US$1,500.00
|
1 Piece
(MOQ)
|
Basic Info.
Transport Package
Plastic Film
Production Capacity
100sets Per Month
Product Description
Model | BH5600 | BH6600 | BH7600 | BH8600 | |
Maximum Digging Depth | 1830mm | 2133mm | 2438mm | 2745mm | |
Digging Depth (two foot flat bottom) | 1676mm | 1980mm | 2286mm | 2590mm | |
Swing Arc | 180 ° | 180 ° | 180 ° | 180 | |
Loading Height (bucket at 60 ° ) | 1270mm | 1524mm | 1778mm | 2032mm | |
Reach from Center Line of Swing Pivot | 2286mm | 2590mm | 2895mm | 3200mm | |
Transport Height (maximum) | 1245mm | 1498mm | 1752mm | 2032mm | |
Bucket Rotation | 180 | 180 ° | 180 ° | 180 | |
Loading Reach (bucket at 60 ° ) | 865mm | 965mm | 1092mm | 1220mm | |
Transport Overhang | 1016mm | 1042mm | 1066mm | 1092mm | |
Undercut | 660mm | 712mm | 762mm | 812mm | |
Stabilizer Spread, down position | 1700mm | 1980mm | 2260mm | 2565mm | |
Stabilizer Spread, up position | 1066mm | 1194mm | 1550mm | 1828mm | |
Bucket Cylinder Digging Force | 930kgs | 1112kgs | 1288kgs | 1360kgs | |
Dipper stick Cylinder Digging Force | 476kgs | 566kgs | 910kgs | 1135kgs | |
Shipping Weight (less bucket) | 252kgs | 296kgs | 356kgs | 498kgs | |
Hydraulic Volume 3'4" Requirements | 3 to 4 GPM | 3 to 4 GPM | 4 to 5 GPM | 5 to 6 GPM | |
Hydraulic Pressure Requirements | 2000psi | 2000 psi | 2000 psi | 2000 psi | |
Recommended Tractor HP | 18-25HP | 20 - 35 HP | 25 - 45 HP | 35 - 65 HP | |
| | | | | |
Company introduction:
Changzhou No.2 Drying Equipment Factory Co.,Ltd is an old drying enterprise which has 23 years drying history. We have got several patents in different dryers. We have much experience in different drying area. Now it holds more than 100 sets of equipment. The company has more than 100 staff and workers, including 15 engineers, with annual value of production more than thirty-eight million RMB.We attach importance to advanced technology, and have cooperated positively with universities and colleges to develop new products by using new technics. We have continuously developed several key and high-tech products with advanced technology both from domestic and abroad.During the past ten continuous years, the company has been appraised as enterprise with high reputation on contract and credit.Bases on the principle of factualism, innovation and mutual benefit, the enterprise is looking forward to creating resplendence with personages from all circles together.
CERTIFICATE
Delivery the dryer:
Foreign customers:
Pre-service
Act as a good adviser and assistant of clients to enable them get rich and generous returns on their investments.
1. Introduce the product to the customer in detail, answer the question raised by customer carefully;
2.Make plans for choice according to the needs and special requirements of users in different sectors;
Sale service
1. Ensure product with high quality and pre-commissioning before delivery;
2. Delivery on time;
3.Provide full set of documents meet customer`s requirements.
After-sale service
Provide considerate services to minimize clients` worries.
1.Assist clients to prepare for the first construction scheme;
2.Install and debug the equipment;
3.Train the first-line operators;
4. Examine the equipment;
5.Take initiative to eliminate the troubles rapidly;
6.Provide technical support;
7.Establish long-term and friendly relationship.
Service commitment
1. Provide clients one-year warranty to make sure the machine work well;
2.We always keep certain inventory level of spare parts, which means the replacements can be sent to you timely;
>>
