| US$5.00-15.00 | 100 Pieces (MOQ) |
| Description | CEMA, DIN, JIS, AS, SABS, ISO Standard Design & JUXIN ODM |
| Pipe | 1) Material : Q235 carbon steel equal to DIN S235JR 2) Roller Diameter : φ63.5mm ~ φ219mm / 2 1/2 inch ~ 8 5/8 inch 3) Roller Length: 150mm ~ 3000 mm 4) Thickness : 3.0 ~6.0 mm |
| Shaft | 1) Material : 45# steel equal to DIN C45 2) Cold-drawn bright round steel 3) Shaft Diameter: 20mm, 25mm, 30mm, 40mm, 45mm, 50mm |
| Bearing | 1) Single Row Deep Groove Ball Bearing 2RS&ZZ with C3 clearance 2) Brand: SKF,FAG,NSK,HRB, LYC, ZWZ or according to your requirement |
| Bearing Housing | 1) Material : Q235 carbon steel equal to DIN S235JR 2) Cold press working fit ISO M7 accuracy 3) Material thickness: 2.5mm ~ 5.0mm |
| Seals | 1) Labyrinth seal, nylon 6 material 2) JUXIN's patented product |
| Grease | 2# Lithium grease lubricant |
| Painting | 1) Ordinary painting, hot galvanized painting, Powder painting 2) Color: Black, red, yellow, blue or according to your requirement |
| Roller No. | D | inch | s | Bearing housing | d | Bearing |
| mm | mm | δ | mm | |||
| JXCR1 | 63 | 3 | 2.5 | 20 | 6204 C3 | |
| 76 | 3 | 3 | ||||
| 89 | 3 | |||||
| 102 | 4 | 3 | ||||
| 108 | 3.5 | |||||
| 114 | 4.5 | 3.5 | ||||
| 127 | 5 | 4 | ||||
| 133 | 4 | |||||
| 140 | 4 | |||||
| JXCR 2 | 76 | 3 | 3 | 3 | 25 | 6205 C3 |
| 89 | 3 | |||||
| 102 | 4 | 3 | ||||
| 108 | 3.5 | |||||
| 114 | 4.5 | 3.5 | ||||
| 127 | 5 | 4 | ||||
| 133 | 4 | |||||
| 140 | 5.5 | 4 | ||||
| 152 | 6 | 4 | ||||
| 159 | 4.5 | |||||
| 168 | 4.5 | |||||
| JXCR3 | 89 | 3 | 3.5 | 25 | 6305 C3 | |
| 102 | 4 | 3 | ||||
| 108 | 3.5 | |||||
| 127 | 5 | 4 | ||||
| 133 | 4 | |||||
| 140 | 5.5 | 4 | ||||
| 152 | 6 | 4 | ||||
| 159 | 4.5 | |||||
| 168 | 4.5 | |||||
| JXCR4 | 89 | 3 | 3.5 | 30 | 6206 C3 | |
| 102 | 4 | 3 | ||||
| 108 | 3.5 | |||||
| 127 | 5 | 4 | ||||
| 133 | 4 | |||||
| 140 | 5.5 | 4 | ||||
| 152 | 6 | 4 | ||||
| 159 | 4.5 | |||||
| 165 | 6.5 | 4 | ||||
| 168 | 4.5 | |||||
| JXCR5 | 89 | 3 | 4 | 30 | 6306 C3 | |
| 108 | 3.5 | |||||
| 133 | 4 | |||||
| 159 | 4.5 | |||||
| JXCR6 | 108 | 4 | 5 | 40 | 6308 C3 | |
| 133 | 4 | |||||
| 159 | 4.5 | |||||
| 165 | 6.5 | 4 | ||||
| 194 | 6.3 | |||||
| Q: What is the MOQ? A: 10 sets for idlers;1 pcs for pulley. |
| Q: What is your delivery time? A: 15-20days after receiving the deposit. |
| Q: What is the payment term? A: 30% T/T in advance, then 70%T/T before shipment. |
| Q: Whether customization is supported? A: We accept customization. |
| Q:Can I get a sample for testing ? A:Yes, sample is available for free.But we don't bear the Express cost. |
