Manual Bottle Shrink Labeling Machine / Semiautomatic Labeler Machine
Product Description
Brief introduction
1. Shrinkage film volume label rack, match with adjustable device, convenient to adjust
according to differ volume label 5″~10″paper tube.
2. Simply installation, then can convenient for square and round bottle.
3. No need of instrument, rotary mechanism is convenient to adjust, apply to differ bottle type.
4. Unique sleeve labeling method, adopt to pressing sleeve labeling method,
not only convenient but also reasonable.
5. Auto controlling feeding system, level-off shrinkage film materials and regulate/adjust strain simultaneity.
6. Unique design knife plate, within specification scope, can avoid changing knife base,
knife changing is quick and conveniently.
7. Middle guide-pole clip system,mould changing is more quick, no need any instrument.
8. Label location system, can promote and demote in-phase adjust location according to specific bottle type requirement.
9. Adopt to Japanese import servo system and high-sensitivity photoelectric, label cutting precision is highly.
10. Stainless steel electric equipment controlling case, controlling adopt to Thinget PLC
11. Adopt to advanced man-computer Interface auto controlling technology, key electric component all adopt to international famous industrial brand
shrink tunnel and steam generator:
Main technical data:
1.1 Brief Introduction1) GD-2300 Steam Heating Shrink Tunnel can be applied to different and irregular bottle types, e.g. round,square and flat bottles.
2) It adopts seamless tube, the distribution of low-pressure steam drum and the spout of steam use the separation style which make the tunnel smooth.
3) The steam nozzle is divided to three adjustable segments; the height, position and steam output of each segment can be adjusted respectively; this guarantees a perfect shrinking effect.
4) The whole machine is made of stainless steel with heat preservation, it not only saves energy, but also match with the international safety standard.
5) The reductor and transportation machine is made by Spirax Sarco which has a good working environment.
6) The stainless steel defrosting tray collects condensed water.The whole machine adopts the water-proof design with the convenience of operation and maintenance.
1.2 Technical Parameter
No.
| Item
| Technical data
|
1
| Input Voltage Supply of Blower
| 1, 220 VAC
|
2
| Input Voltage Supply of Steam Generator
| 380V/ 50 Hz
|
3
| Working Pressure
| <= 0.1 Mpa
|
4
| Dimension of Shrink Tunnel
| L2300mm× W700mm × H1750mm
|
5
| Weight
| 150Kg
|
2. Steam Generator2.1 Brief Introduction1) The water is feed into the series of wholly automatic electrical heating generator by high pressure potential vortex pump made of copper with short water-supply time and durable service.
2) A floating ball for liquid level is fixed in the water tank to automatically control the water inlet.
3) Working system is all automatically controlled.After connecting the water supply and power supple for 5 minutes or so,it can output the steam continuously with high working efficiency.
2.2 Technical Parameter
No.
| Item
| Technical data
|
1
| Input Power Supply
| 3 Phases 380V/220V
|
2
| Input Power
| 24KW
|
3
| Steam Pressure
| 0.4Mpa~0.7Mpa
|
4
| Water Tank Volume
| 48L
|
5
| Vapor Generation Value
| 25.8Kg/h
|
6
| External Dimension
| 760mm*670mm*1360mm
|
7
| Weight
| 125Kg
|
Related product
| RO System
This RO system we can make to match up with your water filling machine from capacity from 500L/Hr to 50000L/hr.
This system included sand filter, carbon filter, sodium exchanger, precision filter, Reverse Osmosis, UV, Ozone generator, Ozonized Tower, Pure water tank.
This system is made of SUS304 or SUS316 material, thickness is 2.5mm-3mm we promised.
|
Blowing Machine with different options
1. Semiautomatic Blowing Machine for 800BPH-2000bph from 0.2-2.5L bottle with 2 or 4 cavities.
2.Full automatic blowing machine from 2 cavity, 4 cavity, 6 cavity, 8 cavity, 9 cavity,etc from 2500BPH to 12000BPH for 500ml bottle.
| |
| | Automatic PVC sleeve labeling machine
Capacity: 100-350bottles/min can be chosen
Label material: PVC PET OPS, etc
Bottle material: PET PE PP Glass
Bottle Diameter: 28 ~ 120mm
Bottle Height: 15~320mm
Bottle shape: round, square, ellipse, rectangular
Label length: 30~250mm(max)
|
|
Automatic pet film shrink packing machine
Flow: Feeding→ pushing bottles→ film covering and sealing→ shrinking→ cooling
Speed: 8-12packages/min
Power (rated/real): 26kw / 16kw
Max. packing size: 420*300*350mm(LxWxH)
Max. sealing size: 650mm
|
