US$90,000.00
|
1 Unit
(MOQ)
|
Basic Info.
Transmission
Hydraulic Transmission
Drive Type
Internal Combustion Drive
Bucket Capacity
0.5~1.0m³
Certification
CE, ISO9001: 2000
Operating Weight
221000kg
Standard Bucket Capacity
1.1m3
Engine Model
Isuz-U 4HK1X
Overall Dimensions
9650 X2810X3050 mm
Rated Power/Speed
120kw/2200r/Min
Max. Digging Height
9640mm
Max. Dumping Height
7110mm
Max. Digging Depth
6620mm
Specification
CE/ ROHS/SGS/GMP
Production Capacity
500 Units/Month
Product Description
Product Description
1. Operation weight: 221000kg
2. Standard 1.1m3 bucket
3. Max. Digging height: 9640mm
4. Original KAWASAKI hydraulic system
5. Engine: 120kw ISUZ-U 4HK1X
6. Original KAWASAKI electronic system
7. Cabin with A/C, ROPS/FOPS
8. With break hammer
Komatu-s hydraulic crawler excavator SL920 produced in Japan with engine isstrong and usually used in mine application.
It has operation weight of 221000kg. It has strong performance in building construction and can be used in mine with hydraulic hammer to break stones into small ones for further processing in crushing plant.
Japan KAWASAKI hydraulic system and electronic system has provided SL920 excavator with reliable and excellent performance.
Detailed Photos
Cabin with AC
Hydraulic Pump
Hydraulic Motor
Engine
Backward
Muti Valve
Operation Cabin
Product Parameters
| Engine | Travel System |
| Model | ISUZ-U 4HK1X | Travel motors | KYB, Japan; |
| Type | Turbocharged, 4 stroke, Direct injection, water cooled, with air-air intercooler | Support roller quantities | 2×8 |
| Carrier roller quantities | 2×2 |
| No. of cylinder | 4 | Travel shoes | 2X47 |
| Bore and stroke | 115X125(mm) | Travel speed | 3.3/5.2(km/h) |
| Displacement | 5.193L | Drawbar pulling force | 134.8kN |
| Power output | 120kw/2000rpm | Gradeability | 70%(350) |
| Max. torque | 657N.m/1500rpm | Track shoe thickness | 10mm |
| Hydraulic System | Cab & Electrical System |
| Main Pump | KPM, Japan | Cab | Cab installed with silicon oil rubber, adjustable luxurious seat, cold and warm air-conditioning system plus flexible pilot control system |
| Type | axial piston pump |
| Max. discharge flow | 2x230(L/min) |
| Max. discharge pressure |
| Boom, arm and bucket | 31.4/34.3 MPa | Voltage | 24V |
| Travel circuit | 34.3 MPa | Batteries | 2X24V |
| Swing circuit | 27.5 MPa | Battery capacity | 240Ah |
| Control circuit | 3.9 MPa | Boom, Arm & Bucket |
| Pilot control pump | Gear type | Boom cylinder | Ф120xФ85xS1335-L1870 |
| Main valve | KYB, Japan | Arm cylinder | Ф135xФ95xS1490-L2075 |
| Oil cooler | Air cooled type | Bucket cylinder | Ф115xФ80xS1120- L1680 |
| Swing System | Refilling Capacity & lubrication |
| Swing motor | KPM, Japan | Fuel tank | 410 L |
| Swing motor type | Axial-piston motor | Cooling system | 26 L |
| Hydraulic oil released | Hydraulic oil released | Engine oil | 22 L |
| Hydraulic disc brake | Hydraulic disc brake | Hydraulic oil tank | 195 L Tank Oil Level |
| Swing speed | 10.5r/min | 295 L Hydraulic System |
| Bucket |
| Type | Backhoe bucket |
| Bucket capacity | 1.1 m3 (SAE) |
| Bucket capacity scope | 0.92-1.10 m3 |
| Number of bucket teeth | 5 |
| Bucket width | 1270 mm |
| Working Ranges | |
| Boom length | 5700mm |
| A | Max. digging radius | 9982mm |
| B | Max. digging depth | 6622mm |
| C | Max. digging height | 9970mm |
| D | Max. dumping height | 7000mm |
| E | Min swing radius | 3203mm |
| F | Max. vertical wall digging depth | 5900mm |
| G | Max. digging reach at ground level | 9975mm |
| Digging Force (ISO6015) |
| Arm length | 2925mm |
| A | Bucket digging force | 139KN |
| B | Arm digging force | 110KN |
