HZS050Y concrete batching plant, equipped with JS1000 twin shafts mixer and belt type aggregates charging system, has rated output 50m³/h compacted concrete. It can mix various kinds of concrete and is suitable for small and medium sized construction projects.
Modular design subserves container transportation. With rear axle installed, the concrete batching plant can be integrally towed by tractor.
The plant is fully automatic controlled by computer with production management and data printing software.
Model
| HZS050-3Y
|
Max theory Capacity (m3/h)
| 50
|
Mixer
| JS1000
|
Storage hopper capacity (m3)
| 4×8
|
Aggregate Max. Dia (pebble/crushed)
| 80/60mm
|
Discharge height (m)
| 4
|
Charge height (m)
| 5.4
|
Aggregate measuring accuracy (%)
| ±2
|
Cement measuring accuracy (%)
| ±1
|
Water measuring accuracy (%)
| ±1
|
Additive measuring accuracy (%)
| ±1
|
()Power of supply (kW) ( without cement silo and screw conveyor)
| 68
|
Power voltage (V) /frequency (Hz)
| AC 380/50
|
)Total weight(t) about ( without cement silo and screw conveyor)
| 28.2
|
