Product Details
Product Description
Product Description
Product Introduction
Perfect Laser is a leading manufacturer in the channel letter benders for stainless steel industry. The fully channel letter benders for stainless steel has a precise structure and can realize efficient and accurate bending of various materials, among which the bending strength of stainless steel is the most prominent. The channel letter benders for stainless steel is the preferred equipment for the production of signs, signs, neon signs, billboards and light boxes in the advertising industry.
Product Features
1) High-precision machining: the feeding accuracy of channel letter bender for sale can reach 0.01 mm, bending accuracy can reach 0.4 °;
2) High-efficiency machining: double machete parallel bending, improving the processing speed, and the processing time is less;
3) Convenient operation interface: the configuration of the channel letter benders for stainless steel is simple, touch screen operation, it can automatically bend after entering text and graphics;
4) Automatic calibration function: the channel letter bender for sale can adjust the processing parameters according to different materials;
5) Facilitate the monitoring of work flow: unique 3D process simulation technology, 2D design files, display of 3D effects, easy to observe and monitor the entire work process;
6) Wide range of applications: the channel letter bender for sale is suitable for different materials such as stainless steel, aluminum strip, galvanized sheet, iron sheet, etc.
Technical Data
Model
| Channel Letter Bender PEL-200
|
Bending materials
| Stainless steel, galvanized sheet, aluminum plate, etc
|
Processed thickness
| Stainless steel: 0.4-1.0mm
Plate aluminium：0.6-1.2mm
|
Max. processed width
| 20-120mm
|
Voltage
| 220V
|
Maximum power
| 2.5KW
|
Weight
| 380KG
|
File format
| DXF PLT AI
|
Feed speed
| 2-5m/min
|
Bending mode
| uniaxial
|
Minimum bending radius
| 7mm
|
Drive motor
| Servo motor：2
Stepper motor：2
|
Size
| 1680mm*750mm*1350mm
|
Air pressure
| 0.6MPa
|
>>
