US$1,944.00-11,944.00
|
1 Piece
(MOQ)
|
Basic Info.
Length of Fiber Cable
5 Meters
Operation Language
Multiple
Power Supply
1 Phase / 100-240V / 50-60Hz
Max Power Consumption
1400W
Lase Beam Width
100 X 100mm (Option)
Max Scanning Speed
45, 000mm/S
Emergency Button on Cleaning Head
Yes
Transport Package
Plywood Box
Specification
480 x 240 x 440 mm
Packaging & Delivery
Package Size
58.00cm * 34.00cm * 60.00cm
Package Gross Weight
25.000kg
Product Description
https://jezlaser.en.made-in-china.com/product-list-1.html
Introducing the innovative Jez 2024 Best Selling Portable Laser Cleaner, featuring cutting-edge small size pulse fiber laser technology with power options ranging from 100W to 300W, designed for unparalleled flexibility and performance.
Our air-cooled laser cleaning machine revolutionizes portability with its compact design, weighing just 15KG, making it effortlessly easy to transport and perfect for on-site demonstrations.
Perfectly suited for a diverse range of applications including rust and paint removal, the restoration of wooden furniture, stone art, building facades, and intricate stone sculptures, this versatile cleaner meets all your restoration needs with precision.
Features
1.Proudly presenting the smallest size and lightest weight in its category;
2.Utilizes advanced non-contact cleaning technology, effectively eliminating any risk of internal stress or deformation of materials;
3.Engineered for ease of use with lightweight handling and high integration ensuring safe and efficient operations; ;
4.Operates without chemical detergents, ensuring zero consumable use, promoting sustainability; ;
5. Universally compatible with power supplies, operating on a 1 phase 100-240V / 50-60Hz system, making it adaptable for global use;
6. Equipped with a state-of-the-art 2D mini air-cooling cleaning head, complete with an emergency stop button for enhanced safety;
7. Features an integrated air cooling system with four different laser patterns, offering versatility for multiple applications;
8. Offers convenient cleaning modes, including 'easier clean' and 'super clean', enhancing efficiency and simplifying every cleaning task.
Applicable materials and industries
1.Efficiently eliminates rust from an extensive array of metal parts, enhancing longevity;
2.Cleans weld beads on stainless steel, copper, aluminum, and carbon steel with exceptional precision;
3.Delicately aids in the restoration of cultural relics and sculptures, preserving historical integrity;,
4.Expertly removes graffiti and paint from heritage buildings and stone statues, ensuring preservation of original aesthetics;
5.Ideal for the meticulous restoration of wooden antique furniture, especially valuable after exposure to smoke damage.
Specifications(For reference only)
Laser Power | 200W |
Laser wavelength | 1060-1080nm |
Pulse width(ns) | 150-190 |
Pulse repetition frequency(KHZ) | 5-200 |
Max Single Pulse Energy(MJ) | 1.5 |
Working Humidity | <70% |
Power Supply | 1PH / 100-240V / 50-60HZ |
Power Consumption | 1400W |
Cooling Way | Air cooling |
Laser Type | Pulse Fiber laser |
Length of fiber cable(m) | 5 |
Working Humidity | <70% |
Working Temperature | 5-40°C |
Lase Beam Width | Standard 100 x 100 mm |
Laser beam types | 4 different types |
E-Stop button on cleaning head | Yes |
Weight of cleaning head | 0.7 kg |
Machine Size | 480 x 240 x 440 mm |
Net Weight | 15KG |
Max Scanning speed | 45,000mm/s |
Operation interface language | English(Option) |
Air Blow function to protect Focus lens | Yes |
Air Blow function to improve working efficiency | Yes |
Scanning Mode | F-Theta |
FAQ
Q: What is the Limitations of laser cleaning for mold ?
A:Molds with deep undercuts
Deep & small diameter holes
Molds with mirror chrome or highly polished finishes
Very thick & strongly adhered residues
Q:What is Typical Applications of laser De-Coating ?
A: Surface preparation for steel structure corrosion control
Safe removal of hazardous coatings & contaminants
De-coating interior surfaces where dust & odors are not permitted
Q: What is the delivery time of your laser cleaning machine :
A: Normally we have new machines in stock ,The delivery time of ordinary machines is generally 7-15 working days ;
