| Specification | Unit | XU6325W | XU6330W | XU6332W |
| Table Size | mm | 1270*250 | 1370*305 | 1570*320 |
| T SIotS(N/W/D) | 3/16/65 | 3/16/65 | 3/16/65 | |
| Longitudinal travel | mm | 750(850 manually) | 800 | 1000 |
| Cross travel | mm | 400 | 380 | 380 |
| Vertical travel | mm | 400 | 400 | 400 |
| Quill Trave | mm | 127 | 127 | 127 |
| Distance between spindle center and column | mm | 155-635 | 155-635 | 155-635 |
| Distance between spindle nose and table top | mm | 0-460 | 0-460 | 0-460 |
| Arm Travel | mm | 400 | 500 | 500 |
| Milling Head tilting | 90°(Left&Right);45°(Front&Back) | 90°(Left&Right);45°(Front&Back) | 90°(Left&Right);45°(Front&Back) | |
| Spindle taper | R8(V);NT40(H) | R8(V);NT40(H) | R8(V);NT40(H) | |
| Spindle speed | r/min | 66-4540(V);40-1300(H) | 66-4540(V);40-1300(H) | 66-4540(V);40-1300(H) |
| Power of spindle motor | kw | 2.2 kw(V);3KW(H) | 2.2 kw(V);3KW(H) | 3.75 kw(V);3KW(H) |
| Max. table safety load | kg | 350 | 350 | 350 |
| Machine Diamension | mm | 1750*1530*2340 | 1750*1650*2340 | 1950*1650*2340 |
| Net. Weight | kg | 1380 | 1550 | 1750 |
