| AD12V190ZLT2 Natural Gas Genset Motor Technical Specification |
| Model | AD12V190ZLT2 |
| Type | four stroke spark plug ignition water cooling. |
| | Intercooled diesel engine |
| Cylinder arrangement | V type 60° angle |
| Cylinder quantity | 12 |
| Cylinder diameter(mm) | 190 |
| Piston stroke(mm) | 210 |
| Piston total flow rate(L) | 71.5 |
| Compression ratio | 10: 1 |
| rated speed(r/min) | 1500 |
| no-load minimum steady speed(r/min) | 700 |
| Rated power(12hours power. kW) | 1100 |
| Heat consumption rate (kJ/kW@ h) | ≤ 11000 |
| Rate of regulating speed in stability (%) | ≤ 5 |
| Engine oil grade | 15W40CD |
| Engine oil consumption rate (kg/kW@ h) | 1.63 |
| Cooling mode | forced water cooling |
| Lubricating mode | pressure and splash lubricate |
| Starting mode | motor starting |
| Gas consumption (m2/h) | 45 |
| Gas pressure(kPa) | 78--138 |
