Three Roller Calender of Film Forming Equipment

Product Description

The forming principle of the three roller calender is to extrude the uniformly plasticized plastic melt in the extruder, extrude it through the die head, apply it to the calendering roller, and then form it after shaping, stretching and cooling.
The laboratory three roller calender produced by the company adopts precision extrusion and high performance calendering molding technology, suitable for PE, PP, PS, ABS, PVC, PET, PC and other commonly used polymer materials calendering film forming.
It is more suitable for scientific research institutions, colleges and universities laboratories, production enterprises laboratories and enterprises engaged in small-scale film production.
Three roller calender

Photograph	Performance Index	Performance Parameter
	Flat die	60×1.5 mm Customizable
	Power of die heating	1.2 kW
	Film thickness	0.5-1.0 mm
	Max. film width	50mm
	Roller Speed	0-140mm/s
	Diameter of roller	110mm
	Roller width	190 mm
	Distance between rollers	0-2.5mm adjustable
	Crimp Ways	Tension adjustment
	Power of Pull Motor	550w
	Power of Crimp Motor	370w
	Total power	1.0 kW
	Cooling	Water
	Mains connection	3×380V,50/60 Hz ,+N +PE
	Weight	200 kg
	Dimension (L×W×H)	1400×650×1300 mm

---
