CE Approved ICU Mecan China Intravenous Syringe Pumps Veterinary Infusion Pump

Product Description

High Quality LCD Display Medical Infusion Pump
Model:MCS0194

Features 1. Double CPU, Safter Infusion
2. Brightness LCD, Display visually
3. Numeric Keypad, User Friendly
4. 10 Level occlusion pressure detection adjustable
5. Occlusion, Air-in-line, Audio Visual Alarm Volume: 10 settings
6.3000Ah Lithium Battery, Backup Life: >=10hours
7. KVO adjustable 0.1-5ml/h
8.Occlusion Detector Safter Infusion Specification

Infusion Mode	Volume Mode,Time Mode,Drug Mode,Bolus Mode
Rate Unit	ml/hs volume/time,d/min
IV Sets	Standard single use IV sets (10,15,20,60d/mL, with diameter 3.4 ~ 4.5mm)
Flow Rate	1.0ml/h~1200ml/h ; l.Od/min-400d/min
Increment	1.0-99.9ml/h with O.lml/h; 100-1200ml/h with Iml/h
Deviation	Flow Rate: W±5% (after calibration)
VTBI	0.1 -9999.9 ml
Total Volume	0~9999.9 ml
Time	lmin -99h59min
Purge Rate	600ml/h, displaying purge volume
KVO	0.1ml/h~5.0ml/h, adjustable
Keypad	Numeric Keypad, user friendly
BOLUS	Bolus function available,flow rate adjustable
Night Mode	Night Mode, No operation for 5mins, LCD brightness lower automatically.
Occlusion Pressure Detection	Occlusion pressure detection , 40~ 130KPa ,0-9 levels adjustable, dynamic pressure value display.
Air bubble Detection	Ultrasonic detection,>50|iL,Single bubble volume: 50 -300u1,0-9 levels adjustable.
Volume	0~9 levels adjustable
Motor Anti-reverse Function	Anti-reverse function to prevent upstream
IV Set	Open System. Can accept all kinds of IV Set after calibration
Self-Testing	Self-Testing when start up and during infusing
Audio Visual Alarm Message	Air bubble, occlusion, door open, infusion finish, standby time expired, battery low, battery empty, battery disengaged, AC Power disengaged, motor error, pump error, pressure sensor error, parameter error; system abnormal
Screen Power Supply	3.2' brightness LCD AC: 100V ~ 240V, 50Hz/60Hz, W 25VA
Battery	Rechargeable Lithium battery: DC11.1V, 3000mAh;operating time: > 10 hours @25ml/h, displaying remaining battery
Operation Conditon	Temperature:5°C~40°C,Relative humidity:20% ~ 80% Atmospheric pressure:70~106KPa
Transportation & Storage	Temperature:-20°C~55°C,Relative humidity:10% -95% Atmospheric pressure:50~106KPa
Classification	Type CF,Class 1 , IPX3,ISO13485,CE,IEC60601
Dimension	145mm X 150mm X 200mm ;
Weight	L7kg
