Features
1. Advanced IGBT technology, energy-efficient and low noise.
2. Digital display, precisely controlled welding current, stable welding process, and excellent welding characteristics.
3. Effective spatter control, improved penetration and better welding effect.
4. Circuit protection against over current, over voltage,and over heat.
5. Built-in wire feeder and adjustable wire feeding speed.
6. Gas/No gas usage optional.
7. Compete with MIG torch, electrode holder, earth clamp, face mask, hammer.
Technical Specifications
ITEM
| UNIT
| MIG-140TY
| MIG-160TY
|
Input Power Voltage
| V
| AC230V±10%
| AC230V±10%
|
Input Power Frequency
| Hz
| 50/60
| 50/60
|
Rated Input Capacity
| KVA
| 3.8
| 4.5
|
Output Current Range (MIG)
| A
| 40-140
| 40-160
|
Output Current Range (MMA)
| A
| 20-120
| 20-140
|
Load Voltage
| V
| 16-21
| 16-22
|
Rated Duty Cycle
| %
| 60
| 60
|
Wire Feed Speed
| M/min
| 3-15
| 3-15
|
Gas Flow
| L/min
| 15-20
| 15-20
|
Dimensions
| MM
| 340*140*275
| 340*140*275
|
weight
| Kg
| 6.8
| 7
|
Related products
Company Introduction
Certifications
Exhibition
Action now
Why choose Retop?
a. We are welding machine MANUFACTURER, so we can offer better price and after-sale service and shorter delivery date.
b. We use all new components,mosfet tube, diode, capacitor and so on imported components.
c. We adopt IGBT technology to decrease failure rate and it is convenient to repair the welding machine and reduce the cost of
repairing, we just need to change the bad pcb board.
d. We provide Warranty period of 1 year for all our items
