Specification
| SP1325
|
X-axis travel
| 2600mm
|
Y-axis travel
| 1400 +160mm(tool change)
|
Z-axis travel
| 800mm
|
Distance from spindle nose to worktable surface
| 150-950mm
|
Worktable size(WxL)
| 2500×1100mm
|
T-slots size (NxWxD)
| 7-22-160mm
|
Max. load bearing of worktable
| 4000kgs
|
X/Y/Z guideway size
| Roller 2-45/2-45mm,Z-axis hard guideway
|
Rapid feed speed of X axis
| 10000 mm/min
|
Rapid feed speed of Y axis
| 10000 mm/min
|
Rapid feed speed of Z axis
| 10000 mm/min
|
Main motor power
| 15/18.5KW
|
Spindle model
| BT50/Φ150
|
Motor torque
| 143N.M
|
Spindle taper
| BT50
|
Blind rivets aize
| P50T-2-MAS403
|
Driven type
| Direct drive/Gear box 1:4
|
X/Y/Z linear guideway size
| X/Y-axis 2-45# roller linear guideways
|
X/Y/Z ball screw size
| X-axis 6316,Y-axis 5016,Z-axis 5016
|
Tool magazine capacity
| 24pcs, 32pcs
|
Tool arbor
| BT50
|
Max. tool dimension
| Φ110/Φ220mm
|
Max. length of tool
| 350mm
|
Max.tool weight
| 20kgs
|
Positioning accuracy
| 0.03mm
|
Re-positioning accuracy
| 0.018mm
|
Machine weight
| 21000kgs
|
Overall size (LxWxH)
| 7800x5500x5000mm
|
