Multi-Layer Chemical Test Equipment Environmental Tester Climatic Constant Temperature Humidity Testing Equipment

Product Description

Multi-Layer Chemical Test Equipment Environmental Tester Climatic Constant Temperature Humidity Testing Equipment
Detailed Photos
Product Description

Model		FTHT-072	FTHT-162
Interior size W*H*D(cm)		40*40*45	60*45*60
Exterior size W*H*D(cm)		106*176*78	126*191*83
Temp. range		-40ºC~+150ºC
Humi. Range		20%RH-95%RH
Performance	Temp. fluctuation & Humi. fluctuation	+(-)0.3ºC, +(-)3%RH
	Temp. uniformity & Humi. Uniformity	+(-)1.0ºC~+(-)1.5ºC;+(-)5%
	Controller resolution accuracy	0.1ºC, 0.1%RH
	Heating up time	30 Min
	Cooling time	40 Min
Material	Exterior material	Baked painting steel or stainless steel (SUS 304)
	Interior material	SUS#304 Stainless steel plate
	Insulation material	PU foam insulation
System	Air circulation mode	Centrifugal fan
	Heater	SUS#304 Stainless steel heating tube
	Humidifier	Steam humidification system
	Refrigeration mode	Binary compound refrigeration
	Dehumidification mode	Compressor condensation dehumidification
	Controller	Programmable Controller
Accessories		Decorative frame indicator light, Shelves*6, Fuse*2, Gauze*3, Caster*4, Temperature Recorder*1.
Safety device		NFB(No fuse breaker), dry heat protector, over pressure, over heat and over current protectors for compressor, over temperature protectors, over load protector of fan, short of water protector, fuse, e-stop(emergency stop button).
Power (KW)		AC1Ψ 220V 50HZ
		7.5	9

Company Profile
Since 2004, China Fantic Company has evolved from a technical service oriented enterprise producing environmental test chambers for Europe, the United States, Taiwan, and Japan to a professional production oriented enterprise with unique characteristics in the industry, capable of independent research and development, design, production, sales, and technical services.

Main production: programmable constant temperature and humidity chamber, composite vibration, cold and hot shock, micro thermal shock, temperature aging chamber, large walk-in constant temperature and humidity chamber, automotive environment simulation chamber, photovoltaic module rapid temperature change constant temperature and humidity chamber, sand and dust, rain, corrosion resistance, etc.
Workshop
Company Development
Certifications
Our Service
Pre-sale Service
Provide testing solution
Send specifications and quotation
In-sale Service
Design
Production
Calibration
Installation
Training
Preventative maintenance
After-sale Service
24-hour Online contact
Free software upgrades
Replacement parts
Assistance via phone or internet
On-site diagnosis and repair/online diagnosis and repair
Features
• Delicate touch screen sight and excellent user experience.
• Unique and compact design, top grade appearance, stable performance and easy operation.
• Environmental chamber can simulate a wide range of temperature and humidity environments.
• Capable of testing components, assemblies and finished products.
• Customized sizes and configurations available.
FAQ
Q:Are your company a trading one or a factory?
A:Factory + trade (integration).More than 20 years focusing on environmental test instruments field.
Q:Which certifications do you have ?
A:We have passed the CE certification,the ISO certification ,China high-tech enterprise certificate,etc.
Q:How to choose the most suitable products?
A:We will give you the best suggestion based on the information about your test sample.
Q:Does your product can be customized with my requirement?
A:Sure.
Q:After an order is placed, when to deliver?
A:Generally about 25-30 days.
Please be aware that our production lead time depends on specific items and item quantities.
Q:How is the product delivered?
A:Sea transportation is the first and the most economical way. We can also help to arrange ship by air or rail if it is urgent.
Q:What about the product' services and quality?
A:Each instrument must be carried out 100% quality examination and test when shipping and delivering goods. We provide a very specific operation manual. Usually, we will take a video to show how to operate as well. If customers need, we can also arrange for abroad onsite installation and training.
Q:What about the warranty with after - sale services?
A:We provide free parts replacement service for accessories with one year. We will supply free parts during machine warranty period if machine have some problems. While we also supply free life long after-sale service.

---
