| Max. swing over bed | 330mm |
| Max. swing in gap | 510mm |
| Max. swing over tool post | 210mm |
| Max.machining length | 750mm |
| Spindle taper | MT5 |
| Spindle bore | 38mm |
| Max. travel of tail-stock sleeve | 100mm |
| Taper of tail-stock | MT3 |
| Rail width | 210mm |
| Maximum height of turning tool | 20mm |
| Middle carriage travel | 200mm |
| Small carriage travel | 120mm |
| Metric thread/Grade | 0.45~4mm/17 |
| Inch thread/Grade | 41/2~64T.P.I(24) |
| Transverse feed | 0.015~0.4mm |
| Longitudinal feed | 0.06~1.60mm |
| Modulus thread/Grade | 0.45~4mm/17 |
| Diameter pitch thread/Grade | 15~192DP/20 |
| Spindle speed range/Grade | 65~1600r/min(9) |
| Motor power | 2KW |
| Net weight/Gross weight | 660kg/720kg |
| Overall dimensions | 1650x700x1300mm |
| Packing Size | 1800x800x1400mm |
