Product Details
Product Description
Product Description
Features:
1. Improve cutting efficiency: According to the type of fabric required, size, quantity and other factors, make a detailed cutting plan. Optimize the workflow, reduce unnecessary waste and improve cutting efficiency.
2. Choose efficient cutting methods: The fabric cutter machine adopts advanced cutting technology, which can complete cutting tasks more quickly and accurately, and improve production efficiency.
3. Optimizing fabric management: Reasonable fabric management in fabric cutter machine can reduce waste and improve utilization. Classify, store, and label fabrics to ensure they can be quickly found when needed. At the same time, pre-treatment of the fabric, such as wrinkle removal and finishing, can improve the cutting quality.
4. Intelligent cutting blade design ensures cutting accuracy: The textile cutting machine precisely controls the height of the machine head to ensure the accurate distance between the cutting blade and the fabric, thereby achieving precise cutting.
5. High precision: Through precise driving and guiding devices, ensure the positional accuracy of the fabric during the conveying process, and improve the accuracy of cutting.
6. Consumables and vulnerable parts have high cost-effectiveness and are easy to maintain.
Technical Data:
Model
| PE-B2025
|
Maximum Cutting Height
| 3cm / 5cm / 7cm / 9cm (post-adsorption)
|
Crop Window
| Length (unlimited)
|
Width (not exceeding fabric width)
|
Working Width
| 1700mm /2000mm/2200mm optional
|
Standard Cut Length
| 2500mm/3300mm optional
|
Operating Voltage
| Three-phase electricity 380V, 50~60Hz
|
Machine Standard Energy Consumption
| 18KW （The highest）
|
CAD& CAM Docking Mode
| Ethernet communication/USB external connection
|
Straight Knife Up and Down Reciprocating Maximum Speed
| 4000RPM
|
Barometric Flow
| 0.55Mpa 160L/min
|
Maximum Speed
| 50000mm/min
|
Acceleration
| 0.6~0.8g (N/ Kg)
|
Cutting Accuracy
| ≤ ±1mm
|
Noise Score
| ＜75 dbA
|
>>
