Large 3-axis NC Precision Surface Grinding Grinder Machine FSG60120NC

Product Description

Features:
Independent hydraulic station;
Automatic center lubrication unit;
Auto grinding program including rough, finish and spark-out stroke to realize automatic grinding;
High precision spindle unit with angular ball bearing;
MPG is equipped for Y & Z-axis to improve production efficiency;

Item	SG-60120NC	SG-60160NC
Table size W*L	630x1250mm	630x1600mm
Max. Grinding size W*L	600x1000mm	600x1000mm
Max. Distance from table to spindle center	600mm
Magnetic chuck size (optional)	600x1000mmx1	600x800mx2
Speed of table longitudinal movement	5-25m/min
Wheel head cross movement
Auto intermittent feed	0-30mm/t
Rapid travel	0-600mm/min
Feed of MPG	0.005mm/div.
Wheel head vertical movement
Auto feed	0.005,0.01,0.02,0.03,0.04
Rapid feed	0-300mm/min
Spindle motor	7.5kW	7.5kW
Packing size	399x225x250cm	564x225x250mm
Gross weight	5500kg	6000kg

Standard accessories:
Working lamp;
Balancing shaft;
Splashing guard;
Standard grinding wheel;
Levelling wedge;
Built-in magnetic chuck controller;
Coolant tank;
Wheel dresser;
FAQ
1. MOQ
1 set
.
2. DELIVERY TIME
It depends on the machine and model you choose. Mostly 2 months - 4months. All machines are 100% new and not used.

3. PAYMENT TERM
T/T 30% down payment when order, 70% balance payment before shipment.
4. WARRANTY PERIOD
13 months from the date of B/L, during the warranty period, daily damage parts will be supplied freely, the after sale service will be done by dealers . After warranty period, the spare parts will be supplied at factory price.

---
