Seam Welding Machine Suppliers with Advanced High-Frequency Inverter Welding Power Supply

Product Description

Product Description
PSS-H160 parallel seam welding machine is a semi-automatic equipment. This device can be used for metal bases and covers Airtight packaging between. This equipment is equipped with a highly reliable PLC and industrial control computer, as well as advanced high-frequency inverter welding power supply, with fast dynamic response speed and high control accuracy.
Place the fixture for placing the shell base and cover plate on the workbench, and press the start button to follow the selected program welding conditions, the entire welding machine head is placed in a glove box for operation.

Shell size: (4-160) x (4-160) mm

Shell shape: rectangular, circular

Cover plate thickness: (0.10-0.15) mm (recommended value: 0.12mm)

Shell materials: Kovar, metallized ceramics, stainless steel, etc

Rectangular shell corner shape: (R0.3~R2) mm

Seam welding sealing: Meet the requirements of GJB548B-2005 Testing Methods and Procedures for Microelectronic Devices

Extreme vacuum degree: 5Pa

Maximum temperature: 200 ºC

Heating layer number: 3 layers (layer spacing of 75mm ± 1mm)

External dimensions of heating plate: 350 × 230 × 10 (mm)

Surface temperature uniformity of hot plate: ± 5 ºC

Number of ovens: 1

Heating method: Plate internal heating

Dew point: ≤ -40 ºC

Welding pressure: 500g-2000g adjustable

Maximum welding power of welding power supply: 9kW (nominal power)

Maximum output current of welding power supply: 3kA (nominal current)

Welding power supply Welding power supply frequency: 8kHz

Electrode wheel up and down stroke: 35mm

X-axis repeated positioning accuracy: ± 0.01mm

Y-axis repeated positioning accuracy: ± 0.01mm

Z-axis repeated positioning accuracy: ± 0.01mm

Boundary dimensions: (2240 x 930 x 1900) mm

Equipment weight: 800kg

Main functions of the device:
1) Oven function: Place the product in the oven for vacuum pumping, heating and other pre-treatment;
2) Glove box function: providing a stable atmosphere environment for product production, controlling the pressure and water of the glove box
Steam content;
3) Exchange box function: Transfer the product out of the glove box while ensuring the atmosphere of the glove box;
4) Sealing function: Complete the airtight packaging of the product, including spot welding, long edge seam welding, and short edge seam welding;
5) Password protection function: Power on password protection, maximizing the protection of user devices and data
Safety;
6) Display operation: Display operation, all parameters are set on the display, and the operation is simple and convenient,
Friendly human-machine interface;
7) Safety device: equipped with emergency stop switch and interlock function, it can stop urgently in case of operation error
The interlocking function of equipment operation enables interlocking of mechanisms that cannot move simultaneously on software, which is the most effective
Maximally protect the safe operation of equipment; Application
Exhibition & Customers
Jiangsu Himalaya Semiconductor Co., Ltd. Was established in 2019, mainly engaged in international trade and integration of semiconductor industry equipment. The equipment is currently imported and exported to over 30 countries, with over 200 customers and suppliers, aiming to control the procurement of the highest cost-effective products in the final stage for customers, and strive for one-time payment collection and risk avoidance for suppliers!
Our main products:Die Bonder,Wire Bonding,Laser Marking(ID IC Wafer),Laser Grooving,Laser Cutting(Glass Ceramics Wafers Packaging,Laser Internal Modification Machine Si /Sic Wafe,Laser Internal Modification Machine Lt/Ln Wafer,Laser Annealing Machine for Si/Sic,Automatic Dicing Saw Machine(Wafer Packaging)),Automatic Silicone Dispensing Equipment.
Packaging & Shipping

FAQ
Q1:How to choose a suitable machine?
A1:You can tell us the working piece material, size, and the request of machine function. We can recommend the most suitable machine according to our experience.
Q2:What is the warranty period for the equipment?
A2:One year warranty and 24 hours online professional technical support.
Q3:How to choose a suitable machine?
A3:You can tell us the request of machine function. We can recommend the most suitable machine according to our experience.

---
