3-2000micron Food Grade Nylon Filter Mesh Cloth for Liquid or Car Filter

Product Description

Product Name Food Grade Monofilament 100% Nylon Filter Mesh Cloth 3micron to 2000micron for Liquid Filter or Car Filter

Company Profile Shanghai SPRING Industrial Corporation is a leading global manufacturer of precision woven fabrics made from high-quality monofilament fibres, including polyester mesh/PET mesh, polyamide mesh/nylon mesh, and polypropylene mesh/PP mesh. Our technical materials are `specifically
designed for industrial and appliance filters where accurate and predictable filtration results are critical.
Shanghai SPRING silk screen mesh precision fabrics offer exceptional accuracy thanks to their narrow aperture size distribution and uniform mesh openings. Our weave pattern is engineered to minimize pressure drop, ensuring an efficient and uninterrupted flow while maintaining superior filtration performance.
With over 20 years of experience and a deep commitment to quality, we supply millions of high-performance filter meshes and fabricated filter products worldwide. We work closely with our customers to develop custom solutions that meet their specific filtration needs, no matter how complex or demanding they may be. From initial design to final product delivery, our team of experts is dedicated to providing outstanding service and support every step of the way.
Product Features SPRING Nylon filter mesh is a type of mesh made from Nylon synthetic fibres that have several features, including:
Durability: Nylon is a strong and durable material, which makes nylon filter mesh long-lasting and resistant to wear and tear.
Chemical resistance: Nylon is resistant to many chemicals, making it an ideal material for use in filtering applications where the mesh may come into contact with various fluids or solutions.
Good abrasion resistance: The surface of nylon filter mesh is smooth and has good abrasion resistance, so it can withstand rubbing against other materials without getting damaged easily.
High tensile strength: Nylon filter mesh has a high tensile strength, which means it can withstand high levels of stress and pressure without sustaining damage.
Good elasticity: Nylon has good elasticity, which enables the mesh to stretch and then return to its original shape, making it great for use in applications where flexibility is important.
Non-toxic: Nylon is a non-toxic material, which makes it safe for use in food and medical applications.
Wide range of mesh sizes: Nylon filter mesh comes in a wide range of mesh sizes, which allows for precise filtration depending on the application.
Product Parameters

100% Nylon Mesh
Type	Weave	Mesh/CM	Mesh/inch	Wire Dia. (um)	Mesh Opening(um)	Open Area (%)	Thickness (um)
PA-4/1950	PW	4	10	550	1950	61	1096
PA-5/1500	PW	5	13	500	1500	56	998
PA-6/1267	PW	6	15	400	1267	58	796
PA-7/1079	PW	7	18	350	1079	57	691
PA-8/900	PW	8	20	350	900	52	697
PA-9/861	PW	9	24	250	861	60	492
PA-10/750	PW	10	25	250	750	56	494
PA-12/533	PW	12	30	300	533	41	590
PA-14/514	PW	14	35	200	514	52	391
PA-16/425	PW	16	40	200	425	46	393
PA-18/356	PW	18	45	200	356	41	395
PA-20/300	PW	20	50	200	300	36	396
PA-24/267	PW	24	60	150	267	41	292
PA-28/207	PW	28	70	150	207	34	295
PA-30/213	PW	30	76	120	213	41	230
PA-32/213	PW	32	80	100	213	46	186
PA-36/178	PW	36	90	100	178	41	189
PA-40/150	PW	40	100	100	150	36	192
PA-44/127	PW	44	110	100	127	31	195
PA-48/128	PW	48	120	80	128	38	150
PA-56/119	PW	56	142	60	119	44	96
PA-59/109	PW	59	150	60	109	42	110
PA-64/96	PW	64	163	60	96	38	116
PA-72/89	PW	72	183	50	89	41	90
PA-80/75	PW	80	203	50	75	36	93
PA-88/71	PW	88	224	43	71	39	70
PA-96/61	PW	96	244	43	61	34	74
PA-100/57	PW	100	254	43	57	32	75
PA-104/53	PW	104	264	43	53	31	76
PA-110/48	PW	110	280	43	48	28	78
PA-120/40	PW	120	305	43	40	23	80
PA-130/34	PW	130	330	43	34	19	81
PA-140/33	PW	140	355	38	33	22	72
PA-150/28	TW	150	380	39	28	17	73
PA-157/25	TW	157	400	39	25	15	74
PA-165/30	TW	165	420	30	30	25	54
PA-200/21	TW	200	500	30	21	17	56
PA-212/8	TW	212	540	39	8	3	75
PA-240/3	TW	240	600	39	3	1	76

Detailed Photos
Application: Shanghai SPRING Nylon mesh is made from 100% nylon PA6 or PA66, it is widely used for food filteraton, car filtration, chemical filtration, etc.as following:
Food and beverage filtration: It can be used for milk, yogurt, coffee, beverage and flour filter, with FDA approval, it can meet all the request and make sure it's safe for our health. Pharmaceutical production: The high quality material with durable and stable characters can meet the Pharmaceutical production request. Automotive filtration systems: With Silicone Oil Quantification certificates can make sure the mesh is safe to use even for car paniter filtration. Water and wastewater treatment: Different microns from 3micron to 2000micron can meet the different microns request even in water filter for purifier or wastewater treatment. Industrial filtration processes: Durable and stable nylon mesh with different microns available can meet also various Inustrial filtration. Certifications

---
