Enerpac Digital, Hydraulic Pressure Gauges with High Quality

Product Description

1>. Digital, Hydraulic Pressure Gauges
Rated for system pressure up to 1380 bar
Displays high pressure in bar, psi, MPa and kg/cm2
Zero reset - ensures that gauge reads actual pressure
IP65 protection
3 Volt battery included (type CR2430), condition indicator on read-out
Shut-off slectable - menu driven
Protective cover included.

Pressure Rating (bar)		Model Number	Pressure Rating (MPa)		Pressure Rating (Kg/cm2)		Weight (kg)
Range	Interval		Range	Interval	Range	Interval
0 - 1380	0,1	DGR-2	0 - 140	0,01	0 - 1400	0,1	0,23

2>.G, H-Series, Hydraulic Pressure Gauges
Glycerine Filled Hydraulic Pressure Gauges (G-Series)
Dual scale reading calibrated in bar and psi
All pressure sensing parts sealed and dampened by glycerine for long life
Includes safety blow-out disk and pressure equalizing membrane
Gauge snubbers or needle valves recommended for high cycle applications.
High Cycle Dry Hydraulic Pressure Gauges (H-Series)
Dual scale reading calibrated in bar and psi
Ideal for use in many applications, specifically for high cycle and harsh environments
Gauge snubbers or needle valves recommended to shut off gauge when not in use.

Pressure Range		G-Series Model Number Glycerine Filled Gauges				H-Series Model Number Dry Gauges
		ø 63 1/4" NPTF Lower Mount Accuracy: ± 1.5 %	ø 63 1/4" NPTF Center Rear Accuracy: ± 1.5 %	ø 100 1/4" NPTF Lower Mount Accuracy: ± 1.0 %	ø 100 1/2" NPTF Lower Mount Accuracy: ± 1.0 %	ø 100 1/4" NPTF Lower Mount Accuracy: ± 1.0 %	ø 100 1/2" NPTF Lower Mount Accuracy: ± 1.0 %
psi	bar
0-100	0-7	G2509L	-	-	-	-	-
0-160	0-11	G2510L	-	-	-	-	-
0-200	0-14	G2511L	-	-	-	-	-
0-300	0-20	G2512L	-	-	-	-	-
0-600	0-40	G2513L	-	-	-	-	-
0-1.000	0-70	G2514L	G2531R	-	-	-	-
0-2.000	0-140	G2515L	-	-	-	-	-
0-3.000	0-200	G2516L	-	-	-	-	-
0-6.000	0-400	G2517L	G2534R	-	-	-	-
0-10.000	0-700	G2535L	G2537R	G4088L	G4039L	-	-
0-15.000	0-1000	G2536L	G2538R	G4089L	G4040L	-	-
0-10.000	0-700	-	-	-	-	H4049L	H4071L

3>.GF, GP-Series, Hydraulic Force & Pressure Gauges
Enerpac GF-Series hydraulic force and pressure gauges are calibrated with dual scale reading for pressure and force in bar and kN
GF-series gauges: all pressure sensing parts are sealed and dampened by glycerine for long life
GP-series gauges: calibrated with dual scale reading for pressure in bar and psi
Excellent readability: gauge face dimensions 100 mm
Fast, easy installation
Stainless steel gauge cases for corrosion resistance.

For use with cylinders	Gauge Calibration			Units per division			Model Number	Thread	Required Gauge Adaptor Model Nr.
	psi	bar	kN	bar	kN	psi		NPTF
all	0 - 10.000	0 - 700	-	10	-	100	GP-10S	1/2"	GA-2
all	0 - 15.000	0 - 1000	-	10	-	200	GP-15S	1/2"	GA-2
5 ton	-	0 - 700	0 -45	10	0,5	-	GF-5B	1/2"	GA-2
10 ton	-	0 - 700	0 - 100	10	1	-	GF-10B	1/2"	GA-2
25 ton	-	0 - 700	0 - 232	10	2	-	GF-20B	1/2"	GA-2
RC, RR 50 ton	-	0 - 700	0 - 500	10	5	-	GF-50B	1/2"	GA-2
RCH 13 ton	-	0 - 700	0 - 124	10	1	-	GF-120B	1/2"	GA-2
RCS-201, 302	-	0 - 700	0 - 175 / 275	10	2 + 5	-	GF-230B	1/2"	GA-2
RCS-502, 1002	-	0 - 700	0 - 450 / 900	10	5 + 10	-	GF-510B	1/2"	GA-2
RCH-202, 302, 603	-	0 - 700	0 - 210 / 320 / 570	10	5	-	GF-813B	1/4"	GA-3
25, 30, 50 ton	-	0 - 700	0 - 232 / 300 / 500	10	5	-	GF-835B	1/4"	GA-3
75, 100 ton	-	0 - 700	0 - 720 / 930	10	10	-	GF-871B	1/4"	GA-3
150, 200 ton	-	0 - 700	0 - 1400 / 2000	10	25	-	GF-200B	1/4"	GA-3

4>. T-Series, Test System Gauges
Enerpac test system gauges are calibrated for dual scale reading in psi and bar
All test gauges have spring-loaded backs with rubber blow-out plugs to protect case assembly in case of over-pressurization
Integral maximum indicator pointer standard included
2800 and 3500 bar models include flange mounting
½" NPTF versions are made of high strength alloy steel
0.25" cone models are made of 316 stainless steel, with 403 stainless steel on 2800 and 3500 bar models.

Pressure Range		Model Number		Accuracy	Number of Intervals bar	Graduation of Intervals bar	Number of Intervals psi	Graduation of Intervals psi
		Alloy Steel 1/2" NPTF	Stainless Steel 0,25" Cone
bar	psi
0-70	0-1000	T-6001L	-	± 0,5 %	10	1	100	10
0-350	0-5000	T-6002L	-	± 0,5 %	50	5	500	50
0-700	0-10.000	T-6003L	T-6007L	± 0,5 %	100	10	1000	100
0-1400	0-20.000	-	T-6008L	± 0,5 %	200	20	1000	100
0-2800	0-40.000	-	T-6010L	± 1,5 %	500	20	5000	200
0-3500	0-50.000	-	T-6011L	± 1,5 %	500	50	5000	200
