| US$100,000.00-350,000.00 | 1 Piece (MOQ) |
| CSD-ALS10-1.5L | CSD-ALS12-0.6L | CSD-ALS14-0.6L | CSD-ALS16-0.6L | CSD-ALS8-2L | CSD-ALSH10-1.5L | CSD-ALSPP10 | ||
| MOLD NUMBER | 10 | 12 | 14 | 16 | 8 | 10 | 10 | |
| PRODUCT CAPACITY | L | ≤1.5L | ≤0.6L | ≤0.6L | ≤0.6L | ≤2L | ≤1.5L | ≤1.5L |
| PRODUCTION CAPACITY | Pcs/h | 10000-11000 PCS/H (3.6S/CYCLE) BASED ON 500ml BOTTLE,PREFORM NECK:28-30mm,WEIGHT:17g 8500-9000 PCS/H BASED ON 1000ml BOTTLE,PREFORM NECK:28-30mm,WEIGHT:28g 7000-8000 PCS/H, BASED ON 1500ml BOTTLE,PREFORM:28-30mm, WEIGHT:37g | 12600-13000 PCS/H (3.6S/CYCLE) BASED ON 500ml BOTTLE,PREFORM NECK:28-30mm,WEIGHT:17g | 14700-15000 PCS/H (3.6S/CYCLE) BASED ON 500ml BOTTLE,PREFORM NECK:28-30mm,WEIGHT:17g | 15000-16000 PCS/H (3.6S/CYCLE) BASED ON 500ml BOTTLE,PREFORM NECK:28-30mm,WEIGHT:17g | 8000-8500 PCS/H BASED ON 500mlBOTTLE,PREFORM NECK:28-30mm,WEIGHT:17g 6800-7200 PCS/H BASED ON 1000ml BOTTLE,PREFORM NECK:28-30mm,WEIGHT:28g 6500-7000 PCS/H BASED ON 1500ml BOTTLE,PREFORM NECK 28-30mm,WEIGHT:33g 5500-6000 PCS/H BASED ON 2000ml BOTTLE,PREFORM NECK:28-30mm,WEIGHT:48g | 4500 PCS/H BASED ON 500ml BOTTLE,PREFORM NECK 28-30mm,WEIGHT:34g 3800 PCS/H, BASED ON 1500mlBOTTLE,PREFORM NECK:28-30mm,WEIGHT:66g | 7200PCS/H |
| MAX.DIAMETER OF PRODUCT | mm | φ95 | Φ70 | Φ70 | Φ70 | φ110 | φ95 | φ70 |
| NECK SIZE OF PRODUCT | Mm | φ28-φ30 | φ28-φ30 | φ28-φ30 | φ28-φ30 | φ28-φ30 | φ28-φ30 | φ28-φ30 |
| WORKING PRESSURE | MPa | 0.8-1.0 | 0.8-1.0 | 0.8-1.0 | 0.8-1.0 | 0.8-1.0 | 0.8-1.0 | 0.8-1.0 |
| BLOWING AIR PRESSURE | MPa | 2.8-3.0 | 2.8-3.0 | 2.8-3.0 | 2.8-3.0 | 2.8-3.0 | 2.8-3.0 | 2.8-3.0 |
| MEASUREMENT OF MAIN BLOWER | Mm | 7500x5700x3600 | 9000x6000x3600 | 10000x6000x3600 | 11200x6000x3600 | 8000x5700x3600 | 7500x5700x3600 | 11400x5700x3600 |
| POWER OF PREHEATER | kW | 201 | 120 | 120 | 120 | 201 | 201 | 300 |
| A | 300 | 160 | 160 | 160 | 300 | 300 | 400 | |
| ACTUAL POWER OF PREHEATER(BASED ON 500ML BOTTLE) | kW | 60 | 60 | 60 | 60 | 60 | 60 | 80 |
| POWER OF PREHEATER | kW | 16 | 20 | 20 | 20 | 16 | 16 | 16 |
| WEIGHT OF MAIN BLOWER | T | 10 | 11 | 12 | 13 | 11 | 10 | 12 |
| MEASUREMENT OF CONVEYER | Mm | 3600x2800x3700 | 3800x2800x3700 | 4000x2800x3700 | 4000x2800x3700 | 3600x2800x3700 | 3600x2800x3700 | 3600x2800x3700 |
| WEIGHT OF CONVEYER | T | 0.5 | 0.55 | 0.55 | 0.55 | 0.5 | 0.5 | 0.5 |
| HIGH PRESSURE AIR COMPRESSOR UNIT | kW | 22x6 | 22x4 | 22x5 | 22x5 | 22x6 | 22x4 | 22×3 |
| MPa | 3.0 | 3.0 | 3.0 | 3.0 | 3.0 | 3.0 | 3.0 | |
| m³/min | 12 | 8 | 10 | 10 | 12 | 8 | 6 | |
| LOW PRESSURE AIR COMPRESSOR | m³ | 1.0 | 1.0 | 1.0 | 1.0 | 1.0 | 1.0 | 22 |
| MPa | 1.25 | 1.25 | 1.25 | 1.25 | 1.25 | 1.25 | 1.25 | |
| AIR TANK | m³ | 2.0 | 1.0 | 2.0 | 2.0 | 2.0 | 1.0 | 1 |
| MPa | 3.0 | 3.0 | 3.0 | 3.0 | 3.0 | 3.0 | 3.0 | |
| WATER CHILLER | Kcal/Hr | 33352 | 33352 | 33352 | 33352 | 33352 | 33352 | 33352 |
| HP | 15 | 15 | 15 | 15 | 15 | 15 | 15 | |
| AIR DRYER | m³/min | 12 | 8 | 10 | 10 | 12 | 8 | 6 |
| MPa | 3.0 | 3.0 | 3.0 | 3.0 | 3.0 | 3.0 | 3.0 | |
| OIL FILTER | m³/min | 12 | 8 | 10 | 10 | 12 | 8 | 6 |
| MPa | 3.0 | 3.0 | 3.0 | 3.0 | 3.0 | 3.0 | 3.0 | |
| ODOR REMOVAL FILTER | m³/min | 12 | 8 | 10 | 10 | 12 | 8 | 6 |
| MPa | 3.0 | 3.0 | 3.0 | 3.0 | 3.0 | 3.0 | 3.0 | |
| AIR FILTER | m³/min | 12 | 8 | 10 | 10 | 12 | 8 | 6 |
| MPa | 3.0 | 3.0 | 3.0 | 3.0 | 3.0 | 3.0 | 3.0 | |
