Hyundai 15ton Medium Size Hydraulic Tracked Excavator R150lvs

Product Description

Hyundai 15ton medium size hydraulic tracked excavator R150LVS
. Focused on special automobiles' design and production for nearly 10 years.
. Obtained the ISO9001 international quality management system certification.
. Achieved foreign trade qualification granted by Chinese government.
. Manufacturer direct sale,quality guaranteed, low price.
. Europe Emission Standard 2/3/4/5.
. Except standard products, also customize products according to your requirements.
Parameters
Bucket: backhoe
Working weight of the whole machine (kg): 13980
Bucket capacity (M:): 0.58
Engine: MITSUBISHI D04FRC-TAA
Rated power (kw/rpm):131(98) / 2200
Maximum torque (N.m/rpm): 49.2 / 1350
Displacement (L): 4.249
Bore diameter * stroke (mm):102*120
Cooling mode: water cooling
Working form: 4 cylinder 4 stroke water-cooled direct injection engine
Maximum flow rate of main pump (l/min): 2 x 124
Walking hydraulic circuit (Mpa): 365
Rotary hydraulic circuit (Mpa): 285
Boom cylinder - number x cylinder diameter * stroke (mm): 2-ø105×ø75×1075
Bucket cylinder cylinder number x cylinder diameter * stroke (mm): 1-ø115×ø80×11138
Bucket oil cylinder - number x cylinder diameter * stroke (mm):1-ø100×ø70×840
Fuel tank (L): 270
Hydraulic tank (L): 124
Hydraulic system (L): 210
Coolant (L): 15.3
Length (mm): 7820
Width (mm): 2600
Height (mm): 2780
Cab full height (mm): 2860
Counterweight ground clearance (mm): 940
Backend radius of gyration (mm): 2650
Number of sprockets: 1
Caterpillar plate quantity : 46
Number of loading wheels: 7
Maximum digging radius (mm): 8330
Maximum mining radius (mm): 8180
Maximum digging depth (mm): 5550
Maximum excavation height (mm): 8500
Maximum unloading height (mm): 6060

---
