Product DescriptionFRP Pipe, Referred To As FRP Pipe, Is A Composite Pipe Made Of Glass Fiber Reinforced Plastic And Mortar. The Surface Layer Is Wrapped By Glass Fiber Bundles, And The Middle Layer And Back Layer Are Composed Of Mortar Materials And Bonded By Technology. It Has Good Acid And Alkali Resistance, Water Resistance, Corrosion Resistance, Impact Resistance, Heat Resistance, And Other Characteristics.
FRP Sand-Filled Pipe Is Made Of Thermosetting Resin As Matrix, Glass Fiber And Its Products As Reinforcing Material, And Is Made By Computer-Controlled Mechanical Winding Process. From The Process Structure, It Can Be Divided Into Pure FRP Pipe And FRP Sand Pipe. The Main Difference Between The Two Is That The Former Is A Fiber-Wound Solid FRP Structure, And The Latter Is Formed By Continuous Fiber Winding And Sand Inclusion Technology. The Middle Layer Of The Pipe Wall Is Made The Resin Mortar Layer Is Used To Increase The Thickness Of The Pipe Wall, Improve The Strength Of The Pipe, And Enhance The Ability To Resist External Loads.
Pipe Wall Structure Description
The Pipe Wall Structure Is Divided Into the Inner Lining Layer, Inner Winding Layer, Resin Mortar Layer, Outer Winding Layer, And Outer Protective Layer From Inside To Outside.
The Inner Lining Layer Plays The Role Of Anti-Corrosion And Anti-Seepage, The Inner Winding Layer And Resin Mortar Layer Play The Role Of Strength Rigidity Of The Pipeline, And The Outer Protective Layer Plays The Role Of Anti-Aging, Anti-Corrosion, And Anti-Sunshine
This Structure Distributes The High-Strength Fiber-Wound Layers In The Inner And Outer Layers Subjected To The Greatest Bending Stress, While The Lower-Strength Quartz Mortar Layer Is Distributed Near The Neutral Layer With A Small Bending Stress, Which Is The Most Economical And Reasonable Structure. Making Full Use Of The Advantages Of Various Materials Is The Best Embodiment Of The Designability Of Materials. Connection Way Of FRP Pipes
1 Sole Sealing Ring Socket Coupling: Suitable For Medium Pressure
2 Double Sealing Ring Socket Coupling: Suitable For High Pressure
3 Socket Coupling: Suitable For High-Pressure And Heavy-Caliber Piping
4 Spigot Coupling: Suitable For High, Medium, And Low-Pressure Piping And Fittings' Coupling
5 Socket '0' Type Sealing Coupling, Nylon Clapper '0' Wedged Lock Which Mainly Applies To Axial Strength Piping
6 Flange Coupling: Suitable For Medium And Low-Pressure Piping
Product Advantages
1. Excellent Mechanical And Physical Properties
2. Corrosion Resistance, Aging Resistance, Long Service Life
3. The Inner Surface Is Smooth And Has Excellent Hydraulic Performance
4. Light In Weight, Easy To Transport, Install And Maintain
5. No Burst Tube, Reliable Interface, Good Safety
6. Non-Toxic, No Secondary Pollution
7. Good Wear Resistance And Strong Corrosion Resistance
8. Heat Resistance, Frost Resistance, Temperature Adaptability
9. The Fluid Negative Force Is Small, and The Inner Wall Of The FRP Pipe With Sand Is Smooth
10. High Mechanical Strength
11. The Water Quality Is Maintained In Good Condition. FRP Pipes With Sand Inclusions Are Non-Toxic Products.
12, Light Weight, Easy To Install FRP Pipes With Sand Inclusions Have A Small Specific Gravity
Product Parameters
Product NameFRP Winding pipe
KeywordsFiberglass-Reinforced Plastic Mortar Pipe
Length3m 6m 10m 12m or customized
ShapeRound Shape
FeatureHigh Strength
Processing ServiceCutting
TechniqueFilament Winding Process
Pressure0.2-1.6MPa
ConnectionFlanged joint, Butt joint
MaterialsFibreglass Reinforced Plastic
Work Temperature-40C-80C
ColorsNatural green or customized
AdvantageSmooth, Not easy to leak, Easy to maintain
CertificateISO9001
MOQ1 meter

Parameters Of GRP/FRP Sand Pipe
Medium RangeDrinking Water, Sewage, Seawater, And Various Chemical Wastewater
Pipe Inner Diameter300Mm~2600Mm In Diameter
Pipe LengthUsually 12 Meters Per Strip
Pipeline Pressure0.25Mpa~1.6Mpa
Pipe Stiffness2500N/M2-10000N/M2
Connection MethodSocket Connection
Appearance ColorTranslucent Light Green
Safety AccessoriesDouble O-Shaped Sealing Rubber Ring
