OEM/ODM Design PTFE Plastic Strap Tape for Water/Air Line Pipe Thread Sealing

Product Description

Product DescriptionProduct DescriptionPTFE THREAD SEAL TAPE is one kind of novel ideal seal material, the best material of anti-corrosive performance. It displays inertia to the majority chemicals and the resolver. And it has the ability to resist strong acid and alkali, water and the organic solvent. As a sealing filler for pipeline connections, PTFE tape can effectively prevent water leakage. It is wrapped around the joint of the pipe fitting that needs to increase the sealing effect, ensuring the airtightness of the pipeline by increasing the sealing effect. (What is ptfe tape?)

Width	12mm 19mm 25mm (1/2",3/4",1")
Thickness	0.075mm 0.1mm 0.2mm
Length	1m-100m
Density	0.2g/cm3--4g/cm3
OEM	According to customer's requests
Color	White,Yellow, Blue,pink,OEM
Heat-resistance	Above370Celsius
Cold-resistance	Below190Celsius
Tensile Strength	>=8MPA
Percentage elongation	>=25%
Residual lubricant	<=0.5%
High pressure resistance	150~200KG/CM^2
Delivery	30 days after getting 30% advanced payment
Shrink	10pcs/shrink
Innerbox	48pcs/box or 100pcs/box or 250pcs/box
Outer Carton	500pcs/ctn or 1000pcs/ctn

How to use ptfe thread seal tape?1. Remove foreign objects from the connecting parts and keep them clean.2. Pay attention to the wrapping direction. Taking the angle valve as an example, when the angle valve is screwed into the inner thread of the wall, it rotates clockwise to the right. The direction of wrapping the raw material tape on the angle valve is counterclockwise to the left. This way, when the angle valve is screwed, it will become tighter and will not loosen.3. When wrapping, tighten the PTFE thread seal tape to make it tightly adhere to the thread, try to tighten it as tightly as possible, and do not loosen it. After wrapping, use your hands to rotate and press it tightly, or you can wrap it while pressing it.4. As for the number of layers of wrapping, there is no strict regulation, which should be able to be tightened without leakage. However, based on experience, it is usually necessary to wrap more than ten times to ensure the sealing effect.5. When tightening the thread, do not tighten it too hard. Just use a little force and it doesn't necessarily have to be too tight to prevent leakage. As long as the hand feels strong when tightening, it is sufficient.
Taixing Hongshuo Electronics Co., Ltd. is a professional manufacture and export company for high quality PTFE THREAD SEAL TAPE. It is widely used for civil-construction, machinery, chemicals and space navigation, especially in grainage systems. Product Parameters

Introdution
Specification		Width: 3 - 100mm(routine :12mm,19mm,25mm)
		Thickness:0.07-0.2mm(routine:0.07mm,0.075mm,0.1mm)
		Length:4--50m(260",480",520")
		Density:0.15-1.2g/cm3
		Special length, thickness, density are available upon request.
Materials		100% PTFE without oil
Color for tape		White tape or colour tapes
Color for shell		Various plastics colors are available upon request.
Port		Shanghai or Ningbo (Any main China port)
MOQ		50000pcs
Delivery time		15 -30 days after receiving the deposit or L/C
Advantages		competitive price&good quality&delivery on time
Certificate		ISO 9001, CE, etc.
Technical parameters
Heat resistance		+370 degree centigrade
Cold resistance		-190 degree centigrade
Pressure resistance		up to 30 bar
Tensile strength		>=8Mpa or control according to the demand
Percentage elongation		>=25%
Feature		easier to wrap under any environment

Detailed specification
Style No.		Width	Thickness	Length	Density
12SS -01		12mm	0.075mm	4m	0.15g/cm3-1.2g/cm3
12SS -02		12mm	0.075mm	5m
12SS -07		12mm	0.075mm	10m
12SS -08		1/2"	0.075mm	260"
12SS -13		1/2"	0.075mm	480"
12SS -14		1/2"	0.075mm	520"
12MS -18		12mm	0.1mm	10m
12BS -35		12mm	0.1mm	30m
12BS -38		12mm	0.075mm	50m
12BS-40		12mm	0.2mm	20m
19SS -42		19mm	0.075mm	10m
19SS- 44		3/4"	0.075mm	520"
19MS- 47		19mm	0.1mm	18m
19BS- 51		19mm	0.075mm	40m
19BS- 56		19mm	0.2mm	20m
19BS- 60		19mm	0.2mm	35m
25SS-64		25mm	0.075mm	10m
25BS-71		25mm	0.075mm	40m
25BS-72		25mm	0.2mm	10m
25BS-76		25mm	0.2mm	35m
Special length, thickness, density are available upon request.

Company ProfileTaixing Hongshuo Electronics Co., LTD
Taixing Hongshuo Electronics Co., LTD., is the manufacturer of PFE. Processing and production of all kinds of widening, thickening, waterproof raw material belt, and all kinds of raw material belt customization. With first-class production equipment, modern operation process, complete and scientific quality management system. Taixing Hongshuo Electronics Co., Ltd.s integrity, strength and product quality is recognized by the industry.
Taixing Hongshuo Electronics Co., Ltd. in line with the production principle of "quality for survival, reputation for development", has won the majority of new and old customers praise. Welcome friends from all walks of life to visit, guide, and conduct business negotiations.Advantages:
We are a manufacturer and exporter of PTFE from Taixing, Taizhou.
2. We produce 100% oil-free PTFE tape.
3. We can accept small orders and welcome OEMs.
4. We can make the color of the scroll and lid according to your requirements.
5. Raw materials for valve core and cover: PP, PS.
We can pack according to your requirements.
We participate in the Canton Fair every year.
8. Sample: The customer provides us with detailed information, and we can send the sample in 5 days.
9. Visit: If you need to visit our factory, we can pick you up from Yangtai Airport. It takes an hour to get from Yangtai Airport to our factory.
Packaging & Shipping
FAQQ1:Are you a factory or trading company?
A: Yes,we have own factory
Q2:Can I get some samples?
A: Yes,free samples are available for you.
Q3: How To Order quickly?
A: 1. Specified density 2. Specify the color and quantity
3. Specify thickness
4. Specify the width

---
