US$150,000.00-400,000.00
|
1 Piece
(MOQ)
|
Basic Info.
Transport Package
Container
Production Capacity
40000t/Year
Product Description
More then 100 production lines running all over the world. More then 95% market share in China.
Not only equipment
We also provide TURNKEY PROJECTS:
RAW MATERIALS -- PICKLING(Waste HCl regeneration equipment) /Unpickling solution -- DRAWING --TWISTING -- TESTING -- FINAL PRODUCTS.
Finished products standards:GB/T5524-2014,
GOST R 13840-68,
GOST R 53772-2010,
ASTM A 416/A416M-02
IS-14268/1995,
EN 10138-3-2006
ASTM A 416/A416M-02
BS5896-1998
JIS G 3536-1999
The technical parameters of steel strand unit
Product specifications(mm) | Φ17.8 , Φ15.7 , Φ15.24 , Φ12.7 , Φ11.1 , Φ9.53 |
Strength level | 1860MPa |
Designed speed | 120m/min |
Assessment speed | 110m/min(Φ15.24) |
Spool | Φ1250,Φ120;diameter:Φ1250; Inner Bore Φ120; manufacturer provides drawings |
Intermediate frequency furnace (domestic) | Power 600kw, Temperature 380-420ºC, Moving distance 12m; Speed matches with the tracking power |
Motor (domestic) | 1st power 280kw, 2nd power280kw, stranding power 132kw |
The annual output table (According to maximum design speed : 600r/min)
Strand ø | Area | Tensile Strength | Weight | pitch | Speed | pull | Production |
mm | mm2 | MPa | kg/m | mm | m/min | KN | kg/h | T/month | t/year |
9.53 | 55 | 1860 | 0.43 | 133 | 79.8 | 48 | 2399 | 978 | 11735 |
11.1 | 74.2 | 0.582 | 155.4 | 93 | 62 | 3527 | 1542 | 18511 |
12.7 | 98.7 | 0.775 | 178 | 106 | 83 | 4929 | 2340 | 28095 |
15.24 | 140 | 1.115 | 213 | 120 | 118 | 8028 | 3813 | 45759 |
17.8 | 191 | 1.5 | 250 | 70 | 160 | 6300 | 2992 | 35910 |
24 h/day * 80% * 25day/month | |
Reduce losses
Improve efficiency
Reduce manufacturing cost
More environmentally friendly !
>>
