CNC Flat Clothing Honing Machine Textile Carding Machine Auxiliary Machine

Product Description

24h Online Customer Service

Product Description

FJS-1500U CNC flat clothing honing machine
Using special grinding plane grinding wheel to sharpen the tip,good flatness,tip sharp,burr.
Configure oil stone grinding head,back to the flat grinding out sharpness.
Manual of CNC grindiing amount of feed,achieve precise grinding quantity control.
Input voltage:220V+PE
Power:1100W+40W
Grinding head ratation speed:2500-6000 rpm/min adjustable
Sharpening stone honing:300 times/min,3mm
The length of the grinding:
FJS-1000U 1060mm
FJS-1500U 1520mm
Grinding head movement speed:700-3000 mm/min adjustable
Suitable for grinding the flat clothing of various types of carding machines.
Using two sets of high-precision guide rails, the CNC running and grinding system of the car ensures smooth and accurate straightness.
Equipped with a special bowl shaped grinding wheel and oil stone without loss, the grinding effect is outstanding, and the needle tip is free of obvious burrs.
After repairing and replacing the flat clothing, due to differences in the overall flatness of the keel, needle cloth, and wrapping, it meets user management standards or process requirements, and achieves the minimization of machine payment differences. The flat grinding wheel with special abrasives has a very high efficiency in repairing flatness.
Within 80% of the service life of the falt clothing, the equipped oilstone system should be used to improve the sharpness of easily worn needle clothing and extend the carding performance of the falt clothing.

---
